Eaton EDS3140 Snap Switch Control Station - Hazardous

Part Number: EDS3140
EDS3140
Manufacturer
Eaton Crouse-Hinds
Part number
EDS3140
Category

Quick Summary

EDS3140 is a snap switch control station for hazardous-location motor control and fault isolation. Engineers often face complex wiring, safety compliance, and downtime when upgrading legacy control stations. This unit meets NEC/CEC requirements and hazardous-location classifications, including Class I, Division 1 and 2, Class II, Division 1 and 2, and Class III, with a NEMA 3, 7, 9 enclosure. With a 1-inch hub, 20A rating, and a compact single-gang footprint, it supports straightforward installation, reliable operation, and lower total installed cost across the project lifecycle. Designed for OEMs and panel builders, the EDS3140 reduces integration risk by providing a standardized control interface that works with common wiring schemes.

Product Information

Extended Description

EDS3140 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With one 1" hub, Feraloy iron alloy, 1, Single-gang, Four-pole, 2, 120-277V, Dead end, 4-way, 1", 120-277 Vac
Product Name
Eaton Crouse-Hinds series EDS snap switch control station
Catalog Number
EDS3140
Product Length/Depth
5.06 in
Product Height
5.875 in
Product Width
3.5 in
Product Weight
7.9 lb
UPC
782274764023
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
NEMA Rating
3 7 9
Enclosure type
With switch
Trade size
1"
Number Of Poles
Four-pole
Switch function
4-way
Number of gangs
Single-gang
Style
Dead end
Voltage rating
120-277 Vac
Amperage Rating
20A
Hub style
With one 1" hub
Number of devices
1
Number of pushbuttons
2
Primary voltage range
120-277V
Material
Feraloy iron alloy
EDS and EDSX Fully Assembled Snap Switches catalog page EDS and EFD Explosionproof Snap Switches Canadian certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches Canadian certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches Canadian certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches Canadian certification - industrial control panels and assemblies IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies Eaton Specification Sheet - EDS3140
Rugged enclosure construction using Feraloy iron alloy delivers superior mechanical strength and heat resistance for demanding industrial spaces, helping prevent enclosure breaches in rough environments. The dead-end style with a four-pole, four-way switch enables straightforward wiring for motor control circuits, reducing commissioning time and potential miswiring. A 1" hub supports flexible field wiring and future expansion while keeping panel space efficient, and the single-gang footprint simplifies retrofit into existing enclosures without major cabinet modifications. Rated for 20A at 120-277Vac, the device accommodates a wide range of loads, improving compatibility with common motors and starter circuits while maintaining safety margins. Compliance with NEC/CEC and hazardous-location approvals, plus NEMA 3, 7, 9 enclosures, minimizes regulatory risk and audit time. Installation resources, including IF328 instructions, streamline field mounting and help maintenance teams reference correct wiring schemas, resulting in lower lifecycle costs. In real-world applications across chemical processing, oil and gas, and heavy manufacturing, the EDS3140 delivers measurable uptime gains and safer operation, supporting both new builds and plant modernization projects.
