Eaton 12004-RTO-ER08-001 Side Marker - IP66 / NEMA 4X
Part Number: 12004-RTO-ER08-001
Quick Summary
Eaton 12004-RTO-ER08-001 Side Marker provides reliable obstruction lighting for industrial facilities. Facilities teams often struggle with maintaining visibility and compliance in harsh environments. This unit meets IP66 and NEMA 4X ratings with Class I, Division 2 hazardous-location approval, plus NEC/CEC standards and CE compliance for global installations. With 1.5 W at 24–48 Vdc and surge protection, it reduces running costs while boosting uptime. Designed as a single, rugged fixture with copper-free aluminum housing and a polycarbonate globe, it withstands tough conditions. Weighing about 2 lb, it installs quickly on standard mounting hardware, shortening commissioning time and improving maintenance efficiency. This aligns with reliability objectives and support contracts common in industrial operations.
Product Information
Extended Description
12004-RTO-ER08-001 Eaton: Eaton Crouse-Hinds series side marker, Threaded 1" and 3/4" bottom hub, Polycarbonate globe and lens, LED, Red, Copper-free aluminum, Surge protection, Single fixture, low intensity, 24-48 Vdc, 1.5W
Product Name
Eaton Crouse-Hinds series Side marker
Catalog Number
12004-RTO-ER08-001
UPC
786689904357
Product Length/Depth
5 in
Product Height
5.93 in
Product Width
5 in
Product Weight
2 lb
Compliances
FAA Transport Canada DGAC Mexico ICAO CE
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Lamp type
LED
Type
Single fixture, low intensity
Wattage
1.5W
Voltage rating
24-48 Vdc
Entry size
Threaded 1" and 3/4" bottom hub
Entry type
Bottom
Material
Copper-free aluminum
Globe material
Polycarbonate
Lens material
Polycarbonate
Lens color
Red
Special features
Surge protection
Low-power LED operation at 1.5 W is a defining feature, delivering energy-efficient illumination without sacrificing visibility. This minimal draw reduces energy costs, lowers heat load on power supplies, and extends component life in remote or battery-connected systems. Application-wise, it excels for obstruction lighting on industrial facilities, cranes, and runway approaches where continuous visibility is critical and power budgets are constrained. Robust enclosure protection combines IP66 ingress protection with a NEMA 4X-rated housing. This combination minimizes corrosion and water ingress, lowering maintenance cycles in harsh environments. It is particularly well-suited for outdoor installations on offshore platforms, chemical plants, and outdoor substations where weather and chemical exposure can otherwise shorten service intervals. Copper-free aluminum housing paired with a polycarbonate globe and lens delivers durable exterior performance. The corrosion resistance helps reduce replacement costs in coastal and aggressive industrial settings, while impact resistance protects against incidental knocks in busy facilities. This construction supports long service life in environments that demand rugged, maintenance-friendly lighting. Threaded 1" and 3/4" bottom hub entry and bottom-entry design simplify mounting. The compatibility with common hubs accelerates retrofits and aligns with existing mounting infrastructure, cutting commissioning time. This is especially valuable in retrofit projects where downtime is costly and install crews benefit from standardized hardware. Integrated surge protection guards the LED against transient electrical events, preserving lumen output and protecting control circuitry. Paired with 24–48 Vdc operation, this feature reduces risk to adjacent equipment and extends system life. It is advantageous in facilities with variable power quality, including processing plants and heavy industry. Compliance and certifications cover NEC/CEC standards, Class I, Division 2 hazardous locations, IP66, NEMA 4X, and CE. This combination supports global deployments, simplifies procurement, and minimizes onboarding risk for multinational projects. Operators gain assurance that the marker meets safety and environmental requirements while delivering consistent performance.
Get a Quick Quote for a Eaton 12004-RTO-ER08-001
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 12004-RTO-ER08-001?
Enquire Now
FAQs
The side marker uses a threaded bottom hub compatible with 1" and 3/4" entries, allowing direct mounting on common poles and brackets. This bottom-entry design simplifies wiring runs, minimizes retrofit complexity, and supports quick alignment with nearby lighting fixtures in industrial sites.
Yes. The device carries Class I, Division 2 hazardous-location approval, along with IP66 and NEMA 4X ratings. It also complies with NEC/CEC standards and CE marking, enabling safe installation in global facilities that demand rigorous safety and environmental compliance.
The marker operates from 24 to 48 Vdc and draws 1.5 W of power. It includes surge protection to guard against transients, helping to extend LED life and protect downstream electronics in facilities with variable power quality.
It's designed for outdoor, harsh environments such as offshore platforms, chemical plants, outdoor substations, and other industrial sites where dust, moisture, and corrosive exposure are concerns, delivering reliable visibility with minimal maintenance.
Energy efficiency (1.5 W), long LED life, and rugged construction reduce running costs and maintenance frequency. The IP66/NEMA 4X enclosure and Class I, Division 2 rating minimize replacement cycles, while easy mounting speeds up commissioning and retrofit projects, delivering measurable uptime and lifecycle cost savings.
