Eaton 6DSL-B1600 Cable Limiter - 200 kAIC IEEE C37.41
Part Number: 6DSL-B1600
Quick Summary
The Eaton 6DSL-B1600 Cable Limiter is a high-capacity current limiter for low-voltage feeder protection in industrial plants. Nuisance trips and downstream faults can cause costly downtime, and this device helps prevent that. Certified to IEEE Std C37.41, it complements standard protection schemes while delivering fast fault-current interruption. Designed for 1600 A at 600 V with a 200 kAIC interrupt rating, it supports safe, reliable operation and reduces protection coordination concerns. In practice, this limiter streamlines protection strategy, improves uptime, and aligns with common low-voltage protection objectives while supporting broader efficiency and reliability goals for power distribution systems.
Product Information
Extended Description
6DSL-B1600 Eaton: Eaton Bussmann series current limiter Low voltage DSL type, 1600A, 600V, 200 kA interrupt
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-B1600
UPC
786670249559
Product Length/Depth
5.75 in
Product Height
2.88 in
Product Width
2.88 in
Product Weight
4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEEE Std. C37.41
Amperage Rating
1600 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Quantity
1
Special features
Cable limiter
Feature: High-capacity current limiting delivers dramatic fault-energy reduction. Business Impact: Protects cables and switchgear, minimizes downstream damage, and improves protection coordination. Application: Main feeders, motor control centers, and switchgear in manufacturing and processing facilities. Feature: Compact form factor and mounting simplicity. Business Impact: Eases panel integration, retrofit projects, and space-constrained enclosures, reducing installation time and labor cost. Application: Retrofit and new-install projects across industrial plants and facilities. Feature: IEEE C37.41 certified protection. Business Impact: Enhances safety compliance and aligns with industry-standard protection practices, lowering regulatory risk. Application: Electrical rooms and switchgear assemblies requiring formal standards conformance. Feature: 1600 A, 600 V, 200 kAIC rating. Business Impact: Delivers robust fault current limitation for high-energy circuits, reducing equipment stress and maintenance needs. Application: Feeder circuits and critical bus connections in harsh industrial environments. Feature: Warranty and service continuity. Business Impact: One-year warranty (or 18 months from shipment) minimizes ownership risk and supports predictable maintenance planning. Application: Asset lifecycle management and service contracts across plants and facilities.
Get a Quick Quote for a Eaton 6DSL-B1600
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-B1600?
Enquire Now
FAQs
Yes. The 6DSL-B1600 is designed as part of the Bussmann series protection family and fits standard low-voltage panels and switchgear up to 600 V. It measures 5.75 inches long by 2.88 inches wide by 2.88 inches high and weighs 4 lb, using standard mounting and bus-bar connections for straightforward retrofit or new installations.
The 6DSL-B1600 provides a 1600 A amperage rating, 600 V voltage rating, and a 200 kAIC interrupt rating. It is a DSL-type current limiter designed for rapid fault-current interruption, with IEEE C37.41 certification to support reliable protection coordination in low-voltage distribution networks.
It is ideal for protecting main feeders, motor control centers, and switchgear in manufacturing plants and processing facilities. Its high-current limitation reduces fault severity, minimizes downstream damage, and supports uptime in power distribution systems where space and installation simplicity matter.
The primary certification is IEEE Std. C37.41, which supports protection coordination and reliability in electrical systems. The device is designed to meet industry-standard performance requirements for low-voltage current-limiting protection and is intended for use in compliant electrical installations.
The unit carries a one-year warranty from installation or eighteen months from shipment, whichever comes first, reducing ownership risk. By limiting fault current, it lowers the likelihood of catastrophic damage and downtime, enabling longer service intervals, easier maintenance planning, and a favorable total cost of ownership for power distribution assets.
