Eaton EDSC3230 Snap Switch Control Station - NEC/CEC

Part Number: EDSC3230
EDSC3230
Manufacturer
Eaton Crouse-Hinds
Part number
EDSC3230
Category

Quick Summary

The Eaton EDSC3230 Snap Switch Control Station delivers rugged control for hazardous-location panels. Maintenance teams often struggle to keep controls safe and sealed in Class I/II environments without sacrificing accessibility. This model carries NEC/CEC compliance with hazardous ratings Class I Div 1 and 2, Class II Div 1 and 2, plus Class III, and a NEMA 3, 7, 9 protection profile. Two-device, two-gang architecture with 1" hubs supports straightforward wiring, faster install, and long-term reliability. Engineered for through-feed, factory-sealed performance, it minimizes field modifications and supports compliance-driven dashboards. In practical terms, operators gain safer operation, reduced maintenance, and regulatory peace of mind in oil & gas, chemical, and mining environments. This makes it a reliable backbone for hazardous-area control rooms and outdoor installations. And with industry-standard dimensions and wiring access, it integrates with existing Eaton/Crouse-Hinds equipment.

Product Information

Extended Description

EDSC3230 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With two 1" hubs, Feraloy iron alloy, 2, Two-gang, Three-pole, 120-277V, Factory sealed, Through feed, 3-way, 1", 120-277 Vac
Product Name
Eaton Crouse-Hinds series EDS snap switch control station
Catalog Number
EDSC3230
Product Length/Depth
5.06 in
Product Height
5.875 in
Product Width
7.19 in
Product Weight
15.35 lb
UPC
782274765990
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
NEMA Rating
3 7 9
Enclosure type
With switch
Trade size
1"
Number Of Poles
Three-pole
Switch function
3-way
Number of gangs
Two-gang
Style
Through feed
Voltage rating
120-277 Vac
Amperage Rating
20A
Hub style
With two 1" hubs
Number of devices
2
Primary voltage range
120-277V
Material
Feraloy iron alloy
Special features
Factory sealed
EDS and EDSX Fully Assembled Snap Switches catalog page EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies EDS and EFD Explosionproof Snap Switches UL certification - industrial control panels and assemblies IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies Eaton Specification Sheet - EDSC3230
Feature → Business Impact → Application: Hazardous-location ratings and factory sealing deliver enhanced safety and reduced risk of ignition or moisture ingress in Class I/II/III environments; ideal for oil & gas, chemical processing, and mining control panels. Feature → Business Impact → Application: 20A, 120–277V, 3-way, three-pole configuration supports versatile control schemes and reliable operation for machine and process panels in industrial plants. Feature → Business Impact → Application: Two-gang enclosure with two devices and two 1" hubs simplifies wiring, speeds installation, and reduces field rework on legacy or retrofit projects. Feature → Business Impact → Application: Through-feed design and factory-sealed construction lower ongoing maintenance needs, extending service life in harsh environments like offshore platforms and refineries. Feature → Business Impact → Application: Feraloy iron alloy enclosure and NEMA 3, 7, 9 protection provide durable protection against corrosion, shock, and ingress in outdoor or exposed locations. Feature → Business Impact → Application: NEC/CEC compliance and documented installation guidance ensure consistent safety audits and straightforward integration with existing Eaton/Crouse-Hinds device portfolios.

Get a Quick Quote for a Eaton Crouse-Hinds EDSC3230

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton Crouse-Hinds EDSC3230? Enquire Now

FAQs

Install the EDSC3230 as a two-gang, two-device control station within a suitable enclosure rated for Class I/II environments. Use the two 1" hubs for through-feed wiring and follow the IF328 instructions for EDS/EDSX device bodies to maintain factory seals. Verify NEC/CEC compliance and NEMA ratings (3, 7, 9) are appropriate for your location and panel design.
The unit is rated for 20A at 120–277V AC with a three-pole, two-device configuration and 3-way switch function. It features through-feed capability and two dedicated 1" hubs, enabling flexible wiring layouts and reliable operation in demanding industrial environments.
Yes. The enclosure’s Hazardous/Classified Locations rating, NEC/CEC compliance, and NEMA 3, 7, 9 protection make it appropriate for oil & gas, chemical processing, and mining facilities where safe, sealed control points are required under harsh conditions.
The EDSC3230 carries NEC/CEC compliance with Class I/II/III hazardous ratings and NEMA 3, 7, 9 ratings. It is designed for Hazardous/Classified Locations and aligns with standard installation practices, improving audit readiness and reducing noncompliance risk in regulated industries.
Factory sealing and a robust Feraloy iron alloy enclosure minimize ingress and corrosion, reducing maintenance cycles. The through-feed design and straightforward wiring lower installation time and field modifications, delivering quicker return on investment through improved uptime and safer, compliant operation.
