Eaton ACK-10 Fuse - Time-Delay DC, Stud-Mounted 130 Vdc
Part Number: ACK-10
Quick Summary
ACK-10 fuse is a time-delay DC protector designed for forklift battery chargers and other DC circuits. This helps prevent nuisance trips while protecting power systems in demanding industrial environments. While the datasheet does not list specific certifications, CE and UL marks are commonly sought for industrial DC protection—confirm the exact Eaton approvals for your application. The ACK-10 supports reliable protection in fleet charging and materials handling operations, with a compact, stud-mounted design that simplifies retrofits and new installations. Use this fuse to balance protection, uptime, and cost efficiency in your DC distribution strategy, keeping critical equipment safeguarded with a proven Eaton Bussmann solution.
Product Information
Extended Description
ACK-10 Eaton: Eaton Bussmann series ACK fuse, Time-delay stud-mounted fuse, DC circuits protection for fork lift truck and battery chargers, 10 A, Dual, Non-indicating, 100 sec at 200%, 35 sec 300%, 13 sec at 500%, Stud, Standard, 130 Vdc
Product Name
Eaton Bussmann series ACK fuse
Catalog Number
ACK-10
UPC
051712701259
Product Length/Depth
2.5 in
Product Height
0.56 in
Product Width
0.56 in
Product Weight
0.5 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
10 A
Response time
100 sec at 200%, 35 sec 300%, 13 sec at 500%
Voltage rating
130 Vdc
Number of elements
Dual
Packaging type
Standard
Fuse indicator
Non-indicating
Mounting method
Stud
Special features
One time fuse
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - ACK-10
Feature → Business Impact → Application: Time-delay design reduces nuisance trips during inrush or brief overload events, improving uptime for forklift chargers and DC motors. This translates to fewer production interrupts and lower maintenance costs in material handling facilities. Feature → Business Impact → Application: 10 A rating with 130 Vdc capability provides targeted protection for compact DC power circuits, enabling safer operation of battery charging hardware in compact spaces such as warehouse fleets. Feature → Business Impact → Application: Dual-element construction enhances reliability in high-current scenarios common in forklift charging stations, supporting continuous operation of multiple lines in a battery room. Feature → Business Impact → Application: Stud mounting simplifies retrofit and field installation on existing bussing or terminal blocks, reducing installation time and labor costs in industrial automation projects. Feature → Business Impact → Application: Time-to-protect metrics (100 sec at 200%, 35 sec at 300%, 13 sec at 500%) give engineers clear fuse curves to size protection precisely, minimizing downstream damage and improving overall system availability. Feature → Business Impact → Application: Non-indicating, standard-packaging fuse minimizes unnecessary indicators while offering a straightforward, low-maintenance solution for OEMs and service teams deploying DC protection across forklift charging infrastructure and battery chargers. Feature → Business Impact → Application: One-time fuse characteristic ensures predictable replacement cycles and clear fault isolation in fleet management, supporting predictable maintenance planning and uptime guarantees for industrial customers.
Get a Quick Quote for a Eaton ACK-10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton ACK-10?
Enquire Now
FAQs
Yes. The ACK-10 is specified for 130 Vdc operation and uses a stud-mounted, dual-element design ideal for forklift battery charging circuits. Always verify your charger’s current and duty cycle align with the 10 A rating and the fuse’s time-delay curve.
The ACK-10 provides a time-delay protection with response characteristics of approximately 100 seconds at 200%, 35 seconds at 300%, and 13 seconds at 500% overload. This helps tolerate inrush during startup while still protecting the circuit from sustained faults.
Yes. The device is described as dual elements, supporting protective needs across two circuits or redundant pathways within a DC distribution setup. Ensure correct separation and wiring per your harness design and safety standards.
The provided data notes no explicit compliance marks. In practice, industrial fuses commonly require CE, UL, or UL/CSA verification depending on region and application. Confirm Eaton’s official specification sheet for the exact certifications on your batch and guarantee compliance for forklift or charger installations.
The ACK-10 is a one-time fuse with non-indicating status, meaning you should plan visual or electrical verification during maintenance to confirm fuse health. Its compact form and straightforward replacement support low downtime and predictable maintenance costs, contributing to a favorable total cost of ownership for fleet charging and DC protection in industrial settings.
