Eaton 6DSL-F5000 Cable Limiter - IEEE C37.41 Certified
Part Number: 6DSL-F5000
Quick Summary
The Eaton 6DSL-F5000 cable limiter protects high-current circuits in industrial power panels and feeders, delivering dependable, code-compliant protection in demanding manufacturing environments. This design reduces nuisance trips and costly downtime by providing precise overcurrent protection for feeders and cable runs, helping maintenance teams keep plant uptime, increase productivity, and improve asset lifecycle costs. IEEE Std. C37.41 compliance supports safe operation in switchgear assemblies; the 200 kAIC interrupt rating and 600 V rating align with rigorous industry standards while delivering robust protection for critical loads. For project teams, this cable limiter delivers measurable business value by simplifying installation, reducing maintenance logs, speeding commissioning, and improving protection of low-voltage circuits across distributed power architectures.
Product Information
Extended Description
6DSL-F5000 Eaton: Eaton Bussmann series, Low voltage DSL type current limiting fuse, 5000A, 600V, 200 kA interrupt
Product Name
Eaton Bussmann series CDC cable limiter
Catalog Number
6DSL-F5000
UPC
786670000600
Product Length/Depth
10.75 in
Product Height
6.25 in
Product Width
6.25 in
Product Weight
9.3 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
IEEE Std. C37.41
Amperage Rating
5000 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Quantity
1
Special features
Cable limiter
Feature: The 5000 A amperage rating with a DSL-type current limiter provides tight overcurrent control for heavy feeders; Impact: reduces conductor damage, minimizes nuisance trips, and lowers maintenance downtime; Application: ideal for industrial panels and distribution enclosures in manufacturing and processing facilities. Feature: 600 V rating paired with a 200 kAIC interrupt capability delivers fast fault interruption in level-appropriate electrical networks; Impact: improves safety, reduces arc energy exposure, and supports compliance with IEEE C37.41; Application: suitable for low-voltage switchgear and cable runs. Feature: The device footprint measures 10.75 in length and 6.25 in square form with a 9.3 lb mass; Impact: simplifies retrofit and field installation in existing cabinets; Application: aligns with standard enclosure designs and reduces mounting complexity. Feature: UPC 786670000600 ensures consistent procurement and asset tracking across sites; Impact: streamlines purchasing, warranty management, and lifecycle cost analysis; Application: supports enterprise-grade maintenance programs and audit readiness. Feature: IEEE Std. C37.41 compliance underscores reliability; Impact: ensures predictability under fault conditions and interoperability with other Bussmann components; Application: critical for utility-scale and manufacturing power protection strategies. Feature: Warranty terms mirror Eaton's service policy; Impact: provides defined coverage windows for budgeting and planning; Application: supports maintenance contracts, risk management, and long-term asset protection. Feature: Field replaceable components and clear installation instructions reduce downtime; Impact: accelerates commissioning and minimizes specialist labor costs; Application: ideal for retrofit projects and spare-part planning in maintenance programs. Feature: Thermal and electrical performance data from the Bussmann series provide design confidence; Impact: enables engineers to model fault scenarios and plan protective coordination; Application: integrates with protection schemes for power distribution architectures. Feature: Clear markups and traceability support auditing and regulatory reporting; Impact: reduces documentation gaps and improves compliance traceability; Application: supports internal audits and external inspections. Feature: Global availability and local support from Eaton guarantee timely assistance; Impact: ensures rapid problem resolution and minimal project delays; Application: ideal for global deployments and multi-site facilities.
Get a Quick Quote for a Eaton 6DSL-F5000
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 6DSL-F5000?
Enquire Now
FAQs
The 6DSL-F5000 cable limiter provides high-current overcurrent protection for feeders and cables in low-voltage power systems. It restricts fault currents to safe levels, preventing insulation damage and equipment trips. Used within Eaton Bussmann series protection schemes, it helps maintain steadier voltages, reduces arc flash risk, and supports fast recovery after faults in manufacturing and process control environments.
Key electrical specs include a 5000 A amperage rating, 600 V voltage rating, and a 200 kAIC interrupt rating. It uses the DSL current-limiting fuse technology from Eaton Bussmann series and carries IEEE Std. C37.41 compliance. The device measures 10.75 inches long by 6.25 inches high and wide, weighing 9.3 pounds, with UPC 786670000600 for traceability.
Yes. The 6DSL-F5000 is part of the Eaton Bussmann series of low-voltage protection devices and uses the CDC cable limiter approach designed to integrate with Bussmann protection schemes in power distribution. It is compatible with standard enclosure layouts and wiring practices for 600 V systems, and the 5000 A current-limiting rating aligns with facility feeder protection strategies.
Best suited for industrial power distribution, feeders, and cable runs within switchgear and panel enclosures, the 6DSL-F5000 delivers reliable protection against overcurrent events. It minimizes damage to cables and insulation, reduces unplanned outages, and supports quick fault isolation. The device is ideal for production lines, process controls, and utility rooms where uptime and safety are critical.
Eaton backs the 6DSL-F5000 with the standard policy, offering a one-year warranty from date of installation or eighteen months from shipment, whichever occurs first. Documentation includes a specification sheet and a short Fuseology video for installation guidance. For service and replacements, refer to Eaton's warranty terms and the official datasheet, ensuring your team can validate compliance and schedule proactive maintenance.
