Eaton 656ORANGE EMT Compression Connector - Threadless
Part Number: 656ORANGE
Quick Summary
656ORANGE EMT compression connector enables reliable EMT terminations for steel conduits in industrial wiring. Installers often struggle with non-insulated, threadless fittings that demand precise alignment and can compromise durability. These fittings meet NEC/CEC standards and are certified for ordinary/non-hazardous locations, with UL listings supporting compliance. By leveraging the Eaton Crouse-Hinds lineage and the distinct orange identification, contractors gain faster installs, predictable performance, and easier field inspections, while staying aligned with code requirements. The 2-1/2 in trade size, steel body, and non-insulated compression design simplify inventory management and reduce installation time in crowded panels and restricted spaces. Orange color coding also supports quick compliance checks during audits.
Product Information
Extended Description
656ORANGE Eaton: Eaton Crouse-Hinds series EMT compression connector, Orange, EMT, Straight, Non-insulated, Steel, Threadless, 2-1/2"
Product Name
Eaton Crouse-Hinds series EMT compression connector
Catalog Number
656ORANGE
UPC
662277090803
Product Length/Depth
3.31 in
Product Height
3.75 in
Product Width
3.75 in
Product Weight
1.9 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
EMT
Connector type
Straight
Style
Compression
Insulator
Non-insulated
Trade size
2-1/2"
Color
Orange
Thread
Threadless
Material
Steel
Eaton Crouse-Hinds 656ORANGE 3D drawing
Crouse-Hinds series Connectors and Couplings - EMT catalog page
Connectors and Couplings - EMT UL certification
Connectors and Couplings - EMT UL certification
Eaton Specification Sheet - 656ORANGE
Orange identification combined with a compression mechanism delivers rapid, secure terminations in crowded panels and control cabinets. The design minimizes misalignment and torque demands, reducing installation time and rework in high-mix environments common to manufacturing—and improving first-pass compliance with NEC/CEC requirements. Compatibility and installation advantages: The 656ORANGE is a straight EMT connector in the Crouse-Hinds series, purpose-built for 2-1/2 inch trade-size EMT conduit. Its threadless, compression style eliminates the need for threaded nuts, enabling tool-free or minimal-tool installations and predictable seating in tight spans. Durability and compliance: Made from steel with non-insulated insulation, the connector offers robust mechanical strength for ordinary/non-hazardous locations. It carries NEC/CEC standards and UL certification, supporting code-approved terminations and simplifying inspection. Lifecycle and value: By standardizing on this connector across panels, you streamline inventory, reduce part variety, and leverage Eaton's engineering backing for reliability. Availability of 3D CAD drawings and EMT catalogs helps engineering teams model installations accurately and accelerate procurement.
Get a Quick Quote for a Eaton 656ORANGE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 656ORANGE?
Enquire Now
FAQs
To install the 656ORANGE, cut and deburr the EMT conduit, slide the connector over the conduit, insert the conduit until it seats fully in the body, and apply the appropriate compression mechanism per Eaton’s instructions. As with all NEC/CEC installations, verify proper seating, alignment, and secure the compression elements before energizing the circuit.
The 656ORANGE is designed to NEC/CEC compliant terminations and carries UL certifications for EMT fittings. It is classified for Ordinary/Non-Hazardous Locations, ensuring suitability for standard commercial and industrial environments while supporting regulatory audits and compliance reporting.
No. The connector is rated for Ordinary/Non-Hazardous Locations. For hazardous or classified locations, select Eaton components explicitly rated for those conditions and consult the applicable standards and local codes to ensure safe operation.
Threadless compression eliminates the need for threaded nuts, reducing torque requirements and misalignment risk. This simplifies installation in tight spaces, speeds up terminations, lowers rework rates, and improves field consistency, especially in high-density panels and limited-access setups common in manufacturing and processing facilities.
Yes. Eaton provides a 3D CAD drawing package and EMT catalog pages for the 656ORANGE, along with a specification sheet. These resources help engineers model installations, ensure proper fit, and streamline procurement while maintaining design accuracy.
