Eaton GHG9601955R0110 Ex-i Cable Gland - IECEx/ATEX
Part Number: GHG9601955R0110
Quick Summary
Ex-i cable gland provides sealing for hazardous locations in industrial electrical installations. For engineers facing ingress, moisture, and explosive atmosphere risks, a dependable fitting minimizes field rework and unplanned downtime. This gland carries IECEx/ATEX certification, IP68/IP66 ingress protection, and Hazardous/Classified Locations area classification, ensuring global compliance. With a polyamide body rated for -40/-55°C up to +70°C and a compact short-thread M25 x 1.5 design, it simplifies installation in cramped panels and conduit entries. The blue non-metallic construction resists chemicals, supports quick gland entry, and reduces long-term maintenance costs, while delivering consistent sealing performance across temperature ranges. Ideal for hazardous-area installations in chemical processing, oil and gas, and mining projects.
Product Information
Extended Description
GHG9601955R0110 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Ex-i cable gland, 8-10 mm cable sealing range, Blue, Polyamide, -40/-55°C up to +70°C, M25 x 1.5 Metric, Short thread
Product Name
Eaton Crouse-Hinds series Ex-i cable gland
Catalog Number
GHG9601955R0110
Product Length/Depth
37.5 mm
Product Height
29 mm
Product Width
29 mm
Product Weight
0.017 kg
EAN
4250959946911
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX
Ingress protection (IP) ratings
IP68 IP66
Type
Short thread
Thread Size
M25 x 1.5
Thread type
Metric
Material
Polyamide
Crouse-Hinds series CEAG GHG Non-metallic EX Cable Glands catalog page for North American applications
CEAG GHG Non-metallic Ex Cable Glands EU Type Examination Certificate
Crouse-Hinds series CEAG GHG Non-metallic EX Cable Glands operating instructions
Feature: The gland uses a non-metallic blue polyamide body. This construction delivers excellent chemical resistance and corrosion tolerance in challenging environments, reducing the risk of seal degradation over time. Benefit: Fewer gland failures means less unplanned downtime and lower maintenance costs in hazardous-area installations such as chemical plants and offshore facilities. Application: Use in control panels, junction boxes, and conduit entries where a reliable Ex-i seal is required. Feature: Temperature range -40/-55°C to +70°C and 8–10 mm cable sealing range with M25 x 1.5 thread. Impact: Maintains seal integrity through cold starts, thermal cycling, and hot process conditions, reducing gasket replacement and ingress risks. Application: Suitable for outdoor, refrigerated, or high-temperature process areas where consistent sealing is critical. Compatibility: Matches standard 8–10 mm cables and supports simple field retrofits. Feature: IP68 and IP66 ingress protection combined with IECEx/ATEX certification and hazardous-location area classification. Impact: Demonstrates regulatory compliance and improves overall safety posture while enabling global deployments with common install practices. Application: Use for hazardous-area equipment in chemical, oil & gas, mining, and energy sectors where robust protection matters. Feature: Short-thread M25 x 1.5 metric thread design. Impact: Enables fast, torque-consistent installation in tight spaces and on panels with limited depth, reducing installation time. Application: Ideal for enclosures and compact control panels in automation and process industries. Objection handling: The short thread reduces misalignment risk and simplifies training for maintenance teams. Feature: Precise dimensions 37.5 mm length and 29 mm width/height with weight 0.017 kg. Impact: Compact form factor supports high-density panel layouts and ease of replacement during retrofit programs. Application: Fitment in space-constrained conduits and multi-gland assemblies, aligning with standard mounting patterns in Eaton Crouse-Hinds Ex-i product family.
Get a Quick Quote for a Eaton Crouse-Hinds GHG9601955R0110
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds GHG9601955R0110?
Enquire Now
FAQs
Installation starts with selecting an 8–10 mm cable and confirming an M25 x 1.5 thread matches the enclosure. Follow Eaton Crouse-Hinds operating instructions for assembly of the Ex-i gland, seal, and entry components. Tighten to the recommended torque and verify IP66/68 integrity after assembly and cable ingress testing.
Yes. The GHG9601955R0110 Ex-i cable gland carries IECEx/ATEX certification and hazardous-location area classification, making it appropriate for chemical, oil & gas, mining, and other explosive-environment installations. Always confirm the site classification matches the gland’s certification scope and follow local regulatory requirements.
The gland uses a blue polyamide body, offering strong chemical resistance and durability. It operates across -40/-55°C to +70°C and provides IP68/IP66 protection, ensuring reliable performance in cold starts, heat, and outdoor conditions common to industrial automation.
Best-suited for control panels, junction boxes, and conduit entries in hazardous areas. It supports 8–10 mm cables with M25 x 1.5 threads, enabling robust sealing for chemical processing, offshore platforms, and mining equipment where safety and compliance are critical.
The non-metallic construction resists corrosion and chemical attack, reducing gasket and seal failures. IECEx/ATEX compliance simplifies multi-site deployments, while the compact, short-thread design speeds installation and retrofits, lowering downtime and total cost of ownership in demanding industrial environments.
