Eaton Crouse-Hinds EDS3130 Snap Switch - Hazardous Locations

Part Number: EDS3130
EDS3130
Manufacturer
Eaton Crouse-Hinds
Part number
EDS3130
Category

Quick Summary

EDS3130 snap switch control station provides protected control for electrical systems in hazardous locations. Engineers often contend with wiring complexity and safety risk when servicing equipment in Class I/II environments. This unit meets NEC/CEC requirements and is rated for Class I Division 1 and Class II, with NEMA 3, 7, and 9 enclosure compatibility. Designed for enclosed control stations and snap-switch configurations, it delivers reliable operation while reducing downtime and maintenance costs.

Product Information

Extended Description

EDS3130 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With one 1" hub, Feraloy iron alloy, 1, Single-gang, Three-pole, 2, 120-277V, Dead end, 3-way, 1", 120-277 Vac
Product Name
Eaton Crouse-Hinds series EDS snap switch control station
Catalog Number
EDS3130
Product Length/Depth
5.06 in
Product Height
5.875 in
Product Width
3.5 in
Product Weight
8.7 lb
UPC
782274764016
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
NEMA Rating
3 7 9
Enclosure type
With switch
Trade size
1"
Number Of Poles
Three-pole
Switch function
3-way
Number of gangs
Single-gang
Style
Dead end
Voltage rating
120-277 Vac
Amperage Rating
20A
Hub style
With one 1" hub
Number of devices
1
Number of pushbuttons
2
Primary voltage range
120-277V
Material
Feraloy iron alloy
EDS and EDSX Fully Assembled Snap Switches catalog page EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies IF 242 - EDS and EDSC Control Stations IF 242 - EDS and EDSC Control Stations Eaton Specification Sheet - EDS3130
Feature: 20A amperage rating delivers capable control for demanding loads → Business Impact: minimizes the need for upstream protection and reduces contractor rework → Application: suitable for industrial machines and conveyors in hazardous areas. Feature: 1" hub and single-gang, three-pole switch configuration → Business Impact: simplifies wiring and accelerates panel assembly → Application: common in compact hazardous-location control stations. Feature: Ferrolay iron alloy enclosure with three-pole, 3-way switching → Business Impact: provides rugged durability against impact and corrosion → Application: long service life in harsh plants. Feature: 120–277V voltage range and dead-end, with switch included → Business Impact: flexible sourcing and easier field wiring → Application: universal fit for low/medium voltage control panels. Feature: NEC/CEC compliance and NEMA 3, 7, 9 ratings → Business Impact: ensures regulatory alignment and safer operation → Application: mandatory for regulated facilities. Feature: 2 pushbuttons and 1 device inclusion → Business Impact: expands control functions without panel overcrowding → Application: compact control stations in automated lines.

Get a Quick Quote for a Eaton Crouse-Hinds EDS3130

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton Crouse-Hinds EDS3130? Enquire Now

FAQs

When installing the EDS3130, ensure the enclosure is mounted within approved hazardous-location zones and that wiring follows NEC/CEC guidelines for Class I, II, and III environments. Use the 1" hub for feed-through wiring where possible and verify proper torque on terminals. Check that the device is wired as a three-pole, 3-way configuration to maintain correct functionality.
EDS3130 conforms to NEC/CEC standards and is rated for Hazardous/Classified Locations. It carries NEC hazardous ratings for Class I Division 1 and Division 2, Class II Division 1 and 2, and Class III, with a NEMA rating of 3, 7, and 9. These certifications support compliant risk management in industrial automation and panel design.
Yes. The EDS3130 is specified for 120–277V operation and a 20A amperage rating, making it compatible with a wide range of control circuits and auxiliary devices. This facilitates direct integration into standard low- to medium-voltage control panels without requiring specialized components.
The EDS3130 is designed as a compatible snap switch control station and works well with related Eaton Crouse-Hinds EDS/EDSX family components. Its single-gang footprint, 1" hub, and three-pole configuration support straightforward integration into existing panel layouts, preserving space and simplifying maintenance.
The EDS3130 reduces maintenance overhead through a rugged feraloy iron alloy enclosure, fewer wiring errors due to a standardized hub-and-switch layout, and dependable operation in hazardous locations. The design minimizes downtime, accelerates commissioning, and improves ongoing reliability, delivering a favorable total cost of ownership for regulated industrial applications.
