Eaton AHMC240L-1 Manual Motor Controller - cULus Listed
Part Number: AHMC240L-1
Quick Summary
The Eaton AHMC240L-1 manual motor controller enables reliable motor control for industrial panel setups. Operators often face wiring errors and downtime during switch operations, especially in rugged environments where miswiring can stall production. This unit carries cULus Listed certification and NAFTA compliance, with a stainless steel NEMA 1 enclosure designed for harsh industrial conditions. Designed for 40A at 600V in single-phase service, it uses side-wired box lug terminals and a maintained two-position toggle to simplify installation, reduce field wiring mistakes, and improve serviceability. With a compact footprint and compatible copper-alloy terminals, it delivers dependable panel control while supporting efficiency goals and regulatory alignment in OEM and maintenance operations.
Product Information
Extended Description
AHMC240L-1 Eaton: Eaton manual motor controller, #14-4 AWG, 40A, Panel, 600V, Side wired box lug, Maintained contact, Gray, NEMA Type 1, Enclosure: SS, Two-pole, Two-position, Single-phase, Toggle, Copper-alloy terminal, Single-throw, Glass-filled nylon
Product Name
Eaton manual motor controller
Catalog Number
AHMC240L-1
UPC
040893653921
Product Length/Depth
9.2 in
Product Height
5.9 in
Product Width
7.2 in
Product Weight
1.23 lb
Compliances
NAFTA
Certifications
cULus Listed
Enclosure
NEMA 1
Type
Manual motor controller
Amperage Rating
40A
Voltage rating
600 V
Number Of Poles
Two-pole
Phase
Single-phase
Enclosure material
Stainless steel
Application
Industrial
Device grade
Industrial
Wiring method
Side wired box lug
Contact type
Maintained
NEMA Rating
1
Switch type
Toggle switch
Mounting method
Panel
Closure type
Maintained
Number of positions
2
Allowable wire size
#14-4 AWG
Material
Glass-filled nylon
Termination style
Side wired box lug
Throw
Single-throw
Terminals
Copper-alloy, brass screw
Color
Gray
Feature 40A at 600V and two-pole single-phase operation enable dependable switching for common industrial motors. This translates to measurable business impact: robust motor control with predictable torque and safer start/stop sequences, reducing unplanned downtime. Application: ideal for panel-mounted motor control in conveyors, pumps, and processing equipment. Feature Stainless steel NEMA 1 enclosure enhances durability and protection against dirt, moisture, and corrosion. Impact: improved reliability of control circuits in harsh factory environments, lowering maintenance costs and extending panel life. Application: manufacturing lines, packaging equipment, and machine control panels. Feature Side wired box lug wiring method and compatibility with #14-4 AWG conductors simplifies field wiring and reduces miswiring risk. Impact: faster installation, easier troubleshooting, and lower labor costs. Application: OEM control panels and service panels in busy production facilities. Feature Maintained contact and a two-position toggle switch provide clear on/off state, preventing accidental operation. Impact: safer operation and improved operator confidence in control actions. Application: manual start-stop stations and local control points. Feature Copper-alloy terminals and brass screws deliver durable, vibration-resistant connections. Impact: long service life in high-vibration environments with minimal loosening risk. Application: industrial assemblies requiring robust electrical integrity.
Get a Quick Quote for a Eaton AHMC240L-1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton AHMC240L-1?
Enquire Now
FAQs
AHMC240L-1 is rated for 40A at 600V in a single-phase, two-pole configuration and supports #14-4 AWG conductors with side-wired box lug terminals for secure, reliable wiring in panel installations.
Install the device in a panel with a NEMA 1 enclosure for indoor use. Mount via panel mounting method, connect wiring through the side-wired box lug terminals rated for #14-4 AWG conductors, and ensure the maintained toggle is in the desired position before power application.
Yes. The AHMC240L-1 carries cULus listing and NAFTA compliance, providing assurance for electrical safety and regional trade requirements in industrial installations.
Best suited for control panels in conveyors, pumps, and other industrial machinery that require reliable single-phase motor control up to 40A, with a durable stainless steel NEMA 1 enclosure for harsh factory environments.
The device offers robust copper-alloy terminals, a maintained two-position toggle, and tool-free wiring with side-lug connections, reducing installation time, improving reliability, and lowering maintenance costs in high-usage industrial settings.
