Eaton ACK-30 Fuse - Time-delay DC Stud Fuse 130 Vdc
Part Number: ACK-30
Quick Summary
ACK-30 is a time-delay DC stud fuse designed for forklift DC circuits and battery charging applications. It delivers reliable overcurrent protection while minimizing nuisance trips during transient inrush events. In practice, engineers seek protective devices that combine fast response to severe faults with tolerance to normal motor and charger inrush, reducing downtime. While this Eaton Bussmann series device is built for rugged DC protection, verify regional compliance and datasheet guidance for your specific installation. This model delivers a compact, easy-to-install solution that pairs with standard stud mounts and supports efficient inventory management for maintenance teams.
Product Information
Extended Description
ACK-30 Eaton: Eaton Bussmann series ACK fuse, Time-delay stud-mounted fuse, DC circuits protection for fork lift truck and battery chargers, 30 A, Dual, Non-indicating, 100 sec at 200%, 35 sec 300%, 13 sec at 500%, Stud, Standard, 130 Vdc
Product Name
Eaton Bussmann series ACK fuse
Catalog Number
ACK-30
UPC
051712701297
EAN
5027590056021
Product Length/Depth
2.5 in
Product Height
0.81 in
Product Width
0.81 in
Product Weight
0.55 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
30 A
Response time
100 sec at 200%, 35 sec 300%, 13 sec at 500%
Voltage rating
130 Vdc
Number of elements
Dual
Packaging type
Standard
Fuse indicator
Non-indicating
Mounting method
Stud
Special features
One time fuse
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - ACK-30
