Eaton 6DSL-D3000-Q Cable Limiter - 1.6 kV
Part Number: 6DSL-D3000-Q
Quick Summary
Eaton Bussmann series CDC cable limiter protects low-voltage cable runs by limiting fault current in switchgear and distribution panels. In busy plants, procurement delays and long lead times can stall critical electrical upgrades. Certified to ANSI/IEEE C37.46, C37.40, and C37.48 standards, the device aligns with widely adopted protection requirements for reliable feeder protection. As a Quickship solution, it reduces downtime and speeds commissioning. Its compatibility with Eaton's Wiring & Connectivity portfolio supports seamless integration into existing panels, delivering repeatable performance and easier maintenance for modern industrial facilities.
Product Information
Extended Description
6DSL-D3000-Q Eaton: Eaton Bussmann series, Low voltage current limiter, DSL, 1.6 kV, 3000A, Quickship
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-D3000-Q
UPC
786685882703
Product Length/Depth
7.25 in
Product Height
6.25 in
Product Width
6 in
Product Weight
8.4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
ANSI/IEEE Std C37.46 IEEE Std. C37.40 ANSI/IEEE Std C37.48 ANSI/IEEE Std C37.41 ANSI/IEEE Std C37.48.1 ANSI/IEEE Std C37.47 ANSI/IEEE Std C37.42 IEEE Std. C37.41
Amperage Rating
3000 A
Voltage rating
1.6 kV
Special features
Quickship
High-current protection with a 3000 A rating and 1.6 kV voltage capability provides robust fault-current limiting to guard feeders and switchgear, reducing the risk of arc-flash events and collateral damage. This translates into measurable downtime reduction, lower maintenance costs, and improved overall equipment reliability in critical manufacturing lines and data-center environments. The compact enclosure measures 7.25 in in length, 6 in in width, and 6.25 in in height, with a weight of 8.4 lb, enabling straightforward retrofits in crowded electrical rooms or cabinet enclosures. Certifications aligned to ANSI/IEEE protection standards help streamline compliance during audits and project handovers, while Quickship availability shortens lead times for time-sensitive upgrades. The product’s 1-year warranty (or 18 months from shipment) provides added ROI defense and predictable maintenance budgeting. Compatibility with Eaton Bussmann series components and standard wiring practices ensures easy installation and minimal training requirements for technicians on site.
Get a Quick Quote for a Eaton 6DSL-D3000-Q
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-D3000-Q?
Enquire Now
FAQs
Installation typically involves mounting the device within standard LV panel spaces, verifying enclosure clearance, and connecting to the feeder conductors per the Eaton wiring guidelines. The compact dimensions (7.25 in L × 6 in W × 6.25 in H) and a weight of 8.4 lb facilitate retrofits in crowded cabinets, while the included spec sheet provides torque and termination details to ensure secure, code-compliant connections.
The 6DSL-D3000-Q is designed to comply with a suite of ANSI/IEEE protection standards, including C37.46, C37.40, and C37.48 (with additional C37.x considerations as listed by Eaton). These certifications support reliable protection performance, facilitate regulatory approvals, and align with industry best practices for low-voltage fault-current limiting in distribution systems.
Yes. The device is part of the Eaton Bussmann series and is designed for seamless compatibility with Eaton’s Wiring & Connectivity ecosystem. It supports standard wiring practices, simplifies panel integration, and benefits from shared documentation such as the Eaton specification sheet, which guides installation, safety, and maintenance procedures.
Eaton provides a one-year warranty from the date of installation or eighteen months from shipment, whichever occurs first. This warranty structure helps protect return on investment for uptime-critical applications and supports predictable maintenance budgeting for panels and switchgear upgrades.
Quickship reduces project lead times, accelerating commissioning and minimizing downtime during upgrades. For facilities upgrading feeders or replacing aging protective devices, faster delivery translates to shorter outage windows, faster validation, and improved overall equipment availability, delivering measurable return on investment through reduced downtime and quicker throughput improvements.
