Eaton 746DC Squeeze Type Connector - FMC 90° Zinc Die-Cast
Part Number: 746DC
Quick Summary
The Eaton 746DC Squeeze Type Connector provides secure FMC terminations for 3-1/2\" trade-size cables in panel and cabinet work. Engineers often struggle to maintain reliable, quick-connect terminations in crowded enclosures or on FMC conduits. It meets NEC/CEC requirements for Ordinary/Non-Hazardous Locations, and its zinc die-cast, non-insulated body delivers durable service in demanding environments. With a 90° squeeze design and a compact footprint, installation is faster and more repeatable, while preserving seal integrity in FMC conduit systems. This combination supports streamlined panel-building projects and reduces field rework, delivering measurable time savings on installation crews and maintenance teams.
Product Information
Extended Description
746DC Eaton: Eaton Crouse-Hinds series squeeze type connector, FMC, 90° angle, Non-insulated, Zinc die cast, 3-1/2"
Product Name
Eaton Crouse-Hinds series squeeze type connector
Catalog Number
746DC
UPC
784564003638
Product Length/Depth
10 in
Product Height
7.75 in
Product Width
4.75 in
Product Weight
5.6 lb
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Conduit type
FMC
Style
Squeeze
Material
Zinc die cast
Connector type
90° angle
Insulator
Non-insulated
Trade size
3-1/2"
Crouse-Hinds series Connectors and Couplings - FMC catalog page
Connectors and Couplings - FMC Canadian certification
Connectors and Couplings - FMC Canadian certification
Eaton Specification Sheet - 746DC
Feature: Squeeze-type connector design provides a secure FMC termination with consistent compression. Business Impact: Reduces field variance and rework, speeding up panel assembly. Application: Ideal for 3-1/2\" trade-size FMC runs in control panels and enclosures. Paragraph two: Feature: Zinc die-cast body delivers rugged durability and corrosion resistance. Business Impact: Longer service life lowers replacement and maintenance costs. Application: Suitable for ordinary/non-hazardous locations inside enclosures. Paragraph three: Feature: 90° angle with a 10 in length and 4.75 in width, 7.75 in height, and 5.6 lb weight supports tight routing. Business Impact: Compact geometry improves space efficiency and reduces enclosure footprint. Application: Installation in constrained FMC conduit paths within panels. Paragraph four: Feature: NEC/CEC compliance ensures regulatory alignment. Business Impact: Accelerates approvals and reduces validation effort. Application: Standard FMC conduit systems in industrial plants. Paragraph five: Feature: Non-insulated design simplifies installation and inspection in standard enclosures. Business Impact: Fewer insulation steps, faster commissioning, and easier stock management. Application: Panel and junction-box installations using Crouse-Hinds FMC fittings.
Get a Quick Quote for a Eaton 746DC
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 746DC?
Enquire Now
FAQs
Begin by confirming the 3-1/2" trade-size conductors match the 746DC’s inlet, then align the 90° elbow with the FMC conduit path. Secure the squeeze-type clamp using the recommended hardware, ensuring the conduit sits fully seated in the zinc die-cast body. Verify alignment and seal integrity, and test continuity after mounting in the panel location. The 10" length helps maintain a clean, organized routing in standard enclosures.
Key specifications include conduit type FMC, style Squeeze, 3-1/2" trade size, 90° connector angle, non-insulated insulator, and zinc die-cast material. The unit weighs 5.6 lb and measures 10 in L x 7.75 in H x 4.75 in W, providing a robust mechanical fit for tight spaces and reliable compression for long-term sealing in ordinary locations.
Yes. The 746DC is designed for Ordinary/Non-Hazardous Locations per NEC/CEC standards, making it suitable for typical industrial control panels, switchgear cabinets, and other non-hazardous FMC conduit installations where durable, code-compliant terminations are required.
The connector complies with NEC/CEC standards for ordinary locations. It is a non-insulated, zinc die-cast 90° FMC squeeze connector designed to meet standard wiring and building codes for non-hazardous environments, supporting reliable installations in panel assemblies and junction boxes.
The squeeze-type design enables faster terminations with fewer field adjustments, reducing labor time during panel builds and retrofits. Its durable zinc die-cast construction lowers replacement frequency, while the 90° configuration simplifies routing in confined spaces, delivering improved reliability and a lower total cost of ownership over the life of the installation.
