Eaton 315C364G04 MCCB Switchboard Mount - MIL-DTL-17361
Part Number: 315C364G04
Quick Summary
Eaton Navy & Marine molded case circuit breaker switchboard mount protects shipboard electrical panels with a three-pole, 100 A rating. Engineers frequently face mounting compatibility challenges and strict regulatory requirements in compact naval installations. This unit complies with MIL-DTL-17361 and carries Naval class designation, with NSN support for streamlined logistics. Designed for rear-line, front-load service on a single-pole imperial mounting base, it offers straightforward installation and reliable field replacement. Used with AQB-A101/A103 and NQB-A101/A103 breakers, it helps optimize spare-part inventories while delivering dependable overcurrent protection in harsh marine environments.
Product Information
Extended Description
315C364G04 Eaton: Eaton Navy and Marine molded case circuit breaker switchboard mount, Three-pole, 100A, 500 V, 250 Vdc, Line and load, Single-pole imperial mounting base, Naval, Rear, Front, used with Used with AQB-A101/A103 and NQB-A101/A103 breakers
Product Name
Eaton Navy & Marine molded case circuit breaker switchboard mount
Catalog Number
315C364G04
UPC
786679716564
Product Length/Depth
8.2 in
Product Height
3.2 in
Product Width
4.4 in
Product Weight
3 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
MIL-DTL-17361
Catalog Notes
NSN 5925-01-124-0156, best to use 315C364G07
Used with
Used with AQB-A101/A103 and NQB-A101/A103 breakers
Type
Single base
Amperage Rating
100 A
Voltage rating
500 Vac, 250 Vdc
Terminals
Line and load
Class
Naval
Line
Rear
Mounting hardware
Single-pole imperial mounting base
Prod load
Front
Number of poles
Three-pole
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Eaton Specification Sheet - 315C364G04
Three-pole design and a 100 A rating deliver robust protection for distribution panels, reducing nuisance trips and improving overall system reliability in demanding marine environments. Its 500 Vac and 250 Vdc voltage ratings ensure compatibility with mixed naval power architectures, while line and load terminals simplify wiring and reduce installation time. The rear line, front product load configuration supports efficient panel layouts, and the single-pole imperial mounting base provides straightforward, secure mounting in standard switchboards. Compatibility with AQB-A101/A103 and NQB-A101/A103 breakers streamlines spares management and upgrade paths across existing fleets. MIL-DTL-17361 compliance and Naval class designation underpin regulatory confidence and long-term durability, crucial for life-cycle cost optimization. NSN support (5925-01-124-0156) enhances logistics and procurement efficiency for naval programs.
