Eaton AC-20C30SS Consolet Enclosures - NEMA 12
Part Number: AC-20C30SS
Quick Summary
Eaton AC-20C30SS Consolet Enclosures are rugged stainless steel housings designed to protect electrical controls in harsh industrial environments. In process facilities, corrosion, dust ingress, and downtime from poorly sealed enclosures drive maintenance costs and safety risks. They carry UL 508A and CSA C22.2 certifications, and a NEMA 12 rating that suits dusty, non-hazardous liquid scenarios. With surface mounting, external feet, and a 20 x 30 x 13.12 inch footprint, you get quick installation and long-term reliability for critical control gear.
Product Information
Extended Description
AC-20C30SS Eaton: Eaton B-Line series consolet enclosures, 20" height, 13.12" length, 30" width, NEMA 12, Screw cover, ACSS concolet, Surface mounted, Medium single door, External mounting feet, 304 stainless steel, Oil-resistant gasket
Product Name
Eaton B-Line series consolet enclosures
Catalog Number
AC-20C30SS
UPC
782051147605
Product Length/Depth
13.12 in
Product Height
20 in
Product Width
30 in
Product Weight
43.5 lb
Certifications
UL 508A CSA C22.2. NEMA
Material
304 stainless steel
Wall thickness
14 gauge
Finish color
#4 brushed
Color
Gray
Style
Medium single door
Model
ACSS consolet
Cover type
Screw
Mounting method
Surface
Mounting hole details
External mounting feet
Closure type
Continous hinge
Special features
Stainless screws
NEMA Rating
12
Country of origin
US
Material and finish deliver durable corrosion resistance: crafted from 304 stainless steel with a 14 gauge wall and a #4 brushed finish, the AC-20C30SS reduces maintenance costs and extends service life in washdown and corrosive environments, enabling reliable control panel protection in chemical, oil, and food processing facilities. The enclosure dimensions—20 in high, 30 in wide, and 13.12 in deep—provide ample space for standard control components while maintaining a compact footprint that simplifies retrofit and upgrades. A screw cover, continuous hinge, external mounting feet, and stainless screws speed access and serviceability, lowering downtime during maintenance cycles and inspections. UL 508A and CSA C22.2 compliance, paired with a NEMA 12 rating, ensure regulatory alignment and safer operation across industries. Designed for surface installation, this model supports seamless integration with ACSS consolet configurations, boosting installation efficiency and long-term reliability.
Get a Quick Quote for a Eaton AC-20C30SS
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton AC-20C30SS?
Enquire Now
FAQs
Install using the surface mounting feet provided; ensure the exterior is clean and gasket seals are undamaged. The 20x30x13.12 inch footprint accommodates standard control panels, and the screw cover with continuous hinge allows quick access during maintenance without compromising the enclosure seal.
This model carries UL 508A and CSA C22.2 certifications and a NEMA 12 rating, confirming electrical safety and protection against dust and non-hazardous liquid ingress in industrial environments.
The 304 stainless steel construction and oil-resistant gasket provide excellent corrosion resistance, making it well suited for many washdown and corrosive zones. For full washdown duty, verify that NEMA 12 coverage meets your process requirements and consider higher protection ratings if needed.
The enclosure measures 20 in in height, 30 in in width, and 13.12 in in depth, with a weight of approximately 43.5 lb, supporting a balance of durability and manageable handling during installation.
Yes, it is designed to pair with ACSS consolet configurations. Surface mounting with external feet provides flexible installation, while the screw cover and continuous hinge facilitate access to installed components and wiring for routine maintenance.
