Eaton 6DSL-C1000 Cable Limiter - IEEE C37.41 Certification
Part Number: 6DSL-C1000
Quick Summary
The Eaton 6DSL-C1000 Cable Limiter is a low-voltage, current-limiting fuse designed for industrial power distribution and control panels. This solution helps operators avoid nuisance trips and costly downtime by rapidly interrupting fault currents. It aligns with IEEE Std. C37.41 for reliable industrial protection, and Eaton backs it with a standard one-year warranty. With a compact footprint and straightforward installation, it fits standard low-voltage panels and supports scalable protection for modern control systems. As part of the Bussmann series, the 6DSL-C1000 delivers dependable, easy-to-source protection for panel upgrades and new installations alike.
Product Information
Extended Description
6DSL-C1000 Eaton: Eaton Bussmann series, Low voltage DSL type current limiting fuse, 1000A, 600V, 200 kA interrupt
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-C1000
UPC
786670249726
Product Length/Depth
5.75 in
Product Height
3.38 in
Product Width
3.38 in
Product Weight
4.2 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEEE Std. C37.41
Amperage Rating
1000 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Quantity
1
Special features
Cable limiter
Bussmann series Fuseology
Eaton Specification Sheet - 6DSL-C1000
Selling Policy 25-000 - Distribution and Control Products and Services
Feature: 1000 A amperage rating with DSL-type current-limiting fuse. Business Impact: Fast isolation of fault currents reduces conductor damage and downtime, improving line availability in feeders up to 1000 A. Application: Control panels and motor feeders in industrial environments. Feature: 600 V voltage rating and 200 kAIC interrupt capacity. Business Impact: Enhanced protection against high-energy faults, lowering risk of equipment overload and fire, while meeting typical industry protection standards. Application: LV distribution blocks and cabinet assemblies with demanding fault levels. Feature: Compact dimensions (5.75 in L, 3.38 in W, 3.38 in H) and 4.2 lb weight. Business Impact: Easy integration into tight spaces and retrofit projects without invasive enclosure changes. Application: Modernization of existing panels and space-constrained installations. Feature: IEEE Std. C37.41 certification. Business Impact: Verifiable compliance for industrial protection schemes, easing procurement and audit processes. Application: Panel assemblies requiring recognized fault-current protection standards. Feature: Cable limiter specialty and Bussmann series compatibility. Business Impact: Streamlined stocking and maintenance with familiar parts, reducing spare-part inventory and lead times. Application: Replacement in legacy Bussmann/Cable limiter implementations and new builds. Feature: Warranty and support. Business Impact: Reduced lifecycle risk with a one-year warranty from installation, aiding total cost of ownership (TCO) planning. Application: Procurement and service contracts for facilities and OEM projects.
Get a Quick Quote for a Eaton 6DSL-C1000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-C1000?
Enquire Now
FAQs
Install the 6DSL-C1000 in a well-ventilated, labeled panel with adequate clearance around cables. Its 5.75 in length and 3.38 in width/height fit standard enclosures, and a 4.2 lb weight minimizes handling risk. Ensure correct busbar alignment and secure terminal connections to maintain the 1000 A rating and 200 kAIC interrupt capability.
The device is rated to carry up to 1000 A and operate at up to 600 V, interrupting fault currents up to 200 kAIC. This means it quickly clears high-energy faults in LV feeders, protecting conductors and equipment while reducing arc energy and downtime in fault conditions.
Yes. With its DSL-type current limiter and 600 V, 1000 A ratings, the 6DSL-C1000 is well-suited for LV protection in control panels, motor feeders, and distribution blocks within manufacturing environments. Its compact footprint eases retrofits and new panel builds while meeting typical industry fault-current protection needs.
The 6DSL-C1000 conforms to IEEE Std. C37.41, highlighting its suitability for industrial fault-current protection. This certification helps verify performance under fault conditions and supports compliance during audits and supplier qualifications.
The unit carries a one-year warranty from installation under Eaton’s policy, reducing maintenance risk. Its high interrupt rating and proven reliability help minimize replacement frequency, lowering spare-part costs and downtime. Typical savings come from fewer nuisance trips and simpler stocking of compatible Bussmann series components.
