Eaton FT1SU400CGL18IP Safety Luminaire - IP66
Part Number: FT1SU400CGL18IP
Quick Summary
The Eaton FlexiTech SU SC safety luminaire delivers reliable escape-route lighting for industrial facilities and open workspaces. When downtime or non-compliance threaten safety, this luminaire provides steady illumination, simple installation, and enduring performance. With CE certification, IP66 protection, and IK07 impact resistance, it stands up to harsh environments while delivering consistent light quality. Designed for wall or ceiling mounting with a plug-in connection and a lithium-ion battery module, it enables quick deployment and measurable uptime improvements, supporting compliant emergency lighting strategies and long-term lifecycle cost reductions.
Product Information
Extended Description
FT1SU400CGL18IP Eaton Crouse-Hinds: Eaton FlexiTech, Safety light Uniform illumination, 400lm, CGLine+, 1 to 8H,IP66
Product Name
Eaton FlexiTech SU SC safety luminaire
Catalog Number
FT1SU400CGL18IP
Product Length/Depth
231 mm
Product Height
34 mm
Product Width
86 mm
Product Weight
0.41 kg
Certifications
CE
EAN
3660191811983
Application
Other
Mounting Method
Wall surface mounted / ceiling surface mounting
Outdoor use compliance
False
Type of indicator
Not applicable
Battery quality
Lithium-ions
Connection type
Plug-in connection
Explosion protected
False
Power supply system
Peripheral (individual battery)
Protection class
II
Voltage type
AC
Wiring system
Continuous circuit/emergency circuit
Function
Escape route lighting
Kind of luminaire
Safety luminaire for escape route and open area lighting
Labelling type
Other
Light distributor
Diffuser lens/optic/panel
Luminaire With Limited Surface Temperature, Sign D
False
Mode
Maintained / Non-Maintained (M / NM)
Pictogram included
False
With remote switch connection
True
Color housing
White
Degree of protection
IP66
Impact strength
IK07
Material cover
Plastic, transparent
Material housing
Plastic
Shape
Rectangular
Color of light
White
Color rendering index (CRI)
80
Energy efficiency class
A
Energy efficiency class of the built-in lamp
A++, A+, A (LED)
Lamp holder
None
Lamp type
LED not exchangeable
Reserve-polarity protected
True
Shape
Rectangular
With light source
True
Monitoring equipment
Safety module for monitoring (central feeded system)
Testing system
CGLine +
eaton-emergency-lighting-self-contained-exit-safety-flexitech-ew-su-certificate-doc-en-fr-de
eaton-emergency-lighting-self-contained-safety-flexitech-su-small-cgl-manual-all-lang.pdf
eaton-emergency-lighting-safety-flexitech-su-small-ldt.zip
eaton-emergency-lighting-safety-flexitech-su-small-ldt.zip
The 400 lm LED light source delivers consistent, high-quality illumination with a CRI of 80, ensuring safety-critical signage and exit paths are clearly visible. This translates to quicker egress and fewer missteps in both routine and emergency situations. The IP66 ingress protection and IK07 impact resistance provide rugged reliability on busy factory floors, washdown zones, and dusty environments, reducing maintenance calls and extending service life. Maintained and non-maintained operating modes enable compliance with diverse safety codes while guaranteeing illumination during power outages. Quick installation is supported by plug-in connections and a wall/ceiling mounting design, which lowers labor costs and minimizes downtime during retrofits. The built-in peripheral lithium-ion battery backup and CGLine+ monitoring offer central fault detection and rapid issue resolution, boosting facility safety and reducing unscheduled downtime. Compatibility with safety monitoring modules and remote-switch options simplifies integration into existing safety architectures, delivering a scalable solution for growing plants and multi-site operations. Overall, this luminaire combines reliability, efficiency, and ease of service to support a strong return on investment through improved compliance, uptime, and lifecycle costs.
Get a Quick Quote for a Eaton Crouse-Hinds FT1SU400CGL18IP
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds FT1SU400CGL18IP?
Enquire Now
FAQs
FT1SU400CGL18IP supports wall surface mounting or ceiling surface mounting with a plug-in connection, enabling fast retrofits and new installs. Its compact dimensions (231 mm long, 86 mm wide, 34 mm high) fit tight spaces, while compatibility with CGLine+ monitoring allows central fault detection and streamlined maintenance planning. This combination reduces installation time and improves system reliability across sites.
Yes. The luminaire offers IP66 ingress protection and IK07 impact resistance, protecting against dust, water jets, and mechanical shocks typical in manufacturing and processing areas. It is designed for indoor use with durable plastics and corrosion-resistant components. Its maintained/non-maintained operation supports compliance for safety lighting while withstanding routine cleaning and washdown procedures.
The unit runs on AC power with a peripheral lithium-ion battery backup and uses a plug-in connection for easy field service. It provides 400 lm of light with a CRI of 80 and energy class A, suitable for escape-route lighting. It supports central monitoring via CGLine+ and integrates with safety circuits, ensuring quick fault detection and reliable operation in installed safety systems.
The luminaire carries CE certification and an EAN of 3660191811983, confirming compliance with European safety standards. Its IP66 and IK07 ratings validate rugged performance in harsh environments. While not explosion-protected, the combination of protective enclosures and robust construction supports broad adoption in industrial facilities that require reliable emergency lighting.
With 400 lm output and LED efficiency, energy use is optimized, contributing to lower operating costs. The lithium-ion battery backup and plug-in connections minimize service time during maintenance, while central CGLine+ monitoring reduces downtime by enabling rapid fault identification. The IP66/IK07-rated housing extends service life in dusty or washdown environments, delivering predictable maintenance cycles and reduced lifecycle costs.
