Eaton 6DSL-D3000 Cable Limiter - IEEE Std. C37.41
Part Number: 6DSL-D3000
Quick Summary
The Eaton 6DSL-D3000 cable limiter is a high‑current, low‑voltage fuse designed to protect cables and feeders in industrial power distribution. In demanding electrical cabinets, installers grapple with nuisance trips and slow fault isolation that drive downtime and maintenance costs. The device carries IEEE Std. C37.41 compliance for reliable circuit protection and compatibility with the Eaton Bussmann series line. With a 3000 A rating at 600 V and a 200 kAIC interrupt rating, it delivers decisive fault isolation in high‑energy environments. Its compact footprint and documented specifications support straightforward installation, reduced spare parts, and improved system reliability in industrial wiring and control panels.
Product Information
Extended Description
6DSL-D3000 Eaton: Eaton Bussmann series, Low voltage DSL type current limiting fuse, 3000A, 600V, 200 kA interrupt
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-D3000
UPC
786670249931
Product Length/Depth
5.75 in
Product Height
4.25 in
Product Width
4.25 in
Product Weight
6.4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEEE Std. C37.41
Amperage Rating
3000 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Quantity
1
Special features
Cable limiter
Feature: High amperage rating and fast interrupt capability. Business Impact: Rapid fault interruption protects cables and minimizes downtime, reducing repair costs and extending conductor life. Application: Suitable for switchgear, feeders, and large panels in heavy industrial wiring. Feature: IEEE Std. C37.41 compliance. Business Impact: Ensures reliable protection aligned with industry standards, simplifying regulatory approvals and system certification. Application: Critical power distribution installations that demand proven performance. Feature: Compact, balanced dimensions (5.75 in L × 4.25 in W × 4.25 in H) and 6.4 lb weight. Business Impact: Easier installation in space‑constrained enclosures, faster retrofit projects, and decreased shipping/handling costs. Application: Retrofit and new builds with tight panel clearances. Feature: Cable limiter capability. Business Impact: Limits fault energy to protect cables from insulation damage and reduce arc flash risk. Application: Cable‑run protections in feeders and control panels. Feature: Warranty and lifecycle support. Business Impact: One‑year warranty (or 18 months from shipment) aids total cost of ownership and supplier confidence. Application: Long‑term asset management and preventative maintenance planning.
Get a Quick Quote for a Eaton 6DSL-D3000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-D3000?
Enquire Now
FAQs
The 6DSL-D3000 is designed for low‑voltage power distribution environments up to 600 V, with applications in switchgear, panelboards, and feeders in industrial facilities. Its 5.75 in length and 4.25 in width enable mounting in space‑constrained enclosures, while the 6.4 lb weight supports straightforward handling during retrofit or new installations.
The unit provides a 3000 A amperage rating, a 600 V voltage rating, and a 200 kAIC interrupt rating. Catalog number 6DSL-D3000 and UPC 786670249931 identify the device, which is part of the Eaton Bussmann series and optimized for fast fault isolation in high‑energy circuits.
A cable limiter is a current‑limiting fuse designed to rapidly interrupt fault currents up to 200 kAIC, thereby constraining arc energy and protecting conductors. This reduces insulation damage and downtime compared with less‑capable fuses, making it ideal for protecting large cables in industrial feeders and switchgear assemblies.
Yes, the 6DSL-D3000 carries IEEE Std. C37.41 certification, indicating adherence to established safety and performance criteria for low‑voltage protective devices in power systems. This compliance supports reliable operation in critical installations and assists with regulatory acceptance during audits and inspections.
The product comes with Eaton’s warranty policy: one year from the installation date or eighteen months from shipment, whichever occurs first. This warranty supports maintenance planning and asset reliability, while Eaton’s support resources and datasheets (including the official specification sheet) help address installation questions and long‑term service needs.
