Eaton ML4F4WC120F Cordset - IP68, 4-Pole, 12 ft
Part Number: ML4F4WC120F
Quick Summary
The ML4F4WC120F cordset from Eaton Crouse-Hinds provides robust power connectivity for industrial automation and machinery. It helps engineers avoid field-fitting delays by offering a ready-to-install, durable solution for reliable control panel and machine connections. This LynxPOWER Mini-Line cordset is designed for ordinary/non-hazardous locations with IP68 sealing and a zinc housing, supporting IEC NEC/CEC compliance and versatile NEMA ratings. With a 12 ft STOOW cable and #16 AWG conductors, it delivers consistent performance while reducing installation time and lifecycle costs. In short, this cordset combines rugged reliability with straightforward integration for enhanced uptime and predictable maintenance planning.
Product Information
Extended Description
ML4F4WC120F Eaton Crouse-Hinds: Eaton Crouse-Hinds series LynxPOWER Mini-Line cordset, 10A, STOOW cable, #16 AWG, Female, 90° plug, internal thread, pigtail, Passive, Zinc, Four-pole, Style I, 12 ft cable length
Product Name
Eaton Crouse-Hinds series LynxPOWER Mini-Line cordset
Catalog Number
ML4F4WC120F
UPC
662275943767
Product Length/Depth
1.62 in
Product Height
1.16 in
Product Width
1 in
Product Weight
1 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
IEC NEC/CEC
NEMA Rating
3 4 13 1 6P
Ingress protection (IP) ratings
IP68
Connector type
Passive
Number Of Poles
Four-pole
Style
Style I
Configuration
Female, 90° plug, internal thread, pigtail
Gender
Female
Cable type
STOOW
Cable/wire size
#16 AWG
Cable length
12 ft
Amperage Rating
10 A
Material
Zinc
LynxPower industrial connectivity solutions
Mini-Line and Micro-Mini Cordsets, Receptacles and Multi-port Boxes catalog page
Eaton Specification Sheet - ML4F4WC120F
Feature: 12 ft STOOW cable with #16 AWG conductors. Business impact: provides flexible routing and ample current capacity for typical automation runs, reducing the need for extensions or splices. Application: robotics cells and small-to-medium control panels in factory floors. Feature: Four-pole, Style I, passive connector with 90° plug and internal thread. Business impact: simplifies wiring, minimizes misconnection risk, and improves vibration resistance in dynamic equipment. Application: panel-mounted connections and equipment interlocks in packaging lines. Feature: IP68 ingress protection and zinc housing. Business impact: withstands washdowns and harsh environments, lowering maintenance cycles and replacement costs. Application: food and beverage processing lines and outdoor machinery. Feature: 12 ft length with pigtail configuration. Business impact: allows easy reach between connectors without excess slack, saving material and labor during install. Application: compact automation enclosures and remote devices. Feature: IEC NEC/CEC standards and NEMA ratings (3, 4, 13, 1, 6P). Business impact: ensures cross-region compliance and simplifies procurement with certified performance. Application: multi-site manufacturing and service operations requiring consistent electrical safety. Feature: Cable/wire size #16 AWG and 10 A rating. Business impact: supports standard industrial loads with reliable current carrying capacity, reducing overdesign. Application: control circuits and auxiliary power feeds in machinery. Feature: Passive connector type. Business impact: lowers maintenance complexity and avoids active components that require monitoring; easier field replacement. Application: legacy and new LynxPOWER installations where quick swaps are needed.
Get a Quick Quote for a Eaton Crouse-Hinds ML4F4WC120F
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds ML4F4WC120F?
Enquire Now
FAQs
To install, align the four-pole connector, secure the 90° plug into the panel inlet, and tighten the internal thread to ensure a watertight seal. Use appropriate strain relief and route the 12 ft STOOW cable to avoid excessive bending. Verify IP68 seals and confirm correct polarity before energizing.
The cordset supports IEC NEC/CEC standards, IP68 ingress protection, and NEMA ratings 3, 4, 13, 1, and 6P. It is intended for Ordinary/Non-Hazardous Locations, providing broad regulatory compatibility for multi-site manufacturing.
Yes. IP68 protection and a zinc housing make it well-suited for washdown and harsh environments typical in industrial facilities, helping to minimize ingress-related downtime and maintenance.
LynxPOWER Mini-Line provides a compact, four-pole passive connection with a 12 ft cable and #16 AWG conductors, featuring a 90° plug and internal thread for secure panel mounting. This enables quicker field installs, easier replacements, and consistent cross-series compatibility with LynxPOWER components.
The durable zinc housing, IP68 protection, and simple, passive design reduce downtime and spare-parts needs. The 12 ft length minimizes field splicing, while compliant certifications simplify audits and cross-site deployment, delivering lower total cost of ownership over the equipment lifecycle.
