Eaton 70R-15/100A Telecommunication fuse - CE Marked
Part Number: 70R-15/100A
Quick Summary
The Eaton 70R-15/100A telecommunication fuse protects sensitive telecom lines in cabinets and control panels. Engineers often wrestle with nuisance trips and costly downtime when fuses are mismatched or slow to react. This part carries CE Marked compliance for global markets and is designed for 125 Vac / 300 Vdc applications with a 1 kAIC interrupt rating at 300 Vdc, delivering predictable protection in harsh environments. With ferrule-end connections and a compact form factor, it installs quickly in standard fuse holders while minimizing panel crowding. The 0.15 A rating is tailored for delicate data and signal lines, making it ideal for telecom and industrial control applications that demand reliability and ease of procurement.
Product Information
Extended Description
70R-15/100A Eaton: Eaton Bussmann series 70 Series telecommunication fuse, Color code red/white, 125 Vac, 300 Vdc, 0.15 A, 1 kAIC at 300 Vdc, Non Indicating, Ferrule end X ferrule end
Product Name
Eaton Bussmann series 70 Series telecommunication fuse
Catalog Number
70R-15/100A
UPC
051712736220
Product Length/Depth
1.63 in
Product Height
2.5 in
Product Width
0.42 in
Product Weight
0.5 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
0.15 A
Interrupt rating
1 kAIC at 300 Vdc
Voltage rating
125 Vac, 300 Vdc
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Color code red/white
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - 70R-15/100A
Feature: 0.15 A amperage rating. This precise current protection reduces nuisance trips and safeguards delicate data and signaling lines, minimizing downtime. Application: Ideal for telecom equipment in data cabinets and industrial control panels that demand tight current control. Feature: 1 kAIC interrupt rating at 300 Vdc. High fault current tolerance protects sensitive circuits while maintaining fast, predictable disconnection during overload events. Application: Telecom cabinets and control rails where reliable interruption prevents collateral damage and unplanned outages. Feature: 125 Vac / 300 Vdc voltage rating. Provides versatile protection across AC and DC rails common in telecom and automation environments. Application: Cross-system protection for mixed-signal lines and data interfaces in data centers and equipment racks. Feature: Ferrule end x ferrule end connections. Facilitates quick, secure mechanical mounting in standard fuse holders. Application: Plug-and-play installation in panel boards and equipment housings requiring ferrule terminations. Feature: Color code red/white. Improves field visibility during maintenance and stocking, reducing installation errors. Application: Color-coded kits in high-density panels where fast identification matters. Feature: Non-indicating fuse. Eliminates visual alarms that can mislead technicians during routine checks. Application: Environments where indicator resets are unwanted or confusing for operators. Feature: Compact dimensions and light weight. Length 1.63 in, Width 0.42 in, Height 2.5 in, Weight 0.5 lb. Application: Suitable for crowded enclosures and retrofit projects with limited space. Feature: Compliance and packaging. CE Marked and standard packaging support easy procurement and regulatory alignment. Application: Global deployments in telecom, data centers, and industrial automation where compliance matters.
Get a Quick Quote for a Eaton 70R-15/100A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 70R-15/100A?
Enquire Now
FAQs
The 70R-15/100A uses ferrule-end terminals, which slide into standard ferrule fuse holders. Ensure the holder is rated for 0.15 A, and insert the fuse with the ferrules oriented per manufacturer guidance. No polarity considerations are required for this non-indicating fuse; simply seat it securely to maintain good contact and minimize vibration-related wear.
Electrical ratings include 0.15 A amperage, 125 Vac and 300 Vdc voltage ratings, and a 1 kAIC interrupt rating at 300 Vdc. These specs enable precise overcurrent protection for low-current telecom lines while delivering fast disconnection during overloads, reducing the risk of equipment damage and collateral failures.
Yes, it is designed for telecom and control panel use with a robust interrupt rating and a compact, ferrule-end construction that fits standard panels. While it is CE Marked for global compliance, verify the specific environmental conditions of your enclosure and ensure proper mounting to minimize vibration and thermal stress.
The fuse carries CE Marked compliance, signaling conformity with European and many international standards. This helps streamline procurement for projects requiring regulatory alignment across regions. If additional certifications are needed for your application, consult Eaton literature or your compliance team for device-level verification.
Dimensions are 1.63 in length, 0.42 in width, and 2.5 in height, with a weight of approximately 0.5 lb. It features ferrule-end connections and standard packaging, enabling straightforward integration into compact or dense panels. Plan for adequate clearance around the fuse holder to prevent contact and ensure reliable cooling.
