Eaton 864-4XSCHC JIC Panel Enclosure - NEMA 4X
Part Number: 864-4XSCHC
Quick Summary
The Eaton 864-4XSCHC JIC panel enclosure protects electrical components in compact industrial control panels. In tight installations, space constraints and harsh washdown environments can drive downtime and maintenance costs. It carries UL 50, CSA C22.2, and NEMA 4X ratings, signaling robust protection for dust, moisture, and corrosive exposure. Built from 304 stainless steel with a 16-gauge wall and a seamless gasket, it delivers reliable corrosion resistance and a smooth finish. With wall mounting and external feet, it simplifies installation and reduces mounting time. This stainless steel enclosure is ideal for food processing, packaging, and OEM machinery, offering durable protection without sacrificing accessibility or serviceability.
Product Information
Extended Description
864-4XSCHC Eaton: Eaton B-Line series JIC panel enclosure, 8" height, 4" length, 6" width, NEMA 4X, Hinged cover, 4XSCHC enclosure, Wall mount, Small single door, External mounting feet, 304 stainless steel, Seamless poured in-place gasket
Product Name
Eaton B-Line series JIC panel enclosure
Catalog Number
864-4XSCHC
UPC
782051702941
Product Length/Depth
4 in
Product Height
8 in
Product Width
6 in
Product Weight
4.7 lb
Certifications
UL 50 CSA C22.2. NEMA
Material
304 stainless steel
Wall thickness
16 gauge
Finish color
#4 brushed
Color
Gray
Style
Small single door
Model
4XSCHC enclosure
Cover type
Hinged
Mounting method
Wall
Mounting hole details
External mounting feet
Closure type
Hinged
Special features
Cont. piano hinge,panel mount prov.,s.s.doorclamps
NEMA Rating
4X
Country of origin
US
304 stainless steel construction delivers superior corrosion resistance, extending service life in washdown environments and reducing maintenance costs for food processing, packaging lines, and beverage applications. The 8 x 6 x 4 inch footprint provides a compact enclosure suitable for space-constrained control panels, improving layout efficiency and enabling faster installation in cramped electrical rooms. The NEMA 4X rating together with UL 50 and CSA C22.2 certifications ensures reliable protection from dust, water spray, and corrosion, supporting safer operation in harsh production areas and outdoor installations. The hinged cover with a continuous piano hinge and door clamps delivers easy, repeated access for fast commissioning and routine servicing, minimizing downtime during maintenance cycles. External mounting feet and wall-mount capability streamline installation, reducing field mounting time and enabling compatibility with standard panel hardware in varied environments. The seamless gasket and 304 stainless steel finish provide a robust, easy-to-clean enclosure suitable for critical control panels and equipment housings.
