Eaton FMVA11LCY-UNV1-33 LED Floodlight - IP66 Rated

Part Number: FMVA11LCY-UNV1-33
FMVA11LCY-UNV1-33
Manufacturer
Eaton Crouse-Hinds
Part number
FMVA11LCY-UNV1-33
Category

Quick Summary

The Eaton Crouse-Hinds Champ FMVA LED floodlight provides high-output illumination for hazardous-area installations. In harsh environments, reliability and compliance are essential, and downtime from failed lighting harms operations. This fixture combines rugged die-cast aluminum housing, a heat- and impact-resistant glass lens, and a dimmable driver to fit modern controls. It carries NEC/CEC and IECEx/ATEX certifications, including Class I Division 2 and Zone 2, Class II Division 1, plus IP66 and NEMA 4X ratings for outdoor and hazardous locations. By delivering efficient performance with compliant construction, it reduces energy use and maintenance, while improving safety. For engineers and procurement teams, it enables reliable lighting with straightforward installation and scalable support for growing facilities.

Product Information

Extended Description

FMVA11LCY-UNV1-33 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Champ FMVA LED floodlight, Cool white, Dimmable driver, 3/4" entry, 320W equiv, Heat and impact resistant glass lens, 11000 lumens, 144 lm/W, Die cast alum, Yoke mount, 100-277 Vac, 108-250 Vdc, 84W, 3x3 optics
Product Name
Eaton Crouse-Hinds series Champ FMVA LED floodlight
Catalog Number
FMVA11LCY-UNV1-33
Product Length/Depth
15.5 in
Product Height
12 in
Product Width
7 in
Product Weight
31.8 lb
UPC
662276880566
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC IEC IECEx/ATEX
NEC hazardous rating
Class I, Division 2 Class I, Zone 2 Class II, Division 1 Class III
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Lamp type
LED
Lumens
11000
Lumens per watt
144
Color temperature
Cool white
Mounting Method
Yoke
Voltage rating
100-277 Vac, 108-250 Vdc
Frequency rating
50/60 Hz
Optical distribution
3x3
Entry size
3/4"
Lens material
Heat and impact resistant glass
Wattage
84 W
Dimming
Dimmable driver
Equivalent luminaire
320W
Power factor
> 0.90
Material
Die cast aluminum
SP3D Design Package - Champ FMVA LED Hazardous Area Floodlights Crouse-Hinds series Champ FMVA LED Floodlights - 9,000 to 15,000 lumens brochure Crouse-Hinds series Champ FMVA LED Floodlights - 9,000 to 15,000 lumens brochure Crouse-Hinds series Champ FMVA LED Floodlights - 9,000 to 15,000 lumens catalog page Champ FMVA LED Hazardous Area Floodlights EC-Declaration of Conformity Champ FMVA LED Hazardous Area Floodlights EC-Declaration of Conformity Champ FMVA LED Hazardous Area Floodlights EC-Declaration of Conformity Champ FMVA LED Hazardous Area Floodlights EC-Declaration of Conformity Champ FMVA LED Hazardous Area Floodlights EC-Declaration of Conformity Champ FMVA LED Hazardous Area Floodlights EC-Declaration of Conformity IF 1883 - Champ FMVA LED Floodlight IF 1883 - Champ FMVA LED Floodlight Eaton Specification Sheet - FMVA11LCY-UNV1-33
High-output efficiency with rugged construction promotes energy savings and reliability in hazardous locations. Feature → Business Impact → Application: 11,000 lumens at 144 lm/W from an 84 W source reduces energy cost while maintaining light levels across large sites; ideal for outdoor plant footprints and outdoor staging areas. Feature → Business Impact → Application: 100-277 VAC / 108-250 VDC universal input simplifies site wiring and lowers install time, enabling quick deployment across multi-site facilities. Feature → Business Impact → Application: IP66 and NEMA 4X protection plus heat- and impact-resistant glass lens deliver durable operation in washdown zones, chemical plants, and offshore locations. Feature → Business Impact → Application: Dimmable driver supports integrated lighting controls, reducing peak demand charges and enabling scheduled maintenance. Feature → Business Impact → Application: 3x3 optical distribution plus 3/4" entry with yoke mount offers flexible mounting for complex industrial layouts. Feature → Business Impact → Application: NEC/CEC IECEx/ATEX certifications and hazardous-location ratings ensure compliance, simplifying procurement and reducing risk for regulated environments.

Get a Quick Quote for a Eaton Crouse-Hinds FMVA11LCY-UNV1-33

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton Crouse-Hinds FMVA11LCY-UNV1-33? Enquire Now

FAQs

The luminaire features a 3/4 inch entry and a versatile yoke mounting option, with universal voltage input (100-277 VAC, 108-250 VDC) and a dimmable driver. It is designed for Class I Division 2 / Zone 2, Class II Division 1 environments and IP66/NEMA 4X protection, simplifying installation across mixed sites and preserving hazardous-location compliance.
It delivers 11,000 lumens at 144 lm/W from an 84 W source, with a 3x3 optical distribution and cool-white color. The driver supports dimming, and the unit maintains a power factor > 0.90, supporting stable operation and energy management in demanding facilities.
Yes. FMVA11LCY-UNV1-33 is certified for NEC/CEC, IECEx/ATEX, and hazardous-location ratings including Class I Division 2 / Zone 2, Class II Division 1. It also features IP66 and NEMA 4X protection, making it suitable for outdoor, washdown, and chemically aggressive locations.
This luminaire complies with NEC/CEC and IECEx/ATEX standards, plus hazardous-location classifications for Class I Division 2 / Zone 2 and Class II Division 1. It also carries IP66 and NEMA 4X ratings, ensuring safety, reliability, and regulatory alignment for industrial facilities.
The dimmable driver and high-efficiency LED output reduce energy consumption and allow integration with smart controls, lowering operating costs. Rugged construction minimizes maintenance cycles in harsh environments, while the robust lens and housing withstand demanding conditions, delivering longer service intervals and improved total cost of ownership.
