Eaton 1313MV2AI38FGMW MV AutoVAR cap bank - IEEE Std. 18
Part Number: 1313MV2AI38FGMW
Quick Summary
Eaton MV AutoVAR capacitor bank is a high-voltage reactive power solution designed for 13.8 kV networks. This product provides reliable VAR support to stabilize voltage, improve power factor, and reduce utility penalties across feeders. This unit complies with IEEE Std. 18 and CSA certification (Canada) to support regulatory alignment and safety. As a scalable solution, it reduces downtime and energy costs while maintaining seamless compatibility with Eaton MV systems and current standards. Operators gain predictable performance with a 15 kVAR class rating and 60 Hz operation, ensuring robust power factor correction. With a compact footprint, a 4.2H detuned filter, and a 13.8 kV rating, it integrates smoothly into existing MV switchgear.
Product Information
Extended Description
1313MV2AI38FGMW Eaton: Eaton MV AutoVAR 15kV Class Standard Design capacitor bank, 1313KVAR, 13800V, 60HZ, 4.2H DETUNED FILTER
Product Name
Eaton MV AutoVAR filtered capacitor bank
Catalog Number
1313MV2AI38FGMW
UPC
786689241735
Product Length/Depth
106 in
Product Height
99 in
Product Width
65 in
Product Weight
10000 lb
Certifications
IEEE Std. 18 CSA Certified (Canada Only)
Frequency rating
60 Hz
kVA rating
1313 kVAR
Voltage rating
13800 V
The Eaton MV AutoVAR filtered capacitor bank delivers high‑voltage reactive power support for 13.8 kV networks. This translates to improved power factor, reduced utility penalties, and more stable voltage profiles across feeders. Ideal for substations and industrial facilities with heavy motor loads, it enables precise VAR management at scale. With a 1313 kVAR rating and 13.8 kV operation, it provides substantial reactive power capacity to meet peak demand. The result is lower transformer loading, better voltage regulation, and improved energy efficiency for manufacturing lines. This is particularly beneficial for facilities running large pumps, fans, or rolling mill motors. A 4.2H detuned filter helps suppress harmonic interaction with nearby equipment. That improves system reliability, reduces capacitor stress, and minimizes resonance risk in HV switchgear. Operators appreciate less maintenance downtime and longer capacitor bank life. IEEE Std. 18 compliance and CSA certification (Canada) support procurement and regulatory adherence. These certifications simplify regulatory audits and supplier qualification for multinational projects. Sites targeting North American markets gain confidence in safety and interoperability with Eaton MV solutions. The unit ships with a robust footprint—106 in long, 99 in high, and 65 in wide, weighing around 10,000 lb. Its modular enclosure and wiring access are designed for straightforward installation alongside existing MV equipment. Compatibility with Eaton MV systems supports faster commissioning and reduced project risk. Engineered for reliability in demanding HV environments, it reduces maintenance intervals and extends lifetime. Access to spare parts and service expertise from Eaton helps keep downtime minimal.
Get a Quick Quote for a Eaton 1313MV2AI38FGMW
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 1313MV2AI38FGMW?
Enquire Now
FAQs
Yes. The 1313MV2AI38FGMW is designed for 13.8 kV distributed networks and works within Eaton’s MV ecosystem. Consider clearances for an 106 in × 99 in × 65 in footprint and a 10,000 lb weight, plus proper electrical clearances for wiring access. Ensure switchgear compatibility and appropriate protective relays are in place to support seamless commissioning and safe operation.
Key specs include a 1313 kVAR reactive power rating, 13,800 V voltage rating, and 60 Hz frequency. The unit also employs a 4.2 Henry detuned filter to mitigate harmonics, and it complies with IEEE Std. 18 with CSA certification for Canada. These specs enable robust VAR management, improved PF, and reliable performance in HV environments.
Yes. The 13.8 kV rating and 60 Hz operation make it suitable for heavy industrial sites and substations feeding motors, pumps, and HVAC loads. The 1313 kVAR capacity provides substantial reactive support, while the detuned filter reduces resonance risk with nearby equipment. Proper installation alongside existing MV gear ensures safe, reliable operation under peak demand.
This unit carries IEEE Std. 18 compliance and CSA certification for Canada, supporting regulatory audits and supplier qualification. These certifications confirm safety, reliability, and interoperability with North American MV systems, helping procurement teams meet corporate and regulatory standards across multi-site projects.
ROI is driven by improved power factor, reduced utility penalties, and lower transformer loading, which translates to energy savings and deferred equipment upgrades. Maintenance is typically infrequent thanks to a robust detuned filter and rugged HV construction; Eaton provides service support and spare parts to minimize downtime and extend the unit’s lifetime.
