Eaton FMVA50LCY/UNV1 LED Floodlight - IP66
Part Number: FMVA50LCY/UNV1 76 BZ
Manufacturer
Eaton Crouse-Hinds
Part number
FMVA50LCY/UNV1 76 BZ
Category
Quick Summary
FMVA50LCY/UNV1 LED floodlight provides high-output illumination for hazardous locations in industrial facilities. Maintenance teams face corrosion, rugged environments, and downtime; this fixture delivers rugged reliability and long service life. It carries IP66 protection with a NEMA 4X enclosure and NEC/CEC hazardous-location certifications, including ATEX/IECEx, ensuring global compliance. The dimmable driver and broad 100–277 VAC range enable flexible integration with existing controls, driving energy efficiency and a lower total cost of ownership. With 50,000 lumens at 126 lm/W and a robust die-cast aluminum housing, it combines performance with durability for demanding outdoor and indoor applications.
Product Information
Extended Description
FMVA50LCY/UNV1 76 BZ Eaton Crouse-Hinds: Eaton Crouse-Hinds series Champ FMVA LED floodlight, 4.14A, Cool white, Dimmable driver, 3/4", 1500W+ equiv, Heat and impact resistant glass lens, 50,000 lm, 126 lm/W, Die cast alum, 7x6 optics, Bronze paint, 100-277 Vac, 400W
Product Name
Eaton Crouse-Hinds series Champ FMVA LED floodlight
Catalog Number
FMVA50LCY/UNV1 76 BZ
Product Length/Depth
15.35 in
Product Height
24 in
Product Width
17.28 in
Product Weight
32.5 lb
UPC
662276661745
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class II, Division 1 Class I, Division 2 Class I, Zone 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Lamp type
LED
Lumens
50000
Lumens per watt
126
Color temperature
Cool white
Mounting Method
Yoke
Voltage rating
100-277 Vac
Frequency rating
50/60 Hz
Optical distribution
7x6
Entry size
3/4"
Lens material
Heat and impact resistant glass
Finish color
Epoxy painted RAL 7032
Wattage
2 x 8.7W
Dimming
Dimmable driver
Equivalent luminaire
1500W+
Power factor
> 0.90
Amperage Rating
4.14 A
Material
Die cast aluminum
SP3D Design Package - Champ FMVA LED Hazardous Area Floodlights
Crouse-Hinds series DLC approved lighting products
Crouse-Hinds series DLC approved lighting products
Crouse-Hinds series Champ FMVA LED Floodlights - 20,000 to 50,000 lumens catalog page
Champ FMVA LED Hazardous Area Floodlights ATEX Certificate
Champ FMVA LED Hazardous Area Floodlights ATEX Certificate
Champ FMVA LED Hazardous Area Floodlights ATEX Certificate
Champ FMVA LED Hazardous Area Floodlights ATEX Certificate
Champ FMVA LED Hazardous Area Floodlights ATEX Certificate
Champ FMVA LED Hazardous Area Floodlights ATEX Certificate
IF 1842 - Champ FMVA40L/50L LED Floodlights
IF 1842 - Champ FMVA40L/50L LED Floodlights
IF 1842 - Champ FMVA40L/50L LED Floodlights
Eaton Specification Sheet - FMVA50LCY/UNV1 76 BZ
Feature → Business Impact → Application: LED technology delivers high brightness with 50,000 lumens and 126 lm/W, enabling lower mounting densities and broader coverage while reducing energy use and maintenance costs; Application: outdoor yards, refineries, and mining sites requiring bright, reliable illumination in hazardous zones. Feature → Business Impact → Application: Dimmable driver provides compatibility with control systems, enabling scene setting and reduced electricity consumption during low-demand periods; Application: plant-wide lighting schemes and automation initiatives. Feature → Business Impact → Application: 2 x 8.7W LED array delivers strong light output from a compact footprint, improving installation flexibility and reducing wiring complexity; Application: retrofit projects and new builds in hazardous locations. Feature → Business Impact → Application: Die-cast aluminum housing and heat- and impact-resistant glass lens enhance durability, lowering replacement intervals and maintenance costs; Application: demanding environments like chemical plants, offshore facilities, and heavy industrial sites. Feature → Business Impact → Application: 3/4" entry and yoke mounting simplify installation, adjustment, and serviceability across varied mounting configurations; Application: retrofits and new installations in restricted or hazardous spaces. Feature → Business Impact → Application: IP66 and NEMA 4X protection ensure reliable operation in water, dust, and corrosion-prone environments, supporting long service life with minimal field servicing; Application: warehouses, outdoor loading areas, and drilling or mining operations.
Get a Quick Quote for a Eaton Crouse-Hinds FMVA50LCY/UNV1 76 BZ
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds FMVA50LCY/UNV1 76 BZ?
Enquire Now
FAQs
The fixture uses a yoke mounting system with a 3/4 inch entry, simplifying alignment and installation in restricted spaces. Its rugged die-cast aluminum housing and heat-resistant lens are designed for hazardous locations, while the 100-277 VAC, 50/60 Hz input range supports multiple supply configurations. For retrofit projects, verify clearance and wiring conformity to local NEC/CEC requirements before energizing.
The FMVA50LCY/UNV1 delivers 50,000 lumens at 126 lm/W, cool white color temperature, and a dimmable driver. It operates on 100-277 VAC and 50/60 Hz, with an optical distribution of 7x6. This combination enables bright, uniform area illumination with the flexibility to optimize energy use through dimming and control strategies.
Yes. The unit is designed for Hazardous/Classified Locations with NEC/CEC standards and certified for Class I, Division 1 and Class I, Zone 2 use, among others. It carries IP66 protection and NEMA 4X enclosures, with ATEX/IECEx certification documentation supporting safe operation across global sites.
The FMVA FMVA50LCY/UNV1 supports multiple certifications, including ATEX/IECEx, UL/IEC documentation, and DLC considerations. Key data become accessible via product brochures and certification reports in the downloads, such as ATEX certificates and IECEx documentation, ensuring you can validate compliance for regional approvals.
The LED-based FMVA50LCY/UNV1 reduces maintenance intervals due to solid-state illumination and a rugged housing, lowering replacement and labor costs. Combined with dimmable operation and high luminous efficacy, the fixture lowers energy costs and supports more predictable operation through controllable lighting schedules, contributing to a favorable return on investment over traditional luminaires.
