Eaton 75413MVF3 LV Unipak capacitor bank - NEMA 1, 3R
Part Number: 75413MVF3
Quick Summary
The Eaton LV Unipak capacitor bank is designed to stabilize voltage and improve power factor in industrial electrical systems. It helps address voltage sags and rising energy costs that challenge uptime and efficiency in demanding manufacturing environments. With rugged NEMA-rated enclosures and a durable baked-on enamel finish, this unit stands up to harsh plant conditions. Configured as three-phase, 4160 V, 75 kVAR with three-fuse protection, it delivers reliable reactive-power management for large facilities. Its viewing window, top and side entry, and removable front cover simplify maintenance and status checks, supporting faster diagnostics and reduced downtime while aligning with modern facility optimization programs.
Product Information
Extended Description
75413MVF3 Eaton: Eaton LV Unipak capacitor bank, 4160V, Three-phase, 75 kVAR, Three-fuse, NEMA 1, 3R, and 12, 14 ga. steel finished with durable baked-on enamel, Viewing window, top and side entry, removable front cover
Product Name
Eaton LV Unipak capacitor bank
Catalog Number
75413MVF3
UPC
786685240565
Product Length/Depth
20.42 in
Product Height
34.44 in
Product Width
20.26 in
Product Weight
70 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Catalog Notes
The wiring enclosure is gasketed to create a weatherproof, dustproof seal. Universal mounting flanges are provided for floor installation. The elimation of knockouts permits indoor/outdoor use.
Type
UNIVAR XV
Fuse type
Three-fuse
Options
Viewing window, top and side entry, removable front cover
Phase
Three-phase
Product Category
Fixed Capacitor Banks
Voltage rating
4160 V
Enclosure
NEMA 1, NEMA 3R, NEMA, NEMA 12
Enclosure material
14 gauge steel finished with durable baked-on enamel
Rating
75 kVAR
Feature → Business Impact → Application: Three-phase, 4160 V configuration delivers consistent voltage support and effective reactive power management, reducing energy penalties and motor wear in high-demand production lines; Application: large industrial motors and pumps benefit from steadier voltage and improved efficiency. Feature → Business Impact → Application: 75 kVAR rating provides substantial power-factor correction, lowering utility charges and improving process stability; Application: steel, chemical, and food processing facilities that run heavy inductive loads. Feature → Business Impact → Application: Three-fuse protection enhances fault safety and minimizes unplanned outages; Application: critical process lines where reliability is non-negotiable. Feature → Business Impact → Application: Gasketed weatherproof/dustproof enclosure (NEMA 1, 3R, 12) enables indoor/outdoor installation in varying environments; Application: outdoor switchgear areas and harsh factory floors. Feature → Business Impact → Application: Viewing window and removable front cover simplify inspections and maintenance scheduling; Application: facilities pursuing reduced downtime and faster asset turnover. Feature → Business Impact → Application: 14-gauge steel enclosure with baked-on enamel delivers durable protection against corrosion; Application: long-term installation in challenging industrial settings. Feature → Business Impact → Application: Universal mounting flanges support flexible floor mounting; Application: retrofits and new installations where space and orientation vary.
Get a Quick Quote for a Eaton 75413MVF3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton 75413MVF3?
Enquire Now
FAQs
For proper fit, verify floor space for a floor-mounted unit and ensure the chosen location supports indoor or outdoor exposure given the NEMA 1, 3R, and 12 enclosure ratings. Use universal mounting flanges and plan top or side wiring entries. Confirm access for the viewing window and removable front cover during routine maintenance.
The 75413MVF3 is a three-phase, 4160 V fixed capacitor bank rated at 75 kVAR with three-fuse protection. It uses a UNIVAR XV design and provides a 20.42 in depth, 34.44 in height, 20.26 in width footprint and weighs approximately 70 lb, suitable for large industrial systems requiring robust reactive power management.
Yes. The enclosure supports indoor/outdoor use through NEMA-rated protection, including NEMA 1, NEMA 3R, and NEMA 12 configurations, along with a gasketed weatherproof and dustproof seal. The durable 14-gauge steel with baked-on enamel finish further enhances corrosion resistance in challenging environments.
A 75 kVAR capacitor bank provides substantial power-factor correction, reducing reactive power drawn from the grid. This lowers utility penalties, improves voltage stability, and can enhance motor efficiency and uptime. It is particularly beneficial in facilities with heavy inductive loads such as pumps, conveyors, and large motors.
The unit is covered under Eaton Selling Policy 25-000, with a one-year warranty from the date of installation or eighteen months from shipment, whichever occurs first. This support includes standard manufacturer assistance, replacement considerations, and access to Eaton’s technical resources for installation and maintenance guidance.
