Eaton AHCL830FO Locking Flanged Outlet - L8-30, 480V
Part Number: AHCL830FO
Quick Summary
Eaton Arrow Hart color coded locking outlet provides a secure, color-coded power connection for industrial equipment in harsh environments. Maintenance teams often wrestle with mis-wiring and accidental unplugging that cause unplanned downtime and safety risks. This solution carries RoHS compliance and cULus Listed NOM certifications, delivering regulatory confidence and safer operation in regulated environments. Designed for 480V industrial systems, it features a nylon body with Ultra grip and back-wiring compatibility to support L8-30 two-pole, three-wire configurations. By standardizing color codes and locking connections, it reduces wiring errors, accelerates panel assembly, and simplifies preventive maintenance, delivering measurable value in uptime, safety, and total cost of ownership for plant floors.
Product Information
Extended Description
AHCL830FO Eaton: Eaton Arrow Hart Color Coded Locking Flanged Outlet, #14-8 AWG, 30A, Industrial, 480V, Back, Red, Black, Ultra grip, Nylon, L8-30, Two-pole, Three-wire, Nylon, -40°C (w/o impact) to 60°C (-40°F to 140°F)
Product Name
Eaton Arrow Hart Color Coded Locking Flanged Outlet
Catalog Number
AHCL830FO
UPC
032664760518
Product Length/Depth
3.8 in
Product Height
2.24 in
Product Width
3 in
Product Weight
0.01 lb
Compliances
RoHS Compliant
Certifications
cULus Listed NOM
Special features
Voltage Color Coding
Type
Locking Flanged Outlet
Amperage Rating
30A
Voltage rating
480 V
Application
Industrial
Wiring method
Back
Number of wires
3
Number Of Poles
Two-pole
Color
Black Red
Material
Nylon
Operating temperature
-40 to 60 °C (-40 to 140 °F)
Allowable wire size
#14-8 AWG
NEMA configuration
L8-30
Torque rating
For #10-14 AWG: 14-16 lbf-inch. For #8 AWG: 20 lbf-inch
Design type
Ultra grip
Face/body material
Nylon
Eaton Arrow Hart color coded locking devices
Eaton Specification Sheet - AHCL830FO
Eaton Specification Sheet - AHCL830FO
Feature: Color-coded voltage coding and Ultra grip nylon housing. Business Impact: Reduces mis-wiring and accidental disconnections, speeding up panel assembly and maintenance. Application: Ideal for industrial control panels and machine feeds where color-coded locking devices improve safety and traceability. Feature: 30A at 480V with L8-30 two-pole, three-wire configuration. Business Impact: Supports high-demand equipment and robust power distribution with reliable current handling. Application: Suitable for heavy machinery, conveyors, and automated lines in manufacturing environments. Feature: Back wiring method with nylon face/body. Business Impact: Simplifies field termination and enhances vibration resistance, lowering installation time and technician fatigue. Application: Common in control cabinets and distributed power blocks across industrial facilities. Feature: Nylon construction and operating range -40 to 60 °C. Business Impact: Delivers durable performance in extreme temperatures and harsh environments, reducing replacement cycles. Application: Industrial plants, outdoor facilities, and cold/heat zones. Feature: RoHS compliant and cULus Listed NOM certifications. Business Impact: Ensures regulatory compliance and safer operation, easing procurement and end-user validation. Application: Regulated industries and projects requiring certified locking devices and color-coded outlets.
