Eaton GRFX119 Condulet GRF Tapped Box - NEC/CEC
Part Number: GRFX119
Quick Summary
GRFX119 is a rugged Condulet GRF tapped outlet box designed for surface-mount conduit terminations in industrial control panels. Engineers often struggle to find enclosures that combine rugged durability, precise tapping, and straightforward installation in tight spaces. This GRF box carries NEC/CEC compliance and UL certifications for US and Canada, with ordinary/non-hazardous area suitability. Its feraloy iron alloy housing, 1/2 inch tap, 4 hubs, and 3 plugs deliver reliable service while reducing field wiring errors and downtime. For procurement and installation planning, its surface-mount design and 6.13 inch length simplify integration with standard conduit runs.
Product Information
Extended Description
GRFX119 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Condulet GRF tapped outlet box with lugs, 1-3/8" inside depth, Feraloy iron alloy, Surface mount, 4 hubs, 3 plugs, Blank back boss, 1/2"
Product Name
Eaton Crouse-Hinds series Condulet GRF tapped outlet box with lugs
Catalog Number
GRFX119
Product Length/Depth
6.13 in
Product Height
4.56 in
Product Width
1.38 in
Product Weight
2.9 lb
UPC
782274448602
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Number of hubs
4
Number of plugs
3
Mounting method
Surface
Material
Feraloy iron alloy
Inside depth
1-3/8"
Tap size
1/2"
Special features
Blank back boss
Crouse-Hinds series VXF and GRF catalog page
VXF and GRF Conduit Outlet Boxes UL certification (GRF)
VXF and GRF Conduit Outlet Boxes UL certification (GRF)
Eaton Specification Sheet - GRFX119
Industrial Fittings Bend Radius and Cubic Capacity Chart
Feraloy iron alloy housing delivers exceptional mechanical strength and corrosion resistance, extending service life in demanding environments and lowering maintenance costs. This rugged construction reduces the risk of enclosure damage during routine handling and near heavy equipment on the factory floor, which translates to fewer unscheduled downtime events. Inside depth of 1-3/8 in and overall length of 6.13 in provide ample space for wiring and field connections, while the four hubs and three plugs offer flexible routing and termination. The 1/2 in tap size enables common conduit fittings without adapters, simplifying configuration and reducing parts costs. The blank back boss adds wiring plan flexibility for future expansion. Surface mounting with a standard footprint speeds installation and minimizes hardware requirements, maintaining enclosure integrity. Certifications supporting NEC/CEC compliance and UL listings for US and Canada ensure audits and cross-border deployments are friction-free. This combination supports safer, faster wiring, easier maintenance, and reliable, code-compliant operation across North America.
Get a Quick Quote for a Eaton Crouse-Hinds GRFX119
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds GRFX119?
Enquire Now
FAQs
GRFX119 is designed for surface mounting on flat panels. It features four hubs and a blank back boss to simplify wiring planning, plus a 1/2 inch tap for conduit connections. Use compatible mounting hardware and ensure the panel surface provides adequate support for the 2.9 lb enclosure to maintain enclosure integrity during operation.
Key specs include 6.13 in length, 4 hubs, 3 plugs, 1/2 in tap size, inside depth of 1-3/8 in, height 4.56 in, width 1.38 in, and weight 2.9 lb. The housing is Feraloy iron alloy, with surface mounting and 4 hubs for flexible wiring routes and plug configurations.
Yes. The Condulet GRF tapped outlet box is intended for Ordinary/Non-Hazardous locations and complies with NEC/CEC standards. UL listings are available for US and Canada, supporting cross-border procurement and audits while ensuring safe, code-compliant conduit terminations.
GRFX119 is NEC/CEC compliant and UL-listed for both US and Canada. It is rated for Ordinary/Non-Hazardous locations, with UL certification documentation available for cross-border validation and quality assurance during compliance audits.
The robust Feraloy housing reduces enclosure wear and failure, lowering replacement and maintenance costs. Its flexible hub/plugs configuration and 1/2" tap simplify wiring changes, accelerating installation and reducing downtime. UL/NEC/CEC compliance also speeds approvals and minimizes risk in regulated environments.
