Eaton EDSC218 Snap Switch Station - Hazardous Locations

Part Number: EDSC218
EDSC218
Manufacturer
Eaton Crouse-Hinds
Part number
EDSC218
Category

Quick Summary

The EDSC218 snap switch control station delivers reliable, fail-safe control for hazardous-location electrical panels in industrial automation environments. Operators often face unexpected downtime, maintenance delays, and safety risks when switching equipment in harsh, hazardous environments. It supports hazardous/classified locations per NEC/CEC and aligns with demanding standards, including NEMA ratings 3, 7, and 9. Through-feed enclosure, two 3/4-inch hubs, and a 120–277V, 20A two-pole design streamline wiring, installation, and future upgrades. Factory sealing and feraloy iron alloy construction reduce leak paths, extend life in harsh plants, and lower lifecycle costs. US-based support and readily available spare parts help keep critical lines running.

Product Information

Extended Description

EDSC218 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With two 3/4" hubs, Feraloy iron alloy, 1, Single-gang, Two-pole, 120-277V, Factory sealed, Through feed, Two-pole, 3/4", 120-277 Vac
Product Name
Eaton Crouse-Hinds series EDS snap switch control station
Catalog Number
EDSC218
Product Length/Depth
5.06 in
Product Height
5.875 in
Product Width
3.5 in
Product Weight
8.5 lb
UPC
782274765280
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
NEMA Rating
3 7 9
Enclosure type
With switch
Trade size
3/4"
Number Of Poles
Two-pole
Switch function
Two-pole
Number of gangs
Single-gang
Style
Through feed
Voltage rating
120-277 Vac
Amperage Rating
20A
Hub style
With two 3/4" hubs
Number of devices
1
Primary voltage range
120-277V
Material
Feraloy iron alloy
Special features
Factory sealed
EDS and EDSX Fully Assembled Snap Switches catalog page EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies IF 242 - EDS and EDSC Control Stations IF 242 - EDS and EDSC Control Stations Eaton Specification Sheet - EDSC218
The EDSC218 is a rugged, through-feed snap switch control station designed for hazardous locations. It combines a two-pole, 20A capability with a 120–277V voltage range, a single-gang enclosure, and two 3/4 inch hubs to simplify wiring and integration in restricted spaces. This balance of compact form factor and robust performance translates into faster installation and safer operation on machine control panels, safety interlock stations, and process lines. The feraloy iron alloy body, factory sealing, and durable enclosure deliver greater resistance to dust, moisture, and chemical exposure, reducing maintenance cycles and extending service life. Built to NEC/CEC standards with hazardous location classifications and a NEMA rating of 3/7/9, it supports regulatory compliance across diverse industries. Through-feed capability and modular hubs also enable scalable upgrades without extensive rewiring, improving overall system reliability and lowering total cost of ownership.

Get a Quick Quote for a Eaton Crouse-Hinds EDSC218

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton Crouse-Hinds EDSC218? Enquire Now

FAQs

Yes. The EDSC218 supports through-feed installation in hazardous locations with two 3/4 inch hubs, a single-gang enclosure, and a 120–277V, 20A two-pole design. It is factory sealed and rated for Class I and II locations per NEC/CEC, with NEMA 3, 7 and 9 compatibility, making it suitable for tough industrial environments.
Key specs include 20A amperage, 120–277V AC voltage rating, two-pole switching, through-feed design, and an enclosure measuring 5.06 in length by 5.875 in height and 3.5 in width. These specs support convenient integration with common automation circuits while maintaining safe switching performance, short-circuit protection, and reliable operation in demanding environments.
Industries such as oil and gas, chemical processing, mining, and other heavy manufacturing benefit from the EDSC218. It's ideal for control stations that demand reliable two-pole switching, rugged enclosure with factory sealing, and through-feed wiring in hazardous locations. Use it in machine control panels, safety interlock stations, and process lines where compliance with NEC/CEC and NEMA 3/7/9 is critical.
Expect NEC/CEC compliance for hazardous locations, area classifications for Class I and II and Class III environments, and NEMA ratings of 3, 7, and 9. The unit is factory sealed and built with feraloy iron alloy to withstand dust, moisture, and corrosive exposures typical in harsh plants, supporting safer operation and easier regulatory audits.
By reducing installation time with through-feed hubs, simplifying wiring, and providing a rugged, factory-sealed enclosure, the EDSC218 lowers labor costs and minimizes downtime. Its durable construction and hazardous-location rating reduce maintenance intervals and replacement frequency in harsh environments, delivering measurable ROI through longer service life, fewer field repairs, and improved system reliability across critical control points.
