Eaton 658ORANGE EMT compression connector - Non-insulated
Part Number: 658ORANGE
Quick Summary
The Eaton 658ORANGE EMT compression connector provides secure straight EMT joins for industrial conduit. For design engineers and purchasing teams, inconsistent fittings cause project delays, documentation gaps, and rework during installation. This connector meets NEC/CEC standards and carries Canadian certification, with a designation for Ordinary/Non-Hazardous Locations. Designed from durable steel and finished orange, it is non-insulated, threadless, and suited for 3-1/2 inch trade sizes in straight runs. Using this connector reduces installation time, improves reliability under vibration, and simplifies color identification on crowded panels. Overall, it supports efficient wiring & connectivity projects by providing a robust, compliant solution you can trust in Ordinary/Non-Hazardous locations.
Product Information
Extended Description
658ORANGE Eaton: Eaton Crouse-Hinds series EMT compression connector, Orange, EMT, Straight, Non-insulated, Steel, Threadless, 3-1/2"
Product Name
Eaton Crouse-Hinds series EMT compression connector
Catalog Number
658ORANGE
UPC
662277090827
Product Length/Depth
3.69 in
Product Height
5 in
Product Width
5 in
Product Weight
3 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
EMT
Connector type
Straight
Style
Compression
Insulator
Non-insulated
Trade size
3-1/2"
Color
Orange
Thread
Threadless
Material
Steel
Eaton Crouse-Hinds 658ORANGE 3D drawing
Crouse-Hinds series Connectors and Couplings - EMT catalog page
Connectors and Couplings - EMT Canadian certification
Connectors and Couplings - EMT Canadian certification
Eaton Specification Sheet - 658ORANGE
Feature → Business Impact → Application: The 658ORANGE is an EMT compression connector built for straight EMT runs in industrial facilities, delivering a secure, vibration-resistant join that reduces maintenance calls and rework on crowded panels. This directly improves installation speed and overall system reliability in mission-critical wiring projects. Application: Use in steel conduit networks where orange color aids rapid identification and where NEC/CEC compliance is mandatory for ordinary, non-hazardous locations. Feature → Business Impact → Application: Threadless, non-insulated design simplifies field assembly, minimizes tool requirements, and lowers total installed cost in large panel arrays. Application: Ideal for automation and power distribution setups needing quick, repeatable fittings with consistent performance. Feature → Business Impact → Application: Steel construction provides durable service in demanding environments, supporting longer service life and lower replacement costs. Application: Suitable for light to medium industrial installations where robust mechanical strength and code compliance are essential. Feature → Business Impact → Application: 3-1/2 inch trade size ensures compatibility with standard EMT systems used in commercial and industrial zones, enabling scalable conduit networks. Application: Plan multi-run installations with predictable fit and straightforward procurement.
Get a Quick Quote for a Eaton 658ORANGE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 658ORANGE?
Enquire Now
FAQs
The 658ORANGE is designed for EMT conduit with a 3-1/2 inch trade size and straight runs. It uses a threadless compression style, simplifying field assembly and reducing the number of required components. The steel body is non-insulated and color-coded orange for quick identification, making it ideal for ordinary, non-hazardous locations.
The 658ORANGE meets NEC/CEC standards and carries Canadian certification listings. It is designed for Ordinary/Non-Hazardous Locations, and Eaton provides certification references for additional validation, including UL-listed documentation for compliance in North American markets.
No. The 658ORANGE is specified for Ordinary/Non-Hazardous Locations. For hazardous or potentially explosive environments, select a conduit connector with appropriate explosion-proof or intrinsically safe ratings and the corresponding certifications.
Compression, threadless connectors shorten installation time by eliminating threaded coupling steps and reducing tool requirements. They provide reliable clamping on EMT, improve alignment in crowded panels, and help maintain code-compliant installations with fewer parts to manage during fieldwork.
658ORANGE features a 3-1/2 inch trade size, orange color, non-insulated steel body, and straight connector geometry. It is designed for EMT conduit in straight runs, with a 3-1/2 inch length and a compact profile suitable for tight installations in industrial electrical systems.
