Eaton Crouse-Hinds N2S2123U Selector Switch - IP66
Part Number: N2S2123U
Quick Summary
N2S2123U selector switch control station from Eaton Crouse-Hinds enables reliable control and isolation in hazardous industrial environments. Operators often struggle with devices that fail in demanding locations or require costly maintenance, leading to unplanned downtime. This solution is NEC/CEC compliant with hazardous-location ratings including Class I Zone 1 and 2, Class II Division 2, IP66 protection, and rugged NEMA 3/4X/7/12 enclosures. With a high-impact polyester body and a compact 3/4" trade size, it simplifies installation in automation panels while delivering long service life. In practice, installers and integrators benefit from safer start-up sequences, easier maintenance, and improved panel reliability in motor control centers and process lines.
Product Information
Extended Description
N2S2123U Eaton Crouse-Hinds: Eaton Crouse-Hinds series N2SU selector switch control station, With selector switch, High impact polyester, Three position, two circuit, Dead end, 3/4", 600 VAC
Product Name
Eaton Crouse-Hinds series N2SU selector switch control station
Catalog Number
N2S2123U
UPC
782274139562
Product Length/Depth
3.94 in
Product Height
6.3 in
Product Width
3.54 in
Product Weight
2.13 lb
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Zone 1 Class I, Division 2 Class I, Zone 2 Class II, Division 2
NEMA Rating
3 4X 7 12
Ingress protection (IP) ratings
IP66
Enclosure type
With selector switch
Normal position
Three position, two circuit
Style
Dead end
Trade size
3/4"
Material
High impact polyester
Voltage rating
600 Vac
N2SU and N2SCU Series Non-metallic Control Stations catalog page
N2SU and N2SCU Non-metallic Industrial Control Stations Canadian certification
N2SU and N2SCU Non-metallic Industrial Control Stations Canadian certification
IF 703 - N2S and N2SU Control Stations
Eaton Specification Sheet - N2S2123U
Feature: Three-position, two-circuit selector switch with dead-end style in a 3/4" trade size. Business Impact: Reduces operator error by providing clearly defined positions, lowering misoperation risk and enabling repeatable start/stop actions. Application: Hazardous-location control stations in automation panels and motor control centers. Feature: High-impact polyester enclosure with IP66 rating. Business Impact: Delivers rugged, corrosion-resistant performance in washdown, dusty, and moisture-prone environments, reducing replacement cycles. Application: Chemical plants, water treatment, and oil/gas facilities. Feature: 600 VAC voltage rating and standard compatibility with control circuits up to high voltage. Business Impact: Enables safe integration into existing 600V control schemas, minimizing wiring changes and surge concerns. Application: Conveyor systems, pumps, and large-motor controls. Feature: NEC/CEC standards compliance and hazardous-location ratings (Class I Zone 1/Zone 2, Class II Division 2). Business Impact: Streamlines regulatory approvals and minimizes certification delays. Application: Plants operating under strict industrial codes. Feature: NEMA 3/4X/7/12 enclosure compatibility and IP66 protection. Business Impact: Ensures reliable operation in harsh industrial environments, lowering maintenance costs. Application: Enclosures exposed to dust, water, and harsh chemicals. Feature: Durable, non-metallic construction with a proven control-station form factor. Business Impact: Lighter weight, easier handling, and faster installation without sacrificing reliability. Application: Panel builders seeking quick-install solutions for hazardous-locations projects.
Get a Quick Quote for a Eaton Crouse-Hinds N2S2123U
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds N2S2123U?
Enquire Now
FAQs
Installers should verify NEC/CEC compliance for the specific area and ensure the enclosure is sealed to IP66 standards. The unit’s 3/4" trade size supports standard conduit connections, and its dead-end, three-position, two-circuit configuration minimizes misoperation. Use appropriate gland fittings and sealants to maintain hazardous-location integrity.
N2S2123U operates as a three-position, two-circuit selector switch with a 600 VAC rating. It uses a high-impact polyester enclosure and a 3/4" trade size, designed for dry and washdown environments while maintaining reliable actuation and defined normal positions in hazardous locations.
Yes. The N2S2123U is NEC/CEC compliant and rated for hazardous locations, including Class I Zone 1/Zone 2, and Class II Division 2, providing safe operation in challenging plants while meeting regulatory requirements.
The device carries NEC/CEC standards, hazardous-location ratings, and NEMA protection up to 4X, along with IP66 ingress protection. These certifications support regulatory compliance and reliable performance in dust, moisture, and chemical exposure typical of process and automation environments.
The non-metallic, high-impact polyester body resists corrosion and withstands harsh environments, reducing replacement frequency. Its clear three-position operation and robust enclosure simplify troubleshooting and maintenance, while IP66 and NEMA ratings minimize field protection concerns, lowering downtime and maintenance costs in control panels.
