Eaton 724DC Squeeze Type Connector - NEC/CEC, FMC
Part Number: 724DC
Quick Summary
The Eaton 724DC squeeze type connector enables secure, fast FMC terminations in control panels and equipment housings. Engineers often contend with labor-intensive installs and inconsistent seals in tight panel spaces. This model adheres to NEC/CEC standards and is suitable for ordinary/non-hazardous locations, with UL certification reports available for verification. Its compact 3/8 inch trade size and zinc die-cast construction deliver durable performance while simplifying procurement and field service. The 90° elbow design minimizes bending and routing challenges, helping installers achieve reliable, leak-free connections with reduced commissioning time. By combining robust materials with practical size, the 724DC supports efficient panel wiring across industrial automation projects.
Product Information
Extended Description
724DC Eaton: Eaton Crouse-Hinds series squeeze type connector, FMC, 90° angle, Non-insulated, Zinc die cast, 3/8"
Product Name
Eaton Crouse-Hinds series squeeze type connector
Catalog Number
724DC
UPC
784564003546
Product Length/Depth
1.76 in
Product Height
0.97 in
Product Width
1.1 in
Product Weight
0.08 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
FMC
Style
Squeeze
Material
Zinc die cast
Connector type
90° angle
Insulator
Non-insulated
Trade size
3/8"
Crouse-Hinds series Connectors and Couplings - FMC catalog page
Connectors and Couplings - FMC UL certification
Connectors and Couplings - FMC UL certification
Eaton Specification Sheet - 724DC
Feature: Squeeze-type connection for FMC conduits with a 90° angle and a zinc die-cast, non-insulated body. Business Impact: delivers reliable, vibration-resistant terminations with consistent compression, shortening installation time and minimizing rework. Application: ideal for control panels, machine enclosures, and junction boxes in industrial automation where space is tight and panel density is high. Feature: Compact 3/8" trade size with an overall footprint of 1.76 in length, 0.97 in height, and 1.1 in width; weight 0.08 lb. Business Impact: reduces enclosure fill and wiring clearance requirements, enabling denser panel layouts and easier retrofits. Application: suited for FMC runs in new builds and upgrades across factory automation, packaging lines, and process equipment. Feature: Zinc die-cast construction provides robust mechanical strength and corrosion resistance. Business Impact: improves lifecycle durability in harsh factory environments, lowering maintenance costs and spare-part needs. Application: supports long-term reliability in ordinary locations across general industrial facilities and equipment installations. Feature: NEC/CEC standards alignment and Ordinary/Non-Hazardous Locations area classification. Business Impact: simplifies compliance documentation and customer audits, reducing approval cycles. Application: fits general industrial facilities and panel installations that require code-backed FMC connectivity. Feature: UL certification reports available for FMC connectors; testing documentation included in Eaton's data resources. Business Impact: provides procurement confidence and risk mitigation in regulated markets, enabling fast sourcing and project handoffs. Application: suitable for systems requiring formal safety certification in US and Canada.
Get a Quick Quote for a Eaton 724DC
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 724DC?
Enquire Now
FAQs
Yes. The 724DC is designed for FMC conduits with a 3/8" trade size and uses a squeeze-type termination ideal for 90° routing. For mounting, install directly to enclosure surfaces using standard hardware compatible with zinc die-cast fittings and ensure proper alignment with the FMC run to maintain a tight seal and reliable electrical performance.
The connector measures 1.76 inches in length, 0.97 inches in height, and 1.1 inches in width, with a weight of 0.08 pounds. These compact dimensions minimize enclosure fill and simplify cable routing, enabling denser panel layouts and easier retrofits without compromising strength or reliability.
The 724DC is ideal for control panels, junction boxes, and machinery housings in ordinary/non-hazardous locations. It leverages a 90° squeeze connection for efficient routing in FMC conduit runs, delivering robust terminations suitable for general industrial automation environments.
The 724DC aligns with NEC/CEC standards and is intended for Ordinary/Non-Hazardous locations. UL certification reports for FMC connectors are available through Eaton’s documentation, providing formal verification of safety and compliance for your project audits and customer requirements.
Constructed from zinc die cast and designed for a secure 90° termination, the 724DC delivers durable, vibration-resistant terminations with reduced field rework. This translates to lower maintenance costs, shorter installation times, and quicker project handoffs, improving total cost of ownership in automation projects.
