Eaton 6DSL-C2000 Cable Limiter - 600V, 200 kAIC
Part Number: 6DSL-C2000
Quick Summary
The Eaton 6DSL-C2000 cable limiter is a high-capacity current-limiting fuse for protecting LV wiring in switchgear and panel installations. Engineers often face nuisance trips, arc-flash risk, and costly downtime when protection is poorly coordinated. This device complies with IEEE Std. C37.41, supporting reliable protection of motor feeders and critical loads. Designed for easy installation in low-voltage power distribution, it delivers robust cable limiter protection while enabling efficient coordination with upstream devices, reducing total cost of ownership. With a 2000 A rating and 200 kAIC interrupt capability at 600 V, it supports demanding industrial environments.
Product Information
Extended Description
6DSL-C2000 Eaton: Eaton Bussmann series current limiting fuse, Low voltage DSL type current limiting fuse, 2000A, 600V, 200 kA interrupt
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-C2000
UPC
786670249849
Product Length/Depth
5.75 in
Product Height
3.38 in
Product Width
3.38 in
Product Weight
4.2 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEEE Std. C37.41
Amperage Rating
2000 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Quantity
1
Special features
Cable limiter
Feature: High amperage rating and 200 kAIC interrupt capacity. Business impact: Enables rapid fault clearance and minimizes arc energy, reducing equipment damage and downtime. Application: Best suited for feeders in switchgear and heavy panel boards where high fault currents are expected. Feature: 600 V voltage rating. Business impact: Ensures compatibility with standard LV distribution systems, simplifying procurement and reducing integration risk. Application: Ideal for motor feeders and power distribution networks in automation facilities. Feature: Cable limiter functionality. Business impact: Limits fault energy to protect conductors and connectors, improving system reliability and extend equipment life. Application: Common in cable-limited protection schemes for critical loads. Feature: IEEE Std. C37.41 certification. Business impact: Supports compliance with industry safety and performance standards, easing regulatory audits. Application: Required for mission-critical protection in industrial environments. Feature: Compatibility with Eaton Bussmann series ecosystem. Business impact: Streamlines stocking, sourcing, and maintenance while ensuring cohesive protection strategy. Application: Seamless integration in Eaton-protected automation architectures. Objection handling: While initial cost may be higher, the long-term savings from reduced downtime, safer operations, and easier maintenance justify the investment. This device also provides clear traceability with catalog-number 6DSL-C2000 and standard mounting footprints for straightforward installation.
Get a Quick Quote for a Eaton 6DSL-C2000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-C2000?
Enquire Now
FAQs
The 6DSL-C2000 is designed as part of the Bussmann series cable limiter family and uses standard low-voltage protection footprints. Verify catalog number 6DSL-C2000, 2000 A rating, 600 V rating, and 200 kAIC interrupt capacity. Ensure mounting and enclosure clearance align with the device’s 5.75 in depth and 3.38 in width for proper installation in switchgear or panel feeders.
Key performance specs include a 2000 A amperage rating, 600 V voltage rating, and 200 kAIC interrupt rating. These figures indicate fast fault clearance for high-energy faults, reduced arc energy, and robust protection of feeders and downstream equipment in demanding LV systems.
This cable limiter is ideal for low-voltage distribution in switchgear, motor control centers, and panel feeders. It protects feeder cables against short-circuit events, supports coordinated protection with upstream devices, and helps limit downtime in automation facilities where reliability and safety are critical.
The 6DSL-C2000 carries IEEE Std. C37.41 certification, aligning with established protection standards. This certification supports regulatory compliance, safety assurance, and consistent performance in industrial environments.
Warranty is set according to Eaton policy (1 year from installation or 18 months from shipment, whichever occurs first). The ROI comes from reduced downtime, lower damage risk, and simplified maintenance due to standardization within the Eaton Bussmann series. Investing now can yield safer operations and lower lifecycle costs over time.
