Eaton 775243MVF3C LV Unipak capacitor bank - IEEE Std. 18
Part Number: 775243MVF3C
Quick Summary
Eaton LV Unipak capacitor bank provides reactive power support for three-phase industrial electrical systems. Facilities often struggle with poor power factor, leading to higher energy costs and motor wear. CSA Certified (Canada Only) and IEEE Std. 18 compliance help ensure safety and reliability in North American installations. This solution supports reliable power quality, aligns with industry standards, and delivers value through a compact, install-ready footprint that simplifies procurement and installation for engineering teams and maintenance personnel. By correcting PF, it reduces utility penalties and improves uptime, supporting production targets while delivering predictable total cost of ownership and easier budgeting for upgrades across plant-wide distribution.
Product Information
Extended Description
775243MVF3C Eaton: Eaton 775 KVAR 2400V 3PH FIXED 3 FUSES CSA
Product Name
Eaton LV Unipak capacitor bank
Catalog Number
775243MVF3C
UPC
786685235721
Product Length/Depth
20.42 in
Product Height
41.94 in
Product Width
26.68 in
Product Weight
307 lb
Certifications
CSA Certified (Canada Only) IEEE Std. 18
Phase
Three-phase
Feature: Three-phase LV Unipak capacitor bank rated for 2400V and 775 kVAR with a fixed 3-fuse configuration. Business Impact: Delivers robust reactive power support that improves power factor, reduces current in feeders, and lowers utility demand charges. Application: Ideal for motor-driven loads in manufacturing and processing facilities seeking energy efficiency and cost savings. Feature: Compact footprint and rugged enclosure with dimensions 20.42 in L × 26.68 in W × 41.94 in H and weight 307 lb. Business Impact: Easier field mounting, improved service access, and space savings in crowded switchgear rooms. Application: Retrofit projects and upgrades in existing LV distributions. Feature: Certifications include CSA Certified (Canada Only) and IEEE Std. 18. Business Impact: Enhances safety compliance and accelerates approvals for North American installations. Application: Projects with strict regulatory requirements and quality benchmarks. Feature: Compatibility with standard LV distribution and switchgear. Business Impact: Simplifies integration with existing infrastructure, reducing engineering effort and installation time. Application: Plant-wide power quality improvement across industrial facilities. Feature: Documentation and data sheet availability (Eaton Specification Sheet for 775243MVF3C). Business Impact: Streamlines procurement, reduces misinterpretation, and supports commissioning with clear reference material. Application: Engineering workflows and maintenance planning for reliable operation.
