Eaton 37MM240R124095 Commercial Meter Stack - UL Listed
Part Number: 37MM240R124095
Quick Summary
Eaton commercial meter stack is a compact, integrated metering and distribution solution designed for 208Y/120V three‑phase systems. Facility teams often contend with cramped spaces, complex wiring, and downtime during service changes, which can drive project delays and increased labor costs. UL Listed certification provides safety validation for commercial installations, while the design supports fast maintenance and modular expansion. This model also aligns with low voltage distribution strategies, helping procurement leaders simplify specifications and reduce total cost of ownership while enabling scalable metering for growing facilities.
Product Information
Extended Description
37MM240R124095 Eaton: Eaton commercial meter stack, 37MM-3-Phase Module, 400A, K-frame included secondary breaker, (1) 200A and (1) 350A breaker installed, 400A socket, 208Y/120V, Ringless, Al 1200A bus, Lever bypass, Seven-jaws, 2 sockets
Product Name
Eaton commercial meter stack
Catalog Number
37MM240R124095
UPC
786689061821
Product Length/Depth
66.625 in
Product Height
8.75 in
Product Width
19.375 in
Product Weight
320 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Number of sockets
2
Amperage Rating
400A
Cover
Ringless
Residential and Light Commercial, Metering Products, Volume 1 Tab 4
Eaton Specification Sheet - 37MM240R124095
The 37MM240R124095 meter stack delivers a robust 400A rating with two sockets, enabling quick, compliant connections for essential feeders and downstream distribution. This feature translates to measurable business impact: safer, faster installation and reduced field wiring time, which lowers labor costs and accelerates time-to-power. In practice, electricians can rely on a ringless cover and lever bypass to streamline maintenance, minimize outage windows, and facilitate rapid isolation during troubleshooting in commercial facilities. The integrated K-frame secondary breaker and seven-jaws design support reliable fault protection and simple retrofits, improving uptime and asset protection for data centers, offices, or retail environments. With 208Y/120V operation and solid aluminum bus for high reliability, the unit supports scalable metering as facilities grow, reducing the need for costly enclosure replacements. Compatibility with Eaton metering products and standard low‑voltage distribution practices makes this stack an easy fit for existing electrical rooms and new builds alike. The enclosure’s dimensions—66.625 in long, 8.75 in high, and 19.375 in wide—offer predictable space planning and installation efficiency, while UL certification and a one‑year to eighteen‑month warranty framework provide purchasing confidence and long‑term support.
Get a Quick Quote for a Eaton 37MM240R124095
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 37MM240R124095?
Enquire Now
FAQs
This meter stack is designed for 208Y/120V three‑phase commercial power distributions and supports a 400A rating with two sockets. It fits standard low‑voltage metering setups and integrates with K‑frame secondary protection. When planning, ensure adequate floor space for the 66.625 inch length and 19.375 inch width enclosure, and verify UL Listed compliance for your facility.
Key specs include a 400A amperage rating, 208Y/120V operating voltage, two sockets, and a ringless cover. The unit ships with a 200A and a 350A breaker installed, a 400A socket, and a 1200A aluminum bus. It supports seven‑jaw connections and lever bypass for safer, faster maintenance in commercial metering applications.
Yes. The 37MM240R124095 is intended for commercial environments such as office buildings, retail centers, and multi‑tenant facilities requiring robust metering and distribution in a single enclosure. Its 400A rating, 208Y/120V service, and modular design support scalable metering for growing loads, while the UL Listed certification ensures regulatory compliance for typical commercial installations.
The meter stack carries UL Listed certification, indicating compliance with recognized safety standards for commercial electrical equipment. This status helps streamline approvals with local inspectors and ensures safer operation in utility metering or building distribution systems. Additional Eaton warranties and support are available to back up installation decisions.
The integrated design reduces field labor by combining metering and distribution in one enclosure, cutting installation time and ongoing maintenance costs. Features like ringless access, lever bypass, and a K‑frame secondary breaker minimize downtime during servicing and enable rapid fault isolation, delivering lower total cost of ownership and improved system reliability for facilities managers.
