Eaton Crouse-Hinds GHG9601955R0122 Ex-i Gland IECEx/ATEX
Part Number: GHG9601955R0122
Quick Summary
Ex-i cable gland protects cable entries in hazardous locations by providing a robust seal for power and control lines. Maintenance teams struggle with seals that fail or fail to meet explosive-atmosphere standards, driving downtime and compliance risk. This model carries IECEx/ATEX certification and IP68/IP66 ratings, plus hazardous-location area classification, enabling safer, regulator-ready installations. Designed for quick installation with a long thread and M16 x 1.5 metric thread, it supports reliable sealing across -20°C to +70°C. Together with a 5.5-7 mm cable sealing range and a polyamide body, it delivers light weight, corrosion resistance, and compatibility with standard gland fittings.
Product Information
Extended Description
GHG9601955R0122 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Ex-i cable gland, 5.5-7 mm cable sealing range, Blue, Polyamide, -20°C up to +70°C, M16 x 1.5 Metric, Long thread
Product Name
Eaton Crouse-Hinds series Ex-i cable gland
Catalog Number
GHG9601955R0122
Product Length/Depth
35 mm
Product Height
20 mm
Product Width
20 mm
Product Weight
0.007 kg
EAN
4250217404092
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX
Ingress protection (IP) ratings
IP68 IP66
Type
Long thread
Thread Size
M16 x 1.5
Thread type
Metric
Material
Polyamide
Crouse-Hinds series CEAG GHG Non-metallic EX Cable Glands catalog page for North American applications
CEAG GHG Non-metallic Ex Cable Glands EU Type Examination Certificate
Crouse-Hinds series CEAG GHG Non-metallic EX Cable Glands operating instructions
Feature: Non-metallic polyamide body reduces weight and simplifies handling while offering good chemical resistance. Business impact: easier field installation, lower freight costs, and improved worker safety in confined enclosures. Application: suitable for control panels and field junctions in hazardous areas where Ex approvals are required. Feature: IP66/IP68 ingress protection provides robust dust and moisture resistance. Business impact: minimizes downtime from washdowns and harsh environments, extending enclosure life. Application: offshore platforms, chemical plants, and outdoor installations. Feature: 5.5-7 mm cable sealing range enables versatile cable compatibility. Business impact: reduces part variety and simplifies stocking. Application: instrumentation and power cables with varying diameters. Feature: M16 x 1.5 long-thread metric connection delivers secure, vibration-resistant mounting. Business impact: reduced maintenance and reliable sealing in equipment subjected to vibration. Application: standard gland mounting on enclosures in rugged environments. Feature: -20°C to +70°C operating range ensures performance across global climates. Business impact: supports global deployment and continuous operation in extreme conditions. Application: worldwide industrial facilities, including cold climates and hot processes.
Get a Quick Quote for a Eaton Crouse-Hinds GHG9601955R0122
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds GHG9601955R0122?
Enquire Now
FAQs
For installation, ensure the enclosure provides an M16 x 1.5 threaded entry and that the cable diameter falls within the 5.5-7 mm sealing range. Use appropriate sealing compound or grommet per site standards, tighten to the manufacturer’s torque guidance, and verify IP66/IP68 protection after assembly. In hazardous locations, verify IECEx/ATEX compliance for the specific zone before commissioning.
Yes, the GHG9601955R0122 is certified to IECEx/ATEX standards for hazardous locations. It is designed for hazardous/classified locations and supports safe cable entry in Zone 1/21 or equivalent zones, depending on the installation and enclosure. Always confirm the specific zone classification per your safety management system and local regulations.
The gland is configured for cables with a sealing range of 5.5-7 mm and uses an M16 x 1.5 metric thread. This makes it compatible with standard control and instrumentation cables used in hazardous-area equipment. If your cable outside this range, select an alternative gland or accessory with the appropriate diameter and thread details.
IP66 and IP68 ratings ensure high levels of ingress protection against dust and water; IP68 allows prolonged immersion under defined conditions. This makes the gland suitable for outdoor, washdown, and offshore environments where moisture ingress is a concern. In practice, this reduces maintenance frequency and helps maintain enclosure integrity during cleaning cycles.
Using the Ex-i gland can lower maintenance costs by reducing seal failures and downtime, especially in hazardous locations where regulatory compliance is critical. Benefits include safer installations, longer equipment life, lighter components for easier handling, and fewer replacements due to corrosion or moisture ingress, all contributing to a lower total cost of ownership over time.
