Eaton 3BR3L100R Main Lug Loadcenter - NEMA 3R
Part Number: 3BR3L100R
Quick Summary
The Eaton 3BR3L100R Main Lug Loadcenter is a compact 100 A three‑phase distribution unit for commercial panels. This main lug design reduces wiring complexity by eliminating feed-thru lugs, cutting installation time and minimizing wiring errors. UL 50 and UL 67 listings, along with a NEMA 3R enclosure, ensure dependable performance in indoor and outdoor environments. With BR 1‑inch breaker compatibility and a 10‑year warranty, it supports fast retrofits and lower lifecycle costs for panel upgrades and new builds.
Product Information
Extended Description
3BR3L100R Eaton: Eaton BR main lug loadcenter,No feed-thru lugs,Main lug,100 A,9R,Aluminum,Cover included,NEMA 3R,Metallic,10 kAIC,BR,3 Circuits,Three-pole,3 Spaces,Four-wire,Three-phase,Type BR 1-inch breakers,208 Y/120, 240 V,#14-1/0 AWG Cu/Al
Product Name
Eaton BR main lug loadcenter
Catalog Number
3BR3L100R
UPC
782114868294
Product Length/Depth
3.88 in
Product Height
39 in
Product Width
14.31 in
Product Weight
7.36 lb
Warranty
10 year
Certifications
UL 50 UL 67
Special features
No feed-thru lugs
Type
Main lug
Amperage Rating
100 A
Bus material
Aluminum
Cover
Cover included
Main circuit breaker
BR
Number of circuits
3
Number Of Poles
Three-pole
Number of spaces
3
Phase
Three-phase
Used with
Type BR 1-inch breakers
Voltage rating
208Y/120, 240V
Wire size
#14-1/0 AWG Cu/Al
Box size
9R
Enclosure
NEMA 3R
Enclosure material
Metallic
Interrupt rating
10 kAIC
Number of wires
4
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - 3BR3L100R
Eaton type BR circuit breaker limited warranty June 2024
Feature: 100 A main lug, three spaces, three-phase configuration. Business impact: Enables compact, scalable power distribution with straightforward expansion in growing facilities. Application: Ideal for commercial panels and light industrial service entrances where space is at a premium. Feature: No feed-thru lugs. Business impact: Reduces wiring complexity and potential miswiring, accelerating installation and reducing field errors. Application: Outdoor and indoor installations requiring quick, reliable wiring with BR breakers. Feature: Aluminum bus. Business impact: Lightweight yet durable conductors improve handling during installation and reduce operating exposure to corrosion. Application: Industrial environments with variable temperatures and exposure. Feature: NEMA 3R, metallic enclosure. Business impact: Weather-resistant protection for outdoor service panels, lowering maintenance costs. Application: Outdoor utility rooms, mechanical spaces, and manufacturing floors. Feature: Covered with BR 1‑inch breaker compatibility. Business impact: Streamlined sourcing and replacement, ensuring compatibility across existing panels. Application: Retrofit projects and facility upgrades. Feature: 208Y/120 or 240 V ratings and 4-wire capability. Business impact: Flexible wiring options support diverse electrical systems. Application: Commercial and light industrial equipment feeds. Feature: 10 kAIC interrupt rating. Business impact: Enhanced fault tolerance reduces downstream damage. Application: Critical load centers and process lines.
