Eaton B221-30FGFWRTR Air Conditioning Disconnect - UL Listed
Part Number: B221-30FGFWRTR
Quick Summary
An Eaton air conditioning disconnect provides safe isolation for HVAC equipment in commercial and industrial installations. This helps technicians avoid extended downtime and reduce risk during service, startup, and maintenance. UL Listed safety certification supports compliance, while its 500V AC rating and 100 kAIC interrupting capability enable robust protection. Designed for easy integration with Bussmann series fuses and ferrule-end connections, it lowers total cost of ownership for HVAC protection assemblies. The compact 16 in depth, 9 in height, and 11.5 in width footprint fits standard service panels, and at 27 lb it offers durable field performance. Its non-indicating, fast-acting design minimizes arc energy while enabling quick maintenance cycles. Weighing 27 lb, the unit is rugged enough for demanding field deployments and steady operation.
Product Information
Extended Description
B221-30FGFWRTR Eaton: Eaton air conditioning disconnect, Bussmann series F60 fuse, 500V, 30A, 100 kAIC Vac, 50 kAIC Vdc, Non Indicating, Fast Acting, Ferrule end X ferrule end
Product Name
Eaton air conditioning disconnect
Catalog Number
B221-30FGFWRTR
UPC
743172087232
Product Length/Depth
16 in
Product Height
9 in
Product Width
11.5 in
Product Weight
27 lb
Certifications
UL Listed
Type
Air conditioning disconnect
Residential and Light Commercial, Air Conditioning Disconnects, Volume 1 Tab 6
Eaton Specification Sheet - B221-30FGFWRTR
B221-30FGFWRTR~REPLACED BY B221-30FGFWTST
B221-30FGFWRTR~REPLACED BY B221-30FGFWTST
Feature: 500V AC voltage rating and 30A current rating with 100 kAIC VAC / 50 kAIC VDC interrupting capability. Business impact: High fault current handling paired with solid isolation enhances equipment protection and reduces unplanned outages in HVAC systems. Application: Suitable for commercial and industrial air conditioning protection schemes where rapid interruption is required. Feature: Non-indicating, fast-acting design. Business impact: Faster disconnects minimize arc energy and shorten downtime during servicing. Application: Ideal for service panels and installations where status indication is not necessary but reliability is critical. Feature: Ferrule-end terminals (X ferrule end). Business impact: Simple, secure terminations and straightforward field wiring. Application: Compatible with ferrule-based wiring and Bussmann fuse integrations for reliable protection. Feature: UL Listed certification. Business impact: Regulatory compliance and safer installations across building codes. Application: Required for HVAC disconnects in many procurement specs. Feature: Integrated with Bussmann series F60 fuses. Business impact: Streamlined protection design with proven fuse compatibility, reducing inventory variety. Application: Effective in both new builds and retrofit HVAC protection.
Get a Quick Quote for a Eaton B221-30FGFWRTR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton B221-30FGFWRTR?
Enquire Now
FAQs
Follow standard panel installation practices: mount the disconnect in a rated enclosure, align with the panel cutout, and secure the ferrule-end wiring to the designated terminals. The unit measures 16 in depth, 9 in height, and 11.5 in width, and weighs 27 lb, which informs support and mounting provisions. Ensure power is de-energized, observe UL Listed safety requirements, and use compatible ferrule terminations with approved conductors for reliable service and safe isolation during HVAC maintenance.
Key electrical specifications are 500 V AC maximum and 30 A current capacity, with interrupting ratings of 100 kAIC on AC and 50 kAIC on DC. The unit is non-indicating and fast-acting, which means it interrupts fault currents quickly to minimize arc energy. It is designed for HVAC loads and is compatible with Bussmann series F60 fuses to complete a protection scheme. These ratings guide fuse selection, panel design, and coordination with upstream protection devices, ensuring reliable operation under fault conditions while meeting code requirements.
UL Listed indicates compliance with recognized safety standards for electrical disconnect devices in many markets, but the data provided does not specify CE or IP ratings. For installations in regions requiring CE marking or IP protection, validate with project specifications and consider enclosure ratings or alternative product variants that carry the required certifications. Always follow local code requirements and manufacturer installation instructions.
Ferrule-end terminals simplify field wiring, improve termination reliability, and pair with Bussmann F60 fuses for a cohesive protection scheme. This combination supports quick fault interruption, reduces wiring errors, and aligns with common HVAC protection architectures in commercial systems. The design also facilitates straightforward BOM management and reliable serviceability during routine maintenance and fault repair.
The unit provides a 16 inch depth, 9 inch height, and 11.5 inch width, with a shipping weight of 27 pounds. This compact footprint fits standard service panels and supports durable, robust field installation for HVAC protection. Plan mounting brackets and clearance accordingly to ensure safe operation and easy access for testing, wiring, and maintenance.
