Eaton 1A33594G01 DS/DSII spring release - UL Listed
Part Number: 1A33594G01
Quick Summary
Eaton DS/DSII spring release provides fast, reliable actuation for modular control panels. In harsh industrial environments, stalled or slow trips disrupt production and raise downtime costs. UL Listed safety certification underpins reliable protection performance in critical systems. Designed for a universal frame and compatible with DS and DSII series devices, it simplifies installation and maintenance. By pairing compact form with industry-standard voltages of 24 to 48 Vdc, it supports efficient, cost-effective panel design. Operators benefit from predictable actuation timing and reduced risk during maintenance shutdowns. Engineers value compatibility with universal framing and standard accessories for quick scaling across facilities. This combination supports safer, more reliable panel operation, reducing total cost of ownership over the device lifecycle.
Product Information
Extended Description
1A33594G01 Eaton: Eaton DS/DSII spring release, 24-48 Vdc, 50/60 Hz, Universal frame
Product Name
Eaton DS/DSII spring release
Catalog Number
1A33594G01
UPC
786670640509
Product Length/Depth
4 in
Product Height
2 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
UL Listed
Frame
Universal
Accessories
Spring release
Series
DS DSII
Frequency rating
50 to 60 Hz
Universal frame compatibility streamlines procurement and installation. With a universal frame designed to fit the DS and DSII series, the release reduces engineering time, minimizes fit issues, and lowers spare-parts costs. In industrial machinery, that translates to faster panel builds and easier lifecycle management. The spring release mechanism enhances safety during maintenance by ensuring predictable manual operation and rapid re-engagement, minimizing downtime and risk during resets. For reliability, the actuator delivers consistent latch and release performance across load conditions, supporting uptime and regulatory compliance in mission-critical panels. Electrical compatibility with 24–48 Vdc and 50–60 Hz control voltages simplifies integration into existing automation architectures, reducing adapter needs and accelerating project timelines. Compact dimensions and light weight enable space-saving installations in dense control cabinets, while standard accessories facilitate fast field upgrades across multiple sites. The 1-year warranty and included spring release contribute to a lower total cost of ownership by reducing maintenance intervals and replacement spend in long-term operations.
Get a Quick Quote for a Eaton 1A33594G01
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 1A33594G01?
Enquire Now
FAQs
Install the 1A33594G01 spring release into a DS/DSII universal frame per Eaton's mounting guidelines. Ensure alignment with the frame, attach the actuator to the provided mounting points, and verify the spring release engages the circuit breaker actuator correctly. Verify electrical connections are secure and perform a functional check with the panel powered down to confirm safe operation.
The 1A33594G01 operates with 24 to 48 Vdc input and supports a 50/60 Hz frequency rating. This range aligns with common control voltages in industrial automation, allowing straightforward integration with standard automation controllers and protective relays without additional adapters or power supplies.
Yes. The 1A33594G01 is designed for universal frame compatibility within the DS and DSII family, enabling seamless retrofits and upgrades across existing panels. This compatibility minimizes modification work and helps ensure consistent actuation behavior across the series.
This spring release is UL Listed, providing recognized safety certification for electrical components in industrial systems. UL Listing supports compliance with safety standards, helps reduce risk for electrical installations, and can simplify customer qualification and procurement workflows in regulated environments.
The Eaton 1A33594G01 includes a 1-year warranty. Maintenance is typically minimal but should include periodic inspection of mounting integrity, actuator alignment, and spring release function. Replacing worn components promptly, using original accessories, and following Eaton’s installation and service guidance helps maintain reliable operation and lowers lifecycle costs.
