Eaton 6636-4XSFW Wireway - NEMA 4X rated stainless
Part Number: 6636-4XSFW
Quick Summary
Eaton 6636-4XSFW Wireway provides rugged cable routing for industrial electrical installations. Users struggle with corrosion, washdown exposure, and difficult access to enclosed wiring in harsh environments. This unit carries UL Listed and CSA C22.2 certifications and a NEMA 4X rating, aligning with safety and reliability standards. Built for the Eaton B-Line wireway ecosystem, it combines 16 gauge 304 stainless steel with a hinged cover to speed maintenance and ensure long-term compliance. Secondary benefits include easy installation, compatibility with standard wireway hangers, and streamlined procurement through the Eaton family of B-Line products. Overall, this wireway enables safer, faster wiring layouts and lower total cost of ownership in automated facilities.
Product Information
Extended Description
6636-4XSFW Eaton: Eaton B-Line series wireway, 6" height, 36" length, 6" width, 4XSFW wireway, Wireway hanger, Hinged cover, NEMA 4X, 304 stainless steel, Seamless poured in-place, Hinged, #4 brushed finish, 16 gauge
Product Name
Eaton B-Line series wireway
Catalog Number
6636-4XSFW
UPC
782051134506
Product Length/Depth
36 in
Product Height
6 in
Product Width
6 in
Product Weight
17.468 lb
Certifications
CSA C22.2. UL Listed
Material thickness
16 gauge
Finish color
#4 brushed
Closure type
Hinged
Mounting method
Wireway hanger
Special features
Cover secured by hinges, screwclamps&s.s. hardware
Type
4XSFW wireway
Feature: The 16 gauge, 304 stainless steel construction delivers superior corrosion resistance and washdown compatibility for industrial environments. Business Impact: Reduces maintenance frequency and replacement costs in harsh facilities such as food processing and pharma. Application: Ideal for the 6x6x36 inch footprint within Eaton B-Line wireway systems, enabling durable cable routing in tight spaces. Feature: Hinged cover with screw clamps and stainless hardware provides quick, tool-free access and secure closure. Business Impact: Accelerates maintenance cycles and minimizes downtime. Application: Suited for frequent inspections on automated production lines. Feature: NEMA 4X rated enclosure with seamless poured-in-place construction. Business Impact: Protects cables from water, dust, and corrosion, improving reliability in outdoor or washdown settings. Application: Critical for outdoor installations and washdown zones in manufacturing plants. Feature: 6 in height, 6 in width, 36 in length with integrated wireway hanger mounting. Business Impact: Large capacity for cable bundles while simplifying mounting reduces installation time. Application: Typical for mid-size runs in industrial facilities using the B-Line family. Feature: 16 gauge, 304 stainless steel finish with #4 brushed appearance. Business Impact: Combines durability with a cleanable surface suitable for hygienic environments. Application: Environments demanding sanitary finishes and durable corrosion resistance. Feature: Compliance and compatibility with the Eaton B-Line wireway ecosystem including EnviroShield resources. Business Impact: Streamlines procurement, warranties, and integration with existing enclosures. Application: Retrofit projects and new installations in automation and process industries.
Get a Quick Quote for a Eaton 6636-4XSFW
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6636-4XSFW?
Enquire Now
FAQs
Installation leverages the included wireway hanger mounting to secure the 6636-4XSFW in standard B-Line enclosures. The hinged cover with stainless hardware allows rapid, tool-free access during maintenance, while the 16 gauge 304 stainless steel body resists corrosion in washdown zones. Ensure alignment with adjacent units, fasten securely using the approved hardware, and verify sealing for NEMA 4X protection.
Key specs include a 6 inch height, 6 inch width, and 36 inch length, 16 gauge stainless steel construction, hinged cover, and NEMA 4X protection. The unit is UL Listed and CSA C22.2 certified, designed for robust cable routing with a 304 stainless steel finish. The footprint fits standard Eaton B-Line wireway systems and supports multiple cable runs.
Yes. The wireway features NEMA 4X protection and 304 stainless steel construction, providing reliable corrosion resistance in washdown areas and outdoor installations. Its seamless poured-in-place design and hinged cover further protect internal cables from moisture, dust, and contaminants while enabling easy maintenance access in challenging environments such as food processing, healthcare, and water treatment facilities.
The 6636-4XSFW is UL Listed and CSA C22.2 certified, reflecting compliance with recognized safety and performance standards. These certifications, combined with the NEMA 4X rating, give engineers confidence in reliability, protectivity, and suitability for regulated industries where wiring needs to withstand harsh conditions and frequent maintenance.
The 16 gauge 304 stainless steel build delivers superior corrosion resistance, reducing refurbishment and replacement costs in harsh environments. Hinged access speeds maintenance tasks, lowering downtime. While initial cost may be higher than non-stainless options, extended service life, fewer corrosion-related failures, and simpler upkeep translate to a favorable total cost of ownership over the product life cycle.
