Eaton 707AF Globe and Guard - IP66
Part Number: 707AF
Quick Summary
The Eaton Crouse-Hinds Pauluhn 707AF globe and guard delivers rugged protection for flush-mount industrial lighting. Facilities struggle with shattered globes and frequent replacements in wet or dusty environments; this design minimizes downtime with a copper-free aluminum guard and durable glass globe. It carries NEC/CEC compliance and IP66 ingress protection, plus ordinary/non-hazardous location rating for broad industrial use. Designed for 300 Vac operation with 2x27W incandescent lamps, it supports cost-efficient, easy-to-maintain lighting in warehouses, plants and control rooms.
Product Information
Extended Description
707AF Eaton: Eaton Crouse-Hinds series Pauluhn 707 industrial globe and guard, Medium base, 2-3/8" box depth, 50/60 Hz, Glass globe, With cast copper-free alum guard, Incandescent, Copper-free aluminum, A-19 max. lamp size, Flush mount, 300 Vac, 100W
Product Name
Eaton Crouse-Hinds series Pauluhn 707 industrial globe and guard
Catalog Number
707AF
UPC
662276385009
Product Length/Depth
7.25 in
Product Height
11 in
Product Width
5.63 in
Product Weight
3.71 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Ingress protection (IP) ratings
IP66
Material
Copper-free aluminum
Mounting Method
Flush
Lamp type
Incandescent
Wattage
2 x 27W
Lamp size - max
A-19
Box depth
2-3/8"
Base type
Medium
Globe material
Glass
Guard type
With cast guard
Guard material
Copper-free aluminum
Voltage rating
300 Vac
Frequency rating
50/60 Hz
Eaton Crouse-Hinds 707AF 3D drawing
Crouse-Hinds series Pauluhn 700 Globe and Guard catalog pages
IF LBL1386 - Pauluhn 707 Flush Mount Incandescent
Eaton Specification Sheet - 707AF
Feature: IP66 protection with glass globe and copper-free aluminum guard. Business Impact: Prevents ingress of dust and water in harsh environments, reducing maintenance costs and extending lamp life. Application: wash-down zones, manufacturing cells, and outdoor-adjacent fixtures. Feature: Medium base, 2x27W incandescent lamps with A-19 max. Business Impact: Uses widely available replacement lamps, simplifying stocking and procurement while keeping lumen output consistent. Application: general-purpose industrial lighting in control rooms, corridors and work cells. Feature: Flush mounting with a compact box depth of 2-3/8 inches. Business Impact: Low-profile installation that eases ceiling layouts and reduces maintenance access complexity. Application: overhead fixtures in tight spaces and service corridors. Feature: Copper-free aluminum guard and durable glass globe. Business Impact: Corrosion resistance and robust protection against physical impacts, lowering replacement cycles in humid or coastal environments. Application: warehouses, process lines and wash-down areas. Feature: NEC/CEC compliance and Ordinary/Non-Hazardous Location rating. Business Impact: Simplifies regulatory approvals, improving project timelines and safety conformance. Application: broad industrial facilities requiring reliable, code-compliant lighting protection. Resource and compatibility note: Includes 3D CAD drawing package, catalog pages, and installation sheets to accelerate procurement and installation in industrial projects.
Get a Quick Quote for a Eaton 707AF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 707AF?
Enquire Now
FAQs
Yes. The 707AF is a flush-mount globe and guard designed for medium-base lamps and compact box depths. It accepts 2x27W incandescent lamps with a maximum size of A-19, operates at 300 Vac, and provides a robust 2-3/8 in box depth clearance. This makes retrofits and new installs straightforward in industrial fixtures.
The 707AF is rated for 300 Vac operation at 50/60 Hz, supporting two 27W incandescent lamps for a total of 54 watts. It uses a medium base and accepts up to A-19 sized lamps, with a 2-3/8 inch box depth to fit standard flush-mount housings. This combination simplifies stocking and compatibility with common replacement lamps.
The 707AF is designed for Ordinary/Non-Hazardous Locations and complies with NEC/CEC standards, making it suitable for warehouses, manufacturing floors, and control rooms. Its IP66 rating protects the globe and guard from dust and water ingress, while the copper-free aluminum guard offers corrosion resistance in humid or wash-down areas.
The 707AF meets NEC/CEC standards and carries an IP66 ingress protection rating. It is intended for Ordinary/Non-Hazardous Locations, supporting reliable operation in standard industrial environments and simplifying regulatory approvals for maintenance teams and project managers.
Installation benefits include flush-mount compatibility with a compact 2-3/8 in depth and standard medium-base lamp access, reducing space constraints. Maintenance advantages come from a durable copper-free aluminum guard and glass globe that resist corrosion and impact, plus downloadable CAD drawings and installation sheets to streamline onboarding and future replacements.
