Eaton undervoltage release 1A33595G01 - UL Listed
Part Number: 1A33595G01
Quick Summary
Eaton DS/DSII undervoltage release protects motor circuits by initiating a controlled trip during undervoltage conditions in control systems. End users often face nuisance trips or missed releases due to unstable power, risking equipment damage and downtime. UL Listed safety certification plus universal DS frame compatibility help you meet strict safety standards and simplify panel design. With a 1-year warranty and clear Eaton datasheet guidance, this release reduces spares inventory while speeding commissioning. Designed for 120 Vac/dc operation, it supports DS/DSII universal frames, enabling plug-and-play integration with Eaton motor starters. This combination delivers faster commissioning, predictable trip behavior, and improved uptime across conveyors, pumps, and process lines.
Product Information
Extended Description
1A33595G01 Eaton: Eaton DS/DSII undervoltage release, DS/DSII, Universal, 120 Vac/dc, 1A33595G01
Product Name
Eaton DS/DSII undervoltage release
Catalog Number
1A33595G01
UPC
782114884843
Product Length/Depth
11.1 in
Product Height
4.5 in
Product Width
6.3 in
Product Weight
1.95 lb
Warranty
1 year
Certifications
UL Listed
Frame
Universal
Accessories
Undervoltage release
Series
DS DSII
Feature: Universal DS frame compatibility → Business Impact: Reduces spare parts and simplifies inventory management, enabling faster panel builds in automation projects. Application: Works across DS and DSII contactors, streamlining OEMs' stocking strategies and field repairs. Feature: 120 Vac/dc operation → Business Impact: Supports both AC and DC control circuits, expanding installation flexibility and improving control reliability in mixed-energy systems. Application: Suitable for conveyors, pumps, and process machinery in industrial environments. Feature: Compact dimensions and weight → Business Impact: Easier mounting in crowded panels, lower installation labor, and reduced enclosure footprint. Application: Ideal for retrofit projects and space-constrained control cabinets. Feature: Warranty and Certifications → Business Impact: Risk mitigation with a 1-year warranty and UL Listed compliance enhances safety assurances and customer confidence. Application: Applicable across food, packaging, and material handling lines seeking consistent safety standards. Feature: Documentation and downloads → Business Impact: Accelerates engineering and commissioning through official datasheets and media. Application: Reference Eaton Specification Sheet 1A33595G01 and circuit breakers explained video for quick onboarding.
Get a Quick Quote for a Eaton 1A33595G01
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 1A33595G01?
Enquire Now
FAQs
Installation follows standard Eaton DS/DSII guidelines. Mount the unit in the universal frame, connect control wiring per the 1A33595G01 datasheet, and verify correct coil voltage (120 Vac/dc). Use proper torque on terminal screws and check clearances to avoid heat buildup.
The product operates at 120 Vac/dc and is designed for DS/DSII universal frames. Catalog number is 1A33595G01 with UL Listed safety certification. Refer to the Eaton specification sheet for detailed current ratings, timing, and contact configurations.
The DS/DSII undervoltage release is built for industrial panel use, with a robust frame allowing reliable operation in typical factory vibration. Review the installation guidelines and ensure secure mounting within the universal frame to optimize performance and minimize nuisance trips.
By triggering controlled trips during undervoltage events, the release minimizes unplanned outages, protects downstream equipment, and reduces wear from voltage fluctuations. Compatibility with DS/DSII frames simplifies maintenance and spare-part planning, lowering total cost of ownership over the system life.
Official resources include the Eaton Specification Sheet for 1A33595G01 and the 'Circuit Breakers Explained' video in the downloads. These documents provide wiring diagrams, installation steps, safety notes, and performance data to accelerate engineering and ensure compliant panel builds.
