Eaton 717B7-E1 Industrial Globe and Guard - IP66
Part Number: 717B7-E1
Quick Summary
The Eaton 717B7-E1 Industrial Globe and Guard protects high-output lighting in industrial facilities. Operators struggle with fragile globes, dust ingress, and costly maintenance in harsh environments. It carries IP66 protection for dust ingress and water ingress, NEC/CEC compliance, and ordinary/non-hazardous locations ratings to meet common facility requirements. The design supports ceiling-mount installations with a 1/2" trade size, brass guard, and glass globe, enabling reliable illumination across manufacturing floors. This combination reduces replacement costs, downtime, and risk of fire or exposure, while fitting seamlessly into existing lighting strategies. By pairing robust materials with standard mounting and voltage ratings, it supports scalable, compliant lighting upgrades without sacrificing performance or safety.
Product Information
Extended Description
717B7-E1 Eaton: Eaton Crouse-Hinds series Pauluhn 717 industrial globe and guard, Medium base, 50/60 Hz, Glass globe, With cast brass guard, Incandescent, Brass, A-21 max. lamp size, Ceiling mount, Dead end, 1/2", 300 Vac, 150W
Product Name
Eaton Crouse-Hinds series Pauluhn 717 industrial globe and guard
Catalog Number
717B7-E1
UPC
662276496651
Product Length/Depth
4.5 in
Product Height
9.88 in
Product Width
5.13 in
Product Weight
7 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Ingress protection (IP) ratings
IP66
Material
Brass
Mounting Method
Ceiling
Lamp type
Incandescent
Wattage
150W
Lamp size - max
A-21
Trade size
1/2"
Base type
Medium
Globe material
Glass
Guard type
With cast guard
Guard material
Brass
Voltage rating
300 Vac
Frequency rating
50/60 Hz
Special features
Dead end
Crouse-Hinds series Pauluhn 700 Globe and Guard catalog pages
IF LBL1390 - Pauluhn 717 Incandescent
Eaton Specification Sheet - 717B7-E1
Durable enclosure and protective shield provide reliability in harsh environments. The brass cast guard and glass globe protect the lamp from accidental impacts and dust ingress, while IP66 protection minimizes maintenance needs in wash-down areas and dusty facilities. This combination extends lamp life and reduces unscheduled downtime, keeping production lines up and running. Electrical compatibility and standardization support easy upgrades and stocking: 150 W incandescent capacity, 300 VAC, 50/60 Hz, and a medium base with a 1/2 in trade size. The 717B7-E1 integrates with standard fixtures and Pauluhn 700-series luminaires, enabling quick retrofits without rewiring and helping procurement consolidate components and simplify maintenance inventories. Installation is straightforward for ceiling-mounted installations; lamp replacement is straightforward with a glass globe that can be accessed without disassembly. The dead-end feature reduces stray conductors and improves safety in overhead installations. Compatibility with existing Pauluhn installations accelerates deployment across large facilities and minimizes training requirements. Environment and protection: Brass guard and glass globe resist corrosion and impact in industrial settings. IP66 enclosure helps protect against dust and water ingress, supporting use in mixed-use facilities and wash-down zones while maintaining consistent illumination. Compliance and safety are reinforced by NEC/CEC standards and Ordinary/Non-Hazardous Location ratings, ensuring suitability for regulated environments. The ceiling-mount configuration simplifies wiring changes during upgrades and aligns with typical facility layouts, reducing installation risk and accelerating project timelines. Industry relevance and outcomes: With standard bulbs and easy replacement, maintenance cycles shorten, and downtime decreases, delivering faster ROI. The robust guard-and-globe assembly fits seamlessly into Pauluhn 700-series ecosystems, enabling scalable upgrades and longer service life across warehouses, factories, and distribution centers.
Get a Quick Quote for a Eaton 717B7-E1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 717B7-E1?
Enquire Now
FAQs
Installation is straightforward for ceiling-mount applications. The unit uses a 1/2 in trade size and accepts a medium-base incandescent lamp up to 150 W. Wire the assembly for 300 VAC, 50/60 Hz, and secure the glass globe with the cast brass guard. It’s designed for ordinary/non-hazardous locations, making retrofit work with existing Pauluhn 700 series fixtures efficient.
Key specs include a 150 W incandescent lamp capacity, 300 VAC voltage rating, 50/60 Hz frequency, and a medium base suitable for standard lamps. The globe is glass and is mounted with a brass guard on a ceiling base, and the unit is rated for ordinary/non-hazardous locations with NEC/CEC compliance. This combination ensures predictable performance and ease of replacement.
Best suited for industrial facilities requiring reliable overhead illumination where exposure to dust and moisture is possible but hazards are non-hazardous. The IP66 rating protects against water and dust ingress, while the ceiling-mount design and 1/2" trade size simplify retrofits in warehouses, manufacturing lines, and wash-down areas. It complements standard Pauluhn 700-series luminaires and supports cost-effective upgrades without rewiring.
Compliance focuses on NEC/CEC electrical standards and IP66 ingress protection for non-hazardous environments. The unit is classified for Ordinary/Non-Hazardous Locations and supports ceiling-mount installations with a brass guard and glass globe. These certifications ease procurement for facilities needing formalized compliance, simplify audits, and help ensure safety and reliability across industrial lighting projects.
Maintenance is straightforward: the glass globe and brass guard are designed for easy cleaning and bulb replacement with standard incandescent lamps up to 150 W. By using a common medium-base lamp and a robust guard, replacement cycles extend and downtime decreases. The IP66 enclosure reduces ingress-related maintenance, while compatibility with existing Pauluhn installations supports scalable upgrades without significant wiring changes.
