Eaton Crouse-Hinds EDS218 Snap Switch Control Station - Hazardous/Classified Locations
Part Number: EDS218
Quick Summary
EDS218 snap switch control station provides reliable local control for hazardous industrial panels. In hazardous environments, maintenance and sealed-enclosure integrity are persistent challenges that can lead to costly downtime. This unit is designed to meet NEC/CEC standards and is rated for Class I, Division 1 and 2, Class II Division 1 and 2, as well as Class III, with corresponding NEMA ratings of 3, 7, and 9, enabling compliant operation in tough locations. By combining a factory-sealed enclosure, a single-gang footprint, and a 3/4 inch hub for fast wiring, it delivers safer installations, quicker commissioning, and lower lifecycle costs for industrial automation and electrical protection teams.
Product Information
Extended Description
EDS218 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With one 3/4" hub, Feraloy iron alloy, 1, Single-gang, Two-pole, 120-277V, Factory sealed, Dead end, Two-pole, 3/4", 120-277 Vac
Product Name
Eaton Crouse-Hinds series EDS snap switch control station
Catalog Number
EDS218
Product Length/Depth
5.06 in
Product Height
5.875 in
Product Width
3.5 in
Product Weight
8.2 lb
UPC
782274763545
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
NEMA Rating
3 7 9
Enclosure type
With switch
Trade size
3/4"
Number Of Poles
Two-pole
Switch function
Two-pole
Number of gangs
Single-gang
Style
Dead end
Voltage rating
120-277 Vac
Amperage Rating
20A
Hub style
With one 3/4" hub
Number of devices
1
Primary voltage range
120-277V
Material
Feraloy iron alloy
Special features
Factory sealed
EDS and EDSX Fully Assembled Snap Switches catalog page
EDS and EFD Explosionproof Snap Switches Canadian certification - snap switches
EDS and EFD Explosionproof Snap Switches Canadian certification - snap switches
EDS and EFD Explosionproof Snap Switches Canadian certification - snap switches
EDS and EFD Explosionproof Snap Switches Canadian certification - snap switches
IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies
IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies
Eaton Specification Sheet - EDS218
Factory-sealed enclosure protects against dust, moisture, and arc-related risks in hazardous locations, reducing field faults and downtime while improving safety during maintenance and inspections. The 3/4 inch hub simplifies wiring routing, speeds up panel assembly, and helps meet enclosure fill and clearance requirements without compromising seal integrity. A 20A, 120-277 Vac two-pole switch provides reliable, versatile control for motors and loads across a broad operating window, reducing the need for multiple components and cutting total installed cost. Built from Feraloy iron alloy, the enclosure offers rugged durability in demanding environments such as oil, gas, and chemical processing, boosting lifecycle value and improving equipment availability. Compliance with NEC/CEC ratings and NEMA 3, 7, 9 further streamlines procurement and regulatory reviews, while compatibility with installation sheets like IF328 supports consistent field practices across sites. The single-gang, dead-end style design minimizes space, simplifies upgrades, and accelerates retrofit projects in existing control panels.
Get a Quick Quote for a Eaton Crouse-Hinds EDS218
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds EDS218?
Enquire Now
FAQs
Plan for a single-gang enclosure footprint, allow the 5.06 in depth and 5.875 in height, and use the factory 3/4 inch hub to route conductors. Ensure wiring methods meet hazardous-location requirements and follow the IF328 instructions for device bodies during mounting and sealing to preserve the enclosure’s integrity.
EDS218 is a 20 A, 120-277 Vac two-pole snap switch with a dead-end, single-gang enclosure. It features a 3/4 inch hub, and is designed for one device in a two-pole configuration, supporting a broad operating range while maintaining a compact form factor for panel space efficiency.
Yes. The device is suitable for NEC/CEC compliance and rated for Class I Division 1 and 2, Class II Division 1 and 2, and Class III. It is intended for Hazardous/Classified Locations and carries compatible NEMA ratings, simplifying regulatory reviews and on-site approvals.
Ideal for hazardous-area control in oil, gas, and chemical processing, as well as other environments requiring safe, sealed switch control. It supports machine enclosures, conveyors, pumps, and other equipment where dependable local control with rugged enclosure protection is needed.
Support documents include installation sheets such as IF328 for EDS bodies, plus the Eaton catalog page for EDS218 and the official Eaton specification sheet. These resources aid proper mounting, wiring, and assembly to maintain certified enclosure integrity.
