Eaton 653BLACK EMT compression connector - Threadless
Part Number: 653BLACK
Quick Summary
653BLACK EMT compression connector terminates EMT conduit in industrial electrical installations. A common challenge is achieving fast, reliable terminations that resist vibration and corrosion. It complies with NEC/CEC standards and is rated for Ordinary/Non-Hazardous Locations. For engineers and procurement teams, this steel, threadless connector offers installation efficiency, reduced field rework, and long-term durability across panel builds and automation applications. The product's 1-1/4 inch trade size and compact form fit tight spaces inside control cabinets. Its non-insulated design minimizes heat buildup in dense wiring bundles, helping maintain conductor integrity. Combined with Eaton's UL certifications and catalog resources, it simplifies sourcing, supports compliance, and strengthens project documentation.
Product Information
Extended Description
653BLACK Eaton: Eaton Crouse-Hinds series EMT compression connector, Black, EMT, Straight, Non-insulated, Steel, Threadless, 1-1/4"
Product Name
Eaton Crouse-Hinds series EMT compression connector
Catalog Number
653BLACK
UPC
662277090254
Product Length/Depth
1.81 in
Product Height
2.13 in
Product Width
2.13 in
Product Weight
0.43 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
EMT
Connector type
Straight
Style
Compression
Insulator
Non-insulated
Trade size
1-1/4"
Color
Black
Thread
Threadless
Material
Steel
Eaton Crouse-Hinds 653BLACK 3D drawing
Crouse-Hinds series Connectors and Couplings - EMT catalog page
Connectors and Couplings - EMT UL certification
Connectors and Couplings - EMT UL certification
Eaton Specification Sheet - 653BLACK
Compression-style straight connectors eliminate threading steps, enabling rapid terminations with a dedicated tool. This translates to shorter panel build times, reduced labor costs, and more predictable results in high-volume assemblies. In practice, engineers appreciate consistent electrical contact and fewer field adjustments when using 653BLACK in automated equipment. The steel construction with a black, non-insulated finish delivers robust durability and corrosion resistance suitable for ordinary locations. Its threadless design minimizes galling and cross-threading risks, while maintaining secure, vibration-resistant connections in active electrical panels. The 1-1/4 inch trade size and 1.81 inch length provide a compact fit for dense conduit runs, allowing cleaner routing in control cabinets and switchgear enclosures. EMT compatibility ensures broad adoption across standard installations, reducing part variety and simplifying inventory. Availability of UL listings, NEC/CEC compliance, and Eaton catalog resources further support engineering validation and procurement workflows. CAD drawings and catalogs streamline design review, favoring faster project approvals and reduced design risk for industrial automation projects.
Get a Quick Quote for a Eaton 653BLACK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 653BLACK?
Enquire Now
FAQs
The 653BLACK is a straight, compression-type EMT connector designed for a 1-1/4 inch trade size. It is threadless and non-insulated, intended for steel EMT conduits in ordinary locations. It requires a compatible compression tool and is ideal for quick, reliable terminations in control panels, switchgear, and enclosures.
Compression fittings like the 653BLACK eliminate threading and set-screw steps, enabling faster terminations with a dedicated compression tool. This reduces handling time, minimizes the risk of cross-threading, and yields more consistent electrical contact, which is especially beneficial in high-volume panel builds and tight electrical spaces.
The 653BLACK is rated for Ordinary/Non-Hazardous Locations under NEC/CEC standards. It is not specified for hazardous environments. For such applications, select fittings with appropriate hazardous-location ratings and verify compatibility with local codes and UL listings.
It adheres to NEC/CEC standards for ordinary locations and is accompanied by UL certification resources for both the US and Canada. These certifications support compliance documentation and regulatory acceptance in typical industrial facilities and help simplify procurement and quality assurance processes.
Eaton provides design resources including a 3D CAD drawing package, an EMT catalog page, and a specification sheet. These assets help verify dimensions, weight, and rating, support accurate modeling in assemblies, and facilitate faster approvals during the engineering and procurement stages.
