Eaton Crouse-Hinds PFMA40LCY/UNV34 76 M25 LED Floodlight - IP66

Part Number: PFMA40LCY/UNV34 76 M25
PFMA40LCY/UNV34 76 M25
Manufacturer
Eaton Crouse-Hinds
Part number
PFMA40LCY/UNV34 76 M25
Category

Quick Summary

PFMA40LCY/UNV34 76 M25 LED floodlight is a high-output luminaire engineered for rugged outdoor and industrial sites. It addresses common downtime and glare issues by delivering reliable, uniform illumination even in challenging environments. The unit carries NEC/CEC compliance, IP66 ingress protection, and NEMA 4X enclosure, supporting safe operation in harsh locations. With a dimmable driver and a lumen package of 40,000 at 119 lm/W, it drives energy efficiency and predictable maintenance planning. The 347–480 Vac rating and 50/60 Hz compatibility simplify integration with existing power distribution, while the heavy-duty die-cast aluminum housing ensures durability. This makes it a strategic fit for outdoor yards, loading docks, and long-throw indoor areas where uptime matters.

Product Information

Extended Description

PFMA40LCY/UNV34 76 M25 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Champ Pro PFMA LED floodlight, 1.24A, Cool white, Dimmable driver, 25mm entries, 1500W+ equiv, Heat and impact resistant glass lens, 40000 lm, 119 lm/W, Die cast alum, 7x6 optics, Gray paint, 347-480 Vac, 340W
Product Name
Eaton Crouse-Hinds series Champ Pro PFMA LED floodlight
Catalog Number
PFMA40LCY/UNV34 76 M25
UPC
662276661547
Product Length/Depth
15.35 in
Product Height
24 in
Product Width
17.28 in
Product Weight
77 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Lamp type
LED
Lumens
40000
Lumens per watt
119
Color temperature
Cool white
Mounting Method
Yoke
Voltage rating
347-480 Vac
Frequency rating
50/60 Hz
Optical distribution
7x6
Entry size
25 mm
Lens material
Heat and impact resistant glass
Finish color
Gray
Wattage
340 W
Dimming
Dimmable driver
Equivalent luminaire
1500W+
Power factor
> 0.90
Amperage Rating
1.24 A
Material
Die cast aluminum
SP3D Design Package - Champ Pro PFMA LED Industrial Floodlights Crouse-Hinds series industrial LED lighting solutions Crouse-Hinds series industrial LED lighting solutions Crouse-Hinds series industrial LED lighting solutions Crouse-Hinds series industrial LED lighting solutions Crouse-Hinds series Champ PFMA LED Floodlights - 20,000 to 50,000 lumens catalog page Champ PFMA LED Floodlights ABS certification Champ PFMA LED Floodlights ABS certification Champ PFMA LED Floodlights ABS certification IF 1847 - Champ PFMA40L/50L LED Floodlights IF 1847 - Champ PFMA40L/50L LED Floodlights Eaton Specification Sheet - PFMA40LCY/UNV34 76 M25
High-output LED engine delivers 40,000 lumens at 119 lm/W, enabling fewer fixtures to cover large areas and reduce installed cost. This also lowers ongoing maintenance needs in demanding outdoor and industrial environments. A dimmable driver provides precise light control, supporting energy management strategies and compatibility with occupancy or daylight-harvesting controls for further cost savings. The fixture operates on 347–480 VAC at 50/60 Hz, simplifying system integration and reducing the need for transformers or power conditioning. IP66 ingress protection and a NEMA 4X enclosure, combined with heat- and impact-resistant glass, deliver rugged reliability in washdowns, vibration, and harsh weather, minimizing downtime and replacement cycles. The 7x6 optical distribution and yoke mounting enable flexible installation and uniform coverage across yards, ramps, and outdoor workspaces while the die-cast aluminum housing and gray finish resist corrosion and wear in tough environments.

Get a Quick Quote for a Eaton Crouse-Hinds PFMA40LCY/UNV34 76 M25

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton Crouse-Hinds PFMA40LCY/UNV34 76 M25? Enquire Now

FAQs

The PFMA40LCY/UNV34 supports yoke mounting and 25 mm entries, with a 347-480 VAC supply and 50/60 Hz. Install in an IP66-rated location using appropriate weatherproof junction boxes and connect in accordance with NEC/CEC guidelines. Use dimmable control where feasible to maximize energy savings without compromising illumination quality.
Key specs include 40,000 lumens at 119 lm/W, 340 W, 347-480 VAC, 50/60 Hz, IP66 ingress protection, and NEMA 4X enclosure. It features a heat and impact resistant glass lens, a 7x6 optical distribution, and a dimmable driver to support modern control schemes.
Yes. This luminaire is rated for Ordinary/Non-Hazardous Locations per NEC/CEC standards and offers robust protection (IP66, NEMA 4X) for outdoor and semi-indoors in industrial facilities, warehouses, and yards.
The PFMA40LCY/UNV34 carries NEC/CEC compliance, IP66 ingress protection, and a NEMA 4X enclosure. It has ABS and UL-related certification references in manufacturer literature, supporting compliance in multiple regions and marine applications as indicated by certification reports.
The dimmable driver reduces energy use when integrated with controls, while the durable die-cast aluminum housing and heat/impact resistant lens lower replacement and maintenance costs. The high lumen output enables fewer fixtures for the same area, shortening installation time and lowering total cost of ownership.
