Eaton 6DSL-C1200 Cable Limiter - IEEE C37.41 Certified
Part Number: 6DSL-C1200
Quick Summary
The Eaton 6DSL-C1200 Cable Limiter protects bus and cables by fast current limiting in control and power circuits. For engineers, selecting the wrong fuse can cause nuisance trips, wasted space, and costly downtime, making proper sizing essential. It is IEEE Std C37.41 compliant, aligning with industry safety and performance expectations, while its DSL-type current-limiting design delivers reliable interruption in demanding environments. This solution pairs with Eaton Bussmann series components to simplify panel design, accelerate commissioning, and improve overall system reliability in industrial power distribution. Use cases span machine control, motor drives, and feeder protection where space, speed, and conformity matter.
Product Information
Extended Description
6DSL-C1200 Eaton: Eaton Bussmann series current limiting fuse, Low voltage DSL type , 1200A, 600V, 200 kA interrupt
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-C1200
UPC
786670249764
Product Length/Depth
5.75 in
Product Height
3.38 in
Product Width
3.38 in
Product Weight
4.2 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEEE Std. C37.41
Amperage Rating
1200 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Quantity
1
Special features
Cable limiter
Feature: Current-limiting performance delivers rapid arc-extinguishing action. Benefit: Reduces fault energy and minimizes conductor damage, improving system uptime and reducing collateral equipment wear in motor control centers. Application: Ideal for control panels and power distribution blocks where fast interruption is critical to maintain line-side availability. Feature: High interrupt rating of 200 kAIC. Benefit: Enables protection across large fault currents without nuisance tripping, supporting safer start-up and reliable factory operations. Application: Suitable for high-energy drives and feeder circuits in manufacturing lines where fault levels can spike. Feature: 1200 A at 600 V rating. Benefit: Handles heavy-duty loads in compact form factors, enabling streamlined panel layouts and fewer components. Application: Common in DC and AC distribution segments for machine tools and process equipment. Feature: Cable limiter design and compact dimensions (5.75 in L, 3.38 in W, 3.38 in H). Benefit: Easier installation in crowded enclosures and panel racks, reducing assembly time and enclosure footprint. Application: Retrofit and new builds where space is at a premium. Feature: IEEE Std C37.41 compliance. Benefit: Aligns with established protection standards, supporting regulatory and customer requirements across facilities. Application: Critical for audits and safety certifications in industrial electrification projects. Feature: Eaton Bussmann series integration. Benefit: Streamlines procurement, warranty coverage, and compatibility with other Bussmann devices, lowering total cost of ownership. Application: Suitable for integrated protection schemes in automation and controls.
Get a Quick Quote for a Eaton 6DSL-C1200
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-C1200?
Enquire Now
FAQs
Yes. The 6DSL-C1200 uses a low-voltage DSL-type current limiter designed to integrate with Eaton Bussmann series components and common panel architectures. Its compact 5.75 in length and 3.38 in width support straightforward mounting in standard enclosures, while the 1200 A rating accommodates heavy feeder protection in modern automation cells.
The device is rated for 1200 A at 600 V with a 200 kAIC interrupt rating. This combination enables fast fault interruption while handling high fault currents, reducing arc energy and protecting cables and downstream equipment in industrial power distribution.
Applications include machine control panels, motor drives, and feeder protection where space is limited but reliable fault interruption is essential. The 6DSL-C1200 supports high-energy drives and complex control schemes, helping minimize downtime and maintain consistent production cycles.
The 6DSL-C1200 carries IEEE Std C37.41 compliance, ensuring alignment with established protection performance requirements for switchgear and protective devices. This assists with regulatory adherence, project specifications, and quality benchmarks in industrial facilities.
Eaton provides a one-year warranty from installation or 18 months from shipment, whichever occurs first. This coverage supports field reliability, with access to Eaton’s technical support and service resources to address field performance or compatibility questions.
