Eaton 742DC Squeeze Type Connector - FMC, 90°
Part Number: 742DC
Quick Summary
The Eaton 742DC squeeze type connector provides reliable FMC conduit connections for 2-inch trade-sized runs in industrial facilities. Its 90° angle and rugged zinc die-cast body simplify installation in confined electrical cabinets, reducing misalignment and field repair time. This connector is designed for ordinary/non-hazardous locations and adheres to NEC/CEC standards, with validated Canadian certifications for cross-border use. For businesses, this translates to faster, compliant installations and reduced risk in FMC wiring harnesses. Designed for FMC connectors and Crouse-Hinds series applications, it supports scalable panel layouts and cost-effective maintenance. With catalogued specs such as 2" trade size, 5.4 in length, and 4.41 in height, spec compliance is straightforward during procurement.
Product Information
Extended Description
742DC Eaton: Eaton Crouse-Hinds series squeeze type connector, FMC, 90° angle, Non-insulated, Zinc die cast, 2"
Product Name
Eaton Crouse-Hinds series squeeze type connector
Catalog Number
742DC
UPC
784564003607
Product Length/Depth
5.4 in
Product Height
4.41 in
Product Width
4.82 in
Product Weight
1.19 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
FMC
Style
Squeeze
Material
Zinc die cast
Connector type
90° angle
Insulator
Non-insulated
Trade size
2"
Crouse-Hinds series Connectors and Couplings - FMC catalog page
Connectors and Couplings - FMC Canadian certification
Connectors and Couplings - FMC Canadian certification
Eaton Specification Sheet - 742DC
Feature — Squeeze-type connector within the Crouse-Hinds FMC family, featuring a 2" trade size, 90° angle, non-insulated zinc die-cast body. Business Impact — Enables fast, precise assembly with reduced torque variability and fewer reworks, accelerating project timelines. Application — Ideal for panel-mounted FMC conduit runs in electrical rooms and equipment skids where space is constrained. Feature — Durable zinc die-cast construction with defined dimensions (5.4 in length, 4.82 in width, 4.41 in height) and weight of 1.19 lb. Business Impact — Delivers predictable fitment, simplified layout planning, and straightforward inventory management. Application — Supports repeatable installations across multi-rack automation setups and OEM equipment. Feature — Non-insulated, 90° design for tight bends and compact routing. Business Impact — Reduces part count while easing cable management in tight cabinets, cutting labor costs and installation time. Application — Common in control panels where enclosure depth is limited and routing flexibility is required. Feature — NEC/CEC compliance for ordinary locations with corroborating Canadian certifications. Business Impact — Ensures regulatory conformity, reduces risk of non-compliance, and eases cross-border procurement. Application — Suitable for facilities subject to NEC/CEC and Canadian certification requirements. Feature — Accessible catalogs and official datasheets (Eaton spec sheet and FMC catalog page). Business Impact — Speeds up design-to-procurement workflows, enabling quick validation against project specs. Application — Useful for engineering teams handling FMC connectors in large-scale automation projects.
Get a Quick Quote for a Eaton 742DC
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 742DC?
Enquire Now
FAQs
The 742DC is a 2" trade-size FMC squeeze-type connector with a 90° zinc die-cast body and non-insulated construction. For installation, ensure clean, aligned joints in control panels and equipment enclosures, tighten to manufacturer-recommended torque, and route conduits to minimize bending stress. Its design supports fast field assembly and reliable long-term performance in ordinary locations.
The 742DC is designed for ordinary/non-hazardous locations in accordance with NEC/CEC standards, providing NEC/CEC-compliant connections for common industrial environments. This compliance simplifies regulatory acceptance across many facilities and aligns with typical FMC installation practices, reducing the need for alternative fittings in non-hazardous areas.
Canadian certification support for the 742DC complements NEC/CEC compliance, enabling cross-border FMC installations. The product is documented with Canadian certification references, which helps ensure regulatory acceptance in Canadian facilities and simplifies sourcing for multinational projects that require compliance across jurisdictions.
Key specs to consider are 2" trade size, 5.4 in length, 4.82 in width, and 4.41 in height, with a weight of 1.19 lb. The conduit type is FMC, and the part is a non-insulated, 90° squeeze-style connector suitable for 2" FMC runs in cable trays or control panels, ensuring proper clearance and routing.
The 742DC addresses space constraints with its 90° angle, simplifying tight-turn FMC installations. Its zinc die-cast construction offers durability and corrosion resistance in ordinary environments, reducing maintenance needs. Non-insulated design and standardized dimensions aid quick assembly and consistent panel layouts, lowering labor costs while maintaining regulatory compliance.
