Eaton LR1089 Condulet Mark 9 conduit outlet body - NEMA 12
Part Number: LR1089
Quick Summary
LR1089 Condulet Mark 9 conduit outlet body is a rugged, copper-free aluminum enclosure for industrial wiring. Engineers struggle with field downtime and mounting complexity, which this model helps reduce with standard LR shape and easy wiring. It carries NEC/CEC compliance and a NEMA 12 rating, with Ordinary/Non-Hazardous locations suitability. In addition to copper-free aluminum construction, this Condulet supports reliable installation in industrial environments, aligning with long-term cost savings. Designed for 4-inch trade size and LR shape, LR1089 integrates with standard conduit fittings and installation practices. This combination delivers faster field assembly, reduced error potential, and predictable maintenance costs for panel builders and machine builders.
Product Information
Extended Description
LR1089 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Condulet Mark 9 conduit outlet body, Copper-free aluminum, LR shape, 4"
Product Name
Eaton Crouse-Hinds series Condulet Mark 9 conduit outlet body
Catalog Number
LR1089
UPC
782274530901
Product Length/Depth
16.88 in
Product Height
8.13 in
Product Width
5.94 in
Product Weight
8 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
12
Shape
LR
Trade size
4"
Material
Copper-free aluminum
Crouse-Hinds series Form 8 and Mark 9 catalog page
Condulet Mark 9 Conduit Outlet Bodies UL certification
Condulet Mark 9 Conduit Outlet Bodies UL certification
IF 964 - Conduit Body Wire Pulling
IF 964 - Conduit Body Wire Pulling
Eaton Specification Sheet - LR1089
Industrial Fittings Bend Radius and Cubic Capacity Chart
Industrial Fittings Bend Radius and Cubic Capacity Chart
Copper-free aluminum construction provides inherent corrosion resistance and a lighter net weight compared with traditional aluminum alloys, improving handling during install and reducing shipping costs. The business impact is clear: longer service life in harsh environments, fewer field call-backs, and lower total cost of ownership. This is particularly beneficial for outdoor installations, damp facilities, or washdown areas where ferrous components risk rust and galvanic corrosion, ensuring reliable conduit connections in demanding applications. LR shape and 4-inch trade size streamline installation by aligning with standard conduit fittings and pre-wired configurations. Engineers report faster panel mounting, fewer misfits, and lower labor hours on site. Applications include machine controls, process equipment, and electrical enclosures where form 8 and Mark 9 configurations are common, enabling seamless integration with existing Eaton Crouse-Hinds accessories and catalog pages. NEMA 12 rating and NEC/CEC compliance provide robust protection in Ordinary/Non-Hazardous Locations, supporting compliance audits and safe operation. The design minimizes ingress of dust and light liquids while maintaining serviceability. This translates to lower risk during commissioning and a reduced need for retrofit work in standard industrial environments. With a length of 16.88 in, height of 8.13 in, width 5.94 in, and a weight of 8 lb, LR1089 fits tight spaces without compromising strength. The compact form reduces enclosure footprint and simplifies storage orders for large projects. Installation benefits include clear wiring access and compatibility with IF 964 instruction sheets for wire pulling, helping technicians complete runs quickly and correctly. UL certification for Condulet Mark 9 components confirms safety and reliability across US and Canada markets, while the catalog pages and datasheets offer quick reference for qualification tests. The availability of installation instructions and data sheets, including the Eaton specification sheet LR1089, supports field engineers in validating performance and maintaining consistent quality across projects.
