Eaton Crouse-Hinds GRF119 Condulet Outlet Box - NEC/CEC
Part Number: GRF119
Quick Summary
GRF119 Condulet outlet box provides tapped outlets for surface-mounted installations in ordinary locations. Engineers often struggle with integrating tapped outlets in compact panels without adding weight or corrosion risk. This GRF119 supports NEC/CEC compliance and Canadian certifications, making it suitable for ordinary locations. Copper-free aluminum construction and surface-mount capability reduce weight and simplify installation, while a 1/2" tap and 4 hubs handle wiring efficiently. With a surface-mount mounting method, installation is faster and reduces frame modifications. The unit's 6.13 in length and 4 hubs accommodate common field wiring while 1-3/8 in inside depth provides space for terminations. This combination supports compliance, reduces service costs, and aligns with design practices in industrial automation.
Product Information
Extended Description
GRF119 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Condulet GRF tapped outlet box with lugs, 1-3/8" inside depth, Copper-free aluminum, Surface mount, 4 hubs, 3 plugs, Blank back boss, 1/2"
Product Name
Eaton Crouse-Hinds series Condulet GRF tapped outlet box with lugs
Catalog Number
GRF119
Product Length/Depth
6.13 in
Product Height
4.56 in
Product Width
1.38 in
Product Weight
1.1 lb
UPC
782274989341
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Number of hubs
4
Number of plugs
3
Mounting method
Surface
Material
Copper-free aluminum
Inside depth
1-3/8"
Tap size
1/2"
Special features
Blank back boss
Crouse-Hinds series VXF and GRF catalog page
VXF and GRF Conduit Outlet Boxes Canadian certification (GRF)
VXF and GRF Conduit Outlet Boxes Canadian certification (GRF)
Eaton Specification Sheet - GRF119
Industrial Fittings Bend Radius and Cubic Capacity Chart
Copper-free aluminum construction reduces weight and extends life in harsh industrial environments where corrosion and maintenance costs are a concern. The GRF119 provides a 6.13 inch depth, a 1/2 inch tapped connection, four hubs, and three plugs, delivering ample termination space and room for future expansion. This design supports reliable field wiring while minimizing enclosure footprint in compact control panels. Surface-mount installation streamlines assembly by eliminating bulky mounting brackets, cutting on-site labor time and potential misalignment. The back boss is blank for quick customization, and the durable finish resists vibration and temperature swings common in automation environments. Four hubs and three plugs enable organized wiring schemes, while the 1/2 inch tap simplifies branch connections for control circuits. The copper-free aluminum construction also means reduced maintenance and lower lifecycle costs. The GRF119 aligns with industry practices, offering compatibility with standard conduit fittings and retrofit-ready features, which speeds procurement and installation across multi-site deployments. The result is faster project execution, lower total cost of ownership, and improved reliability in general-purpose control cabinets.
Get a Quick Quote for a Eaton Crouse-Hinds GRF119
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds GRF119?
Enquire Now
FAQs
GRF119 is designed for surface-mount installation in ordinary locations, so plan for a compact footprint with front-accessible taps. The 6.13 inch depth and 1/2 inch tap size support straightforward terminations, while four hubs and three plugs provide clean routing. Ensure the enclosure is mounted on a stable surface and verify conduit connections meet NEC/CEC requirements for non-hazardous locations.
GRF119 carries NEC/CEC standards and is suitable for Ordinary/Non-Hazardous locations. Canadian certification references are included in the product data and UL listings. When selecting for regulated environments, verify the catalog page and certification reports to confirm compliance for your specific jurisdiction and installation scenario.
The GRF119 uses copper-free aluminum construction and a 1/2 inch tapped inlet to simplify branch connections, while four hubs and three plug locations support organized wiring. This combination reduces weight, provides robust termination options, and ensures compatibility with common conduit fittings used in industrial automation panels.
GRF119 excels in general-purpose control cabinets, machine housings, conveyors, and other non-hazardous equipment enclosures. Its surface-mount design, along with four hubs and three plugs, supports scalable wiring arrangements and quick upgrades, making it a strong choice for new installations and retrofits that require NEC/CEC compliance and reliable terminations.
By reducing weight with copper-free aluminum, enabling faster surface-mount installation, and providing ample termination space, GRF119 lowers installation labor and lifecycle maintenance costs. Its compliance with NEC/CEC and non-hazardous location specs helps minimize rework for regulatory audits, delivering faster project completion and long-term reliability in automation environments.
