Eaton 653ORANGE EMT Connector - Orange, Straight, NEC/CEC
Part Number: 653ORANGE
Quick Summary
653ORANGE EMT compression connector delivers secure EMT terminations for industrial conduit runs. In many installations, crews struggle with slow terminations, retrofit challenges, and inconsistent insulation choices. This straight, threadless connector from Eaton Crouse-Hinds is designed to speed up assembly while maintaining robust corrosion resistance in steel. It is rated for ordinary/non-hazardous locations and aligns with NEC/CEC requirements, with UL Canadian certification support documented in the official reports. Using this connector helps you reduce installation time, improve auditability, and simplify field maintenance. Its orange color supports quick identification in crowded panels or trunking, while the non-insulated steel construction ensures durable, long-life service for daily industrial use.
Product Information
Extended Description
653ORANGE Eaton: Eaton Crouse-Hinds series EMT compression connector, Orange, EMT, Straight, Non-insulated, Steel, Threadless, 1-1/4"
Product Name
Eaton Crouse-Hinds series EMT compression connector
Catalog Number
653ORANGE
UPC
662277090773
Product Length/Depth
1.81 in
Product Height
2.13 in
Product Width
2.13 in
Product Weight
0.43 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
EMT
Connector type
Straight
Style
Compression
Insulator
Non-insulated
Trade size
1-1/4"
Color
Orange
Thread
Threadless
Material
Steel
Eaton Crouse-Hinds 653ORANGE 3D drawing
Crouse-Hinds series Connectors and Couplings - EMT catalog page
Connectors and Couplings - EMT Canadian certification
Connectors and Couplings - EMT Canadian certification
Eaton Specification Sheet - 653ORANGE
Compression design delivers a secure, tool-efficient termination with fewer components, enabling faster assembly, reduced rework, and more consistent performance under vibration. In control panels and field cabinets, this translates to shorter commissioning windows and lower labor costs. The 1-1/4 inch trade size and distinctive orange color support rapid identification and seamless compatibility with EMT conduit, reducing downtime during maintenance and upgrades. The threadless, non-insulated steel construction provides rugged durability and corrosion resistance, extending service life and lowering replacement costs in harsh plant environments. Compliance with NEC/CEC and UL Canada certification simplifies regulatory audits and site approvals, reducing project risk. Availability of 3D CAD drawings and catalogs accelerates engineering workflows, improving BOM accuracy and ensuring correct fit in enclosure terminations. Ordinary/non-hazardous location ratings enable broad applicability across manufacturing floors, data centers, and process facilities.
Get a Quick Quote for a Eaton 653ORANGE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 653ORANGE?
Enquire Now
FAQs
The 653ORANGE uses a compression, threadless design for EMT terminations, allowing tool-free or minimal-tool installations that speed up assembly. It reduces re-termination risk, delivers consistent clamping force, and minimizes the chance of insulation damage during assembly. This makes it ideal for busy panels, field cabinets, and retrofit projects where time and reliability matter.
Yes. The 653ORANGE is specified for a 1-1/4" trade size EMT conduit and features a non-insulated, threadless compression design. Installation uses standard EMT fittings practices, with no additional insulation required in ordinary/non-hazardous locations. This simplifies field installations while ensuring a secure, code-compliant termination.
653ORANGE is built to NEC/CEC standards and rated for ordinary/non-hazardous locations, with UL Canada certification support referenced in authorized reports. Certification documents are available through UL Canada listings and Eaton’s specification resources, including the official datasheet and product pages for traceability and compliance evidence.
Typical applications include electrical panels, motor control cabinets, switchgear terminations, and process equipment enclosures requiring reliable EMT terminations. The compression design reduces installation time and labor costs, lowers rework risk, and improves field reliability, leading to quicker project completion and lower maintenance overhead in manufacturing plants and data centers.
You can download 3D CAD drawings and the EMT catalog page from Eaton’s resources. The provided downloads include a 3D CAD package, the EMT catalog page for Crouse-Hinds series connectors, and the Eaton specification sheet, enabling accurate design integration and BOM accuracy in engineering workflows.
